- Page 1 QuickStart Guide FortiGate 1500G Series FG-1500G and FG-1501G FG-1500G-ACDC-QSG-20221208.indd 1 FG-1500G-ACDC-QSG-20221208.indd 1 2022-12-08 12:01:45 PM 2022-12-08 12:01:45 PM...
- Page 2 Fortinet. For absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet’s internal lab tests.
-
Page 3: Before You Begin
Before you begin Register your device to access FortiGuard updates, cloud management, firmware upgrades, technical support and warranty coverage. http://support.fortinet.com FG-1500G-ACDC-QSG-20221208.indd 3 FG-1500G-ACDC-QSG-20221208.indd 3 2022-12-08 12:01:45 PM 2022-12-08 12:01:45 PM... - Page 4 For contracts, licensing, product registration and account management, contact FortiCare Support at https://www.fortinet.com/support/contact Self-service Resources Access our knowledge base, forums, videos and technical experts at https://www.fortinet.com/support/support-services/forticare-support Thank you for choosing Fortinet FG-1500G-ACDC-QSG-20221208.indd 4 FG-1500G-ACDC-QSG-20221208.indd 4 2022-12-08 12:01:45 PM 2022-12-08 12:01:45 PM...
-
Page 5: Package Contents
Package Contents FortiGate 1500G Series FG-1500G and FG-1501G FortiGate Device QuickStart Guide 2x Power Cables 1x Ethernet Cable 1x Console Cable (AC models only) 4x Rubber Feet 2x SFP SX Transceivers 2x Mounting Brackets 8x Bracket Screws 6x Terminal Rings... -
Page 6: Setup Options
Setup Options Set up your Fortinet device locally or connect using forticloud.com MGMT Management Computer Ethernet Cable Note: For static IP configuration, use 192.168.1.1 with subnet mask 255.255.255.0 Speed (default): 9600 Data bits: Stop bits: Parity: None Flow Control: None... -
Page 7: Installation
SFP Modules Installation Cage Socket Removal Cage Socket Lock FG-1500G-ACDC-QSG-20221208.indd 7 FG-1500G-ACDC-QSG-20221208.indd 7 2022-12-08 12:01:46 PM 2022-12-08 12:01:46 PM... -
Page 8: Desktop Installation
Desktop Installation 1.5in 1.5in 1.5in 1.5in Note: Place the device on a flat, clean and stable surface. FG-1500G-ACDC-QSG-20221208.indd 8 FG-1500G-ACDC-QSG-20221208.indd 8 2022-12-08 12:01:47 PM 2022-12-08 12:01:47 PM... -
Page 9: Rack Mount
Rack Mount Note: The recommended clearance is 1.5 inches above and below the device. Caution: To avoid personal injury or damage to the device, it is recommended that two or more people mount the device on a rack. FG-1500G-ACDC-QSG-20221208.indd 9 FG-1500G-ACDC-QSG-20221208.indd 9 2022-12-08 12:02:00 PM 2022-12-08 12:02:00 PM... - Page 10 FG-1500G Series Front Panel FortiGate 1500G CONSOLE MGMT Green: Normal operation STATUS Flashing Green: Booting up Red: Major alarm Off: Device is off Red: Major alarm detected ALARM Amber: Minor alarm detected Off: No errors detected Green: Operating in an HA cluster Red: HA failure Off: HA disabled Green: Device is on...
- Page 11 X5 — ULL — X7 X6 — ULL — X8 Ports 1 to 16 (RJ45) RJ45 Ports Green: Link established LINK/ACT Flashing Green: Data activity Off: No link established LINK/ACT SPEED Green: Connected at 1000 Mbps SPEED Amber: Connected at 100 Mbps Off: Connected at 10 Mbps or not in use Ports 17 to 24 (SFP) Green: Connected at 1 Gbps...
- Page 12 FG-1500G Series Rear Panel SSD2 SSD1 FAN1 FAN2 FAN3 FG-1500G-DC Series Rear Panel SSD2 SSD1 FAN1 FAN2 FAN3 DC Models Only (FG-1500G-DC and FG-1501G-DC) This product is only intended for installation and use in a Restricted Access Location. The DC power cables are intended to be used only for in-rack wiring, must be routed away from sharp edges, and must be adequately fixed to prevent excessive strain on the wires and terminals.
- Page 13 PWR2 PWR1 FAN4 FAN5 Power Supply for FG-1500G and FG-1501G 100-240VAC, 50/60Hz, 6A Max (2x PSU) 1+1 Redundant, hot-swappable power supplies Input LED Indicators Green: Input voltage within normal range Green: Over or under voltage warning Flashing Off: No input power Output LED Indicators Green: Output voltage normal Green: Standby mode...
-
Page 14: Cautions And Warnings
Cautions and Warnings Environmental specifications Ambient operating temperature: 0°C to 40°C Rack Mount Instructions - The following or similar rack-mount instructions are included with the installation instructions: Instructions de montage en rack - Les instructions de montage en rack suivantes ou similaires sont incluses avec les instructions d’installation: Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. -
Page 15: Regulatory Notices
Do not put any load on the slide-rail mounted equipment in the installation position. Não coloque nenhuma carga no equipamento montado em trilho deslizante na posição de instalação. Do not leave the slide-rail mounted equipment in the installation position. Não deixe o equipamento montado em trilho deslizante na posição de instalação. Laser Class 1 optical transceiver shall be used only L’émetteur-récepteur optique de classe 1 laser doit être utilisé... - Page 16 EU or countries that have implemented the EU Directives and/or spectrum regulation. Any Fortinet products not obtained directly from Fortinet or Fortinet’s authorized partners may not comply with EU Directives and Fortinet makes no assurances for such products.
- Page 17 Denna produkt överensstämmer med direktiv 2014/53/EU. Note: The full Declaration of Conformity for this product is available in the link below: https://site.fortinet.com/ProductRegulatory/EU Compliance with 2014/53/EU Radio Equipment Directive (RED) In accordance with Article 10.8(a) and 10.8(b) of the RED, the following table provides information on the frequency bands used and the maximum e.i.r.p.
- Page 18 National Telecommunications Commission (NCC) – Taiwan NCC警語 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使 用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射頻器材之 使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理法規 定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 China 此为A级产品，在生活环境中，该产品可能会造成无线电干扰。这种情况下，可能需要用户对其采取切实可行的措施 FG-1500G-ACDC-QSG-20221208.indd 18 FG-1500G-ACDC-QSG-20221208.indd 18 2022-12-08 12:02:03 PM 2022-12-08 12:02:03 PM...
- Page 19 FG-1500G-ACDC-QSG-20221208.indd 19 FG-1500G-ACDC-QSG-20221208.indd 19 2022-12-08 12:02:03 PM 2022-12-08 12:02:03 PM...
- Page 20 Fortinet.com FG-1500G-ACDC-QSG-20221208.indd 20 FG-1500G-ACDC-QSG-20221208.indd 20 2022-12-08 12:02:03 PM 2022-12-08 12:02:03 PM...
