Summary of Contents for Ocular IQ TOWER IOCAP26-7SE-RW4
- Page 1 IQ TOWER INSTALLATION GUIDE IOCAP26-7SE-RW4 / IOCAP26-7TE-RW4 ocularcharging.com.au IOCAP26-22SE-RW4 / IOCAP26-22TE-RW4 sales@ocularcharging.com.au 1300 912 650 Version 2.2...
-
Page 2: Table Of Contents
CONTENTS Specifications ......................3 Product Overview ......................4 Safety Instructions .......................5 Installation ........................7 Tools Required ......................7 Overview of Steps ....................7 Step One - Check Box Contents ................7 Step Two - Floor Mounting ..................8 Step Three - Power Cable Wiring ................8 Step Four - Internet Connection ................9 Step Five - Verify The Installation .................10 Step Six - Secure Cover ..................10 LCD Display Details ....................11... -
Page 3: Specifications
Communication Type Modbus (TCP/IP) Energy Meter 2 x MID Meter, Optional NMI Pattern Approved Load Control Compatible with Ocular Load Controller or OCPP smart profiles General Data Ambient Air Temperature for Operation -30°C to +50°C Ambient Air Temperature for Storage -40°C to +70°C... -
Page 4: Product Overview
Wiring Rules. . LCD Screen & RFID Reader The Ocular IQ Tower is equipped with a 7 inch LCD screen allowing users to know the status of the charger. Details about the LCD screen are on page 11. The Ocular IQ Tower charger comes with an inbuilt RFID reader to allow for access control to the charging station. -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS WARNINGS Do not install or use the charger near flammable, explosive, harsh, or combustible materials, chemicals, or vapors. Turn off input power at the circuit breaker before installing or maintaining. Do not use or stop using the charger if it is defective, appears cracked, frayed, broken or other- wise damaged, or fails to operate. -
Page 6: Example Wiring Diagram
EXAMPLE WIRING DIAGRAM Regarding the installation of the Ocular Tower, each charger will need 2 connections to allow smart charging with Energy Tracking, Smart Control and Load Management. • Power connection • Internet connection Regarding the power connection of the chargers, each charger will have its own designated circuit from the distribution board as per required in Appendix P, AS 3000:2018 Australia Standard for EV charging stations. -
Page 7: Installation
4. Internet connection. 5. Verify the installation. 6. Secure cover and power up. STEP 1 - Check box contents If any components are damaged or missing, please contact your installer or Ocular Charging. Backplate key x 1 Ferrule crimps x 3... -
Page 8: Step Two - Floor Mounting
STEP 2 - Floor mounting 1. Open the charger backplate with the 2. Remove the screws and open the key provided. guard plate. 3. Anchor the charger to the concrete basement. STEP 3 - Power cable wiring 1. Cross the power cables through 2. -
Page 9: Step Four - Internet Connection
WiFi networks Choose the Wi-Fi SSID that you prefer, and then input the Wi-Fi Password 4. Submit and reboot the charger to apply for changes If Static IP address is required, contact the internet provider & Ocular charging for instructions. -
Page 10: Step Five - Verify The Installation
STEP 5 - Verify the installation 1. Verify the power cables are wired properly 2. Close the RCD to power on the charger unit, and you should see the LED lights sequentially illuminate green. 3. If the LED red light illuminates or flashes, refer to the Troubleshooting table on page 12. -
Page 11: Lcd Display Screen
LCD DISPLAY SCREEN Welcome Screen Scan the QR code or swipe the Connect the charging plug RFID card to start charging Charging in process Suspended by EV Suspended by EVSE Remove the charging plug Automatic upgrade mode acti- Software downloading and vated upgrading automatically Network upgrade mode... -
Page 12: Troubleshooting
If the status indicator doesn’t return to green, turn OFF the pedestal charger, and then back ON using the switch. 4 If the problem persists, please contact your installer or Ocular Charging. 1 There is a critical error. Status indicator is solid red 2 Unplug the charging plug from the EV immediately. -
Page 13: Maintenance & Repair
MAINTENANCE & REPAIR • Regularly inspect the Charger. If damage is found, contact your installer or Ocular Charging. • The Charger contains no user-serviceable components. If unit is not operating correctly, contact your installer or Ocular Charging. • Wipe the outside of the Pedestal Charger regularly with a clean damp cloth to... - Page 14 IQ TOWER ocularcharging.com.au sales@ocularcharging.com.au 1300 912 650...
