Grizzly T32734 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The Model T32734 Gouge Grinding Attachment
secures your spindle gouges, bowl gouges, and
roughing gouges at angles up to 40° for sharp-
ening bevels at repeatable angles and shapes.
The brass knob locks in your tool and doubles
as a thumb rest while rounding gouges. The jig
holds tools up to 1 ⁄
9
16
⁄ "–1 ⁄ ". Quickly grind fingernail profiles, side
3 3
16 8
grinds, and simple bevels, as well.
To reduce your risk of
serious injury, read this
entire
using machine.
Figure 1. Example of gouge attachment in use.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
" wide with shafts between
manual BEFORE
COPYRIGHT © OCTOBER, 2021 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 10/21) #CS22114 PRINTED IN TAIWAN
MODEL T32734
GOUGE GRINDING
ATTACHMENT FOR T32732
INSTRUCTIONS
Using Gouge Attachment
The gouge attachment secures your gouge and
rests in the V-holder of the long arm to pivot for
bevels, side grinds, and fingernail gouges.
Eye and face injuries and respiratory prob-
lems can occur while operating this tool.
Wear personal protective equipment to
reduce your risk from these hazards.
Keep hair, clothing, and
jewelry away from mov-
ing parts at all times.
Entanglement can result
in death, amputation, or
severe crushing injuries!
V1.10.21
