Grizzly T28372 Instructions Manual

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The Model T28372 Bed & Tool Post Extensions
are designed to fit on the Model G0838 lathe.
The 22 ⁄ " bed extension can be mounted to the
7
8
end of the lathe bed to expand total work area, or
it can be offset from the lathe bed to provide a 28"
swing over the bed extension for outboard turning
operations.
The tool post extension can be mounted to
the tool rest base that came with your lathe. It
should always be used when the bed extension
is mounted for outboard turning operations to
ensure the tool rest can be properly positioned.
Figure 1. T28372 Bed & Tool Post Extensions.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
COPYRIGHT © APRIL, 2024 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 10/23) #JA23145 PRINTED IN CHINA
***Keep for Future Reference***
MODEL T28372
BED & TOOL POST
EXTENSIONS FOR G0838
INSTRUCTIONS
Wear safety glasses during
the entire setup process!
Inventory
Description (Figure 2)
A. Tool Post Extension ..........................................1
B. Cap Screws M10-1.5 x 30 ...............................4
C. Locking Handle M10-1.5 x 18 ..........................1
D. Bed Extension ..................................................1
A
Figure 2. Inventory.
B
D
V1.04.24
Qty
C
