HYPERICE Normatec Elite Operating Instructions Manual page 3

Do not dry clean
Do not tumble dry
Do not bleach
Do not iron
EU RF transmitter symbol
FCC approved equipment authorization
The Bluetooth figure mark
Warning symbol to identify a hazard that may lead to
death or serious injury
Caution symbol to indicate the need for the user to
consult the instructions for use for important cautionary
information such as warnings and precautions that
cannot, for a variety of reasons, be presented on the
medical control unit itself
Tip to provide guidance to make use easier. Risk to user
is considered negligible
Indicates the manufacturer's model number so the
device can be identified.
INDICATIONS FOR USE
The Normatec Elite is an air pressure massager intended to temporarily relieve minor muscle aches and/
or pains, and to temporarily increase circulation to the treated area.
RISKS AND BENEFITS OF THE NORMATEC ELITE
The risks and benefits of using the Normatec Elite are similar to having a massage.If the Normatec
Elite massage feels uncomfortable, you can reduce the level or stop the session. Benefits include the
temporary relief of minor muscle aches and pains, and increased circulation in the area being treated.
Please call customer service at +1.949.565.4994 if you have any questions.
ILLUSTRATIONS of ME SYSTEM COMPONENTS
1 2 3 4
On attachment tag
On attachment tag
On attachment tag
On attachment tag
In manual
On control unit
On control unit
In manual and on control unit
In manual
In manual
On control unit
6
1 - 5. Zones
6. Control unit
5
2 3 4 5 6 7
8
9
1
10
1
OPERATING INSTRUCTIONS
WARNING! BEFORE OPERATING THIS DEVICE: Read all warnings at the beginning of this manual. If
you do not understand these operating instructions, contact Hyperice at +1.949.565.4994. Make sure that
the equipment operating environment meets the specifications otherwise unexpected consequences,
e.g. damage tot he equipment, could result. The operating environment of the equipment must meet
the requirements specified in this manual. If device is exposed to extreme temperatures, allow device to
acclimate to ambient temperature for 30 minutes before use.
SET UP THE DEVICE
• Step 1: Plug the charger into an electrical outlet and then into the Normatec Elite control unit. The charger
has a bifurcated cable so you can charge your left and right Normatec Elite legs at the same time.
This control unit is equipped with a lithium-ion battery. The battery automatically charges when the
charger is connected to the Normatec Elite control unit and an electrical outlet. Battery status
indicator lights show charge status; one light is low battery, five lights is fully charged
• Step 2: Put the device on. The control units should sit towards the outside of either leg. Find a
comfortable position sitting, reclined, or lying down. Never try to use the device with the zipper partially
or totally unzipped—this could void your warranty.
Be sure to zip the legs fully before starting treatment to prevent damage to your Normatec Elite
• Step 3: Press the power button on the Normatec Elite control unit firmly for one second to turn on the
device. While the control unit is on, the display will light up and show the current settings for Level, Time
and ZoneBoost.
ADJUST THE PRESSURE LEVEL
Adjust the pressure level of the session by pressing the pressure level adjustment button on the left of
the level indicators. Pressure level 1 is the gentlest setting. The massage becomes more intense as the
pressure level is increased. Level can be adjusted while the session is running.
ADJUST THE SESSION TIME
Adjust the session time by pressing the time adjustment button on the left of the display screen. The session
time can be set to 15, 30, 45 and 60 minutes. Time can be adjusted while the session is running. Tap the time
adjustment buttons to cycle through the session time options to add or subtract time from the session.
1. Power button
2. Bluetooth status indicator
®
3. Start/Stop button
4. HyperSync status indicator
™
5. ZoneBoost button
™
6. Time adjustment button
7. Pressure level adjustment button
8. Display screen
9. Battery status indicator
10. Power jack
1. Wall outlet plug
2-3. Barrel connectors
2
3
