NB6L239MNEVB
NB6L239MNEVB Evaluation
Board User's Manual
Description
The NB6L239 Evaluation Board was designed to provide
a flexible and convenient platform to quickly evaluate,
characterize and verify the performance and operation of the
NB6L239. This user's
information on board contents, layout and its use. It should
be used in conjunction with the NB6L239 data sheet:
(www.onsemi.com).
The NB6L239 is a differential Receiver to differential
LVPECL Clock Divider. The board features Output Enable
control of the Outputs.
© Semiconductor Components Industries, LLC, 2012
February, 2012 − Rev. 1
manual provides detailed
Figure 1. Evaluation Board
EVAL BOARD USER'S MANUAL
Board Features
•
Accommodates the electrical characterization of the
NB6L239
•
Selectable Jumper for the VT pin, minimizing cabling
•
CLK/CLK input and QA/QA and QB/QB output pins
are accessed via SMA connectors
•
MR, EN and Clock Divide Select pins are accessed via
SMA Connectors or by the Logic Switches
•
Convenient and compact board layout
•
2.5 V, 3.3 V Power Supply Operating Range
1
http://onsemi.com
Publication Order Number:
EVBUM2081/D
