Ocular LTE PLUS User Manual & Installation Manual
Hide thumbs
Also See for LTE PLUS:
- Installation manual (14 pages) ,
- User manual (6 pages) ,
- User manual (9 pages)
Subscribe to Our Youtube Channel
Related Manuals for Ocular LTE PLUS
Summary of Contents for Ocular LTE PLUS
- Page 1 LTE PLUS USER MANUAL & INSTALLATION GUIDE OC20-BC-7.2KW-Plus-A ocularcharging.com.au OC20-BC-22KW-Plus-A sales@ocularcharging.com.au 1300 912 650 Version 2.2...
-
Page 2: Table Of Contents
CONTENTS Welcome to Your LTE Plus ................. 3 EVSE Master app ....................4 User Manual ...................... 5 How to Charge - LTE Plus ................5 Schedule and Delayed Charging ..............7 Reports and Statistics .................. 8 Troubleshooting .................... 9 Warranty ....................... 9 Installation Guide..................... -
Page 3: Welcome To Your Lte Plus
Welcome to your Ocular LTE Plus! Resource Library FAQs Follow the links or scan to QR codes to access all our user manuals and technical documents. You will also find answers to the most common questions we receive. -
Page 4: Evse Master App
Download the EVSE Master app Click here to Click here to download download... -
Page 5: User Manual
USER MANUAL SECTION 1 HOW TO CHARGE - LTE PLUS Scan for a video overview of the EVSE Master app and how to start charging 1. CONNECT YOUR CHARGER AND APP After installation, launch the EVSE Master app. You will see a home screen with a Connect button. - Page 6 Charger Button a. Open the app and navigate to general settings via the button in the bottom right-hand corner of the screen b. Ensure the toggle “start charging by button” is switched ON c. Plug the charging cable into the car d.
-
Page 7: Schedule And Delayed Charging
SECTION 2 SCHEDULE AND DELAYED CHARGING DELAY CHARGING 1. Press custom charge on the home page. 2. Press the single charging tab. 3. The first slider will delay the start time based on your choice-up to 24 hours. 4. The second slider determines the duration by choosing the stop time. -
Page 8: Reports And Statistics
SECTION 3 REPORTS AND STATISTICS 1. Records and Statistics page 2. My records tab: records of all charging sessions that were started on your phone. 3. All records tab: all charging records that were stored in the charger. 4. Refresh button: synchronise all charging records to your phone. 5. -
Page 9: Troubleshooting
This product is warranted for 2 years by Ocular. For all faults or warranty related questions or claims, please contact Ocular at... -
Page 10: Installation Guide
INSTALLATION GUIDE SPECIFICATIONS Model Number OC20-BC-7.2KW-Plus OC20-BC-22KW-Plus Power Output 7.2kW (1- Phase) 22kW (3- Phase) Charging Connector Tethered 6m Type-2 Cable Display 3.5” LCD Screen + LED indication lights Frequency (Hz) 50Hz Input and Output Voltage 230V ± 20% per phase Input and Output Current 32A MAX per phase Operating Temperature... -
Page 11: Accessories Of Tethered Model
OCULAR LTE PLUS OVERVIEW ACCESSORIES OF TETHERED MODEL It is the installer’s responsibility to provide and install a suitable RCBO, cabling and isolator switch to complete the installation. Plate Station Holder Screws for Holder 30mm Screws 30mm Plastic Bolts Allen Key... -
Page 12: Installation Guide
INSTALLATION GUIDE Hammer the Place reference 30mm plastic paper on wall bolts into the holes Wall Drill the holes Take down the reference paper according to the reference paper from the wall Embed station into plate on the wall. Use Connector Clip Fix the plate with to connect base 30mm screws... -
Page 13: Illustration Of Screen And Led
Continuous light Red flashing Note: The Ocular LTE Plus will automatically restart when minor problems occur. For serious failures, the system cannot automatically recover. In order to remind user of this failure, the system will automatically countdown 10 seconds to restart. -
Page 14: Safety Warning
MAINTENANCE Ocular LTE Plus is only recommended for use in residential applications and use outside of this area (i.e. for commercial application) is outside of warranty. The product should be placed at an ambient temperature of -25C~+55C in relative humidity of no more than 95%. - Page 15 LTE PLUS ocularcharging.com.au sales@ocularcharging.com.au 1300 912 650...
