- Page 1 INSTALLATION MANUAL Sinks and bowls SBL 10, 20, 30 and SSK10 series...
-
Page 2: Table Of Contents
1. Introduction General This is the installation manual for the Thetford's Sinks and Bowls. The manual is meant for competent installers who will install the appliance in a caravan, camper or holiday home. Read the information and instructions carefully and follow them strictly to install the appliance safely and correctly. -
Page 3: Safety
In terms of serviceability, this means that a dealer or authorised Thetford service partner must be able to remove and re-install the Thetford product within the time that is allowed according to the Thetford time-list, using standard tools and equipment. -
Page 4: Drawings And Models
4. Drawings and models Aftermarket models are supplied with templates, for easy position and placement. Table 1: Available drawings and models Model* 2D Cut Out Template SBL10 STEM0006 SBL17 STEM0007 SBL22 STEM0001 SBL23 STEM0002 SBL30 STEM0003 SBL33 STEM0202 SBL34 STEM0005 SSK10 STEM0008 * Not all models are available for the Aftermarket. -
Page 5: Main Dimensions
Main dimensions SBL10 series SBL17 series SBL33 series SBL34 series SSK10 series Length x 470 x 360mm 550 x 360mm 480 x 480mm 400 x 445mm 630 x 470mm width Depth 153mm 135mm 145mm 145mm 153mm SBL22 series SBL23 series SBL30 series Diameter 362mm 461mm 405mm Depth 127mm 127 or... - Page 6 SBL17 series SBL170 models 315mm SBL172 models 13mm 315mm 132.5mm 30mm 180mm 30mm 132.5mm...
- Page 7 SBL22 series 336mm Ø 6mm Ø 315mm SBL23 series 426mm Ø 6mm Ø 405mm...
- Page 8 SBL30 series Ø 390mm SBL33 series The template provides two options: A for surface mounting. ■ B for flush mounting. Flush mounting has the extra rebate, not a full cut-out ■ for the area between A and B.
- Page 9 Surface mount 452 . 9 88 . 4 236 . 0 R112 . 0 R 80 . 0 R690 R112 . 0 Flush mount 484 . 0 18 . 5 453 . 0 R87 . 0 88 . 4 236 . 0 R112 .
- Page 10 SBL34 series The template provides two options: A for surface mounting. ■ ■ B for flush mounting. Flush mounting has the extra rebate, not a full cut- out for the area between A and B. Surface mount 387 . 0 86 .
-
Page 11: Installation
SSK10 series 38mm 183.5mm 162mm 38mm R696 605mm 6. Installation Read the applicable safety instructions in Safety. Prepare ■ Place the template on the worktop, where applicable. ■ Check the dimensions. Make sure there is enough space around the appliance. ■... - Page 12 Make sure the appliance is located centrally and level in the aperture. ■ Secure the appliance, to finish the installation. Use the applicable secure instructions per model in Secure below. Secure SBL10 and SSK10 series The sink is not completely flat on the worktop and is slightly higher at either end.
- Page 13 SBL10 only: Attach the rack bracket to the lid with sealant as shown. 65mm 65mm 186mm The curing time and the required pressure depend on the type of sealant. Always follow the instructions of the bonding manufacturer. Thetford recommends using a clear silicone sealant.
- Page 14 SBL17 series 1. Optional seal 2. Glass lid 3. Glass lid bump stop 4. Rivet nut 4,5mm 5. Bowl/sink 6. Clamping screw 7. Clamping bracket 8. Worktop ■ Place the rivet nuts (4) and clamping screws (6) through the screw position holes. ■...
- Page 15 ■ Tighten each nut with a 7mm spanner to clamp the bowl to the worktop. SBL23 series The SBL23 series has 3 different fixing systems to secure the appliance. For fixing systems 2 and 3, the 4 Ø6mm holes and corresponding 426mm distances are not required.
- Page 16 Fixing system 2 1. Self-adhesive foam seal 2. 15-30mm worktop 3. Clamping bracket 4. Washer 5. Self-locking nut The bowl is supplied with under-bowl fixings, equally spaced around the base of the bowl. A self-adhesive foam seal (1), which prevents water penetration, is already at- tached.
- Page 17 SBL30 series 1. Seal 2. Glass lid bump stop 4,5mm 3. Glass lid 4. Clamping bush 5. Bowl 6. Clamping screw 7. Clamping arm 8. Worktop ■ Remove the 4 glass lid bump stops (2), that are fitted into clamping bushes (4), to gain access to the clamping screws (6).
-
Page 18: After Installation
Flush mount 1. Seal 2. Glass lid bump stop 3. Glass lid 4. Clamping bush 5. Bowl 6. Clamping screw 7. Clamping arm 8. Worktop ■ Remove the 4 glass lid bump stops (2), that are fitted into clamping bushes (4), to gain access to the clamping screws (6). -
Page 19: Service & Questions
If you contact an authorised local Service Centre in your country, provide the details of the model and serial number plus the date of purchase. SPECIMEN Serial Number Item Number Model Warranty For our warranty clause, please refer to the conditions mentioned on www.thetford.com. - Page 20 T +61 3 9358 0700 T +86 755 8627 1393 T +46 31 336 35 80 F not available F +86 755 8627 1673 F not available E infoaus@thetford.com.au E info@thetford.cn E infos@thetford.eu www.thetford.com.au www.thetford.cn Copyright 2020-2024 Thetford B.V. All rights reserved. SINS2150/0624-V03...
