- Page 1 #61-800 800 Series Power Clamp Meter 61-800 Power Clamp True RMS 61-800 Power Clamp True RMS 1. Transformer Jaw 2. Transformer Trigger 3. Data Hold Button 4. Rotary Function Switch 5. LCD Display 6. Function Buttons 7. Input Terminals...
-
Page 2: Lcd Display
WARNING! Data Hold Button 1. DO NOT UNDER ANY CIRCUMSTANCES EXCEED THESE • The data hold button is used to capture and hold a reading RATINGS: on the LCD display. - Voltage is not to exceed 800 Volts. • Press the button again to release the reading. - Wattage, Resistance and Continuity functions are not to be performed on circuits capable of delivering greater than LCD Display... - Page 3 MIN/MAX Button • The Min/Max button is used to toggle between the mini- mum and maximum values captured by the clamp meter. • Press once to display the minimum value. • Press again to display the maximum value. • Press a third time to return to normal measurement mode. Range Button •...
- Page 4 DC Current Measurements 4. Release the trigger and be sure that the jaws have closed completely. DC Current Resolution Accuracy 5. If the meter is in auto-ranging mode, the range will be auto- Range matically selected. 6. If the meter is in manual ranging mode, press the range but- 400A 0.1A ±(1.5% +3)
-
Page 5: Ac Voltage Measurements
To Connect to a Monitoring Device 5. If the meter is in manual ranging mode, press the range 1. The analog output of the meter is proportional to the current button to select the desired range. measurement (1mV/A). 6. Measure AC voltage. 2. - Page 6 AC+DC Watt Measurement Temperature Measurement AC+DC Watt Range Resolution Accuracy Temperature Range Resolution Accuracy (250V max) -50 to –400°F 0.1°F ±(1% +3) 40kW 0.01kW ±(2.5% +5) -400 to 1000°F 1°F 400kW 0.1kW Overload Protection: 600VAC AC+DC Watt Range Resolution Accuracy (600V max) 400kW 0.1kW...
-
Page 7: Battery Replacement
To Measure Resistance and Continuity Battery Replacement 1. Set the rotary switch to Warning 2. Insert the black lead into the COM port and the red lead into Do not touch or adjust any components inside the clamp the port. when the back case is removed. -
Page 8: Lifetime Limited Warranty
Any implied warranties arising out of the sale of an IDEAL product, including but not limited to implied warranties of mer- chantability and fitness for a particular purpose, are limited to the above.
