- Page 1 USER MANUAL IOCAH15-7T / IOCAH15-22T ocularcharging.com.au sales@ocularcharging.com.au 1300 912 650 Version 2.0...
- Page 2 Welcome to your Ocular IQ Home Solar! Download the Ocular App Click here to Click here to download download Warning: This product shall only be installed, repaired or serviced by an authorised electrician. All applicable local, regional and national regulations for...
- Page 3 Plug & Charge. OCULAR APP After downloading the Ocular App and adding the charger to it (See section 3), you can start and stop a charging session via the app, you can also stop a charging session through your car.
- Page 4 SET UP THE APP AND CHARGER Please ensure you have downloaded the OCULAR APP, other apps will not be compatible with your charger. (see page 1) Please scan QR Code or CLICK HERE to watch this video on how to connect your charger and...
- Page 5 Press add station, then enter your charger's serial number which can be found on the silver sticker on the side of the charger. The serial number begins with AW. eg. AW12345678912 Select the 'energy tab', then select 'add gateway'. Enter M_ followed by the serial number.
- Page 6 After registering your account and charger, you can invite other users to your group so that they can also use your charger from their APP. They will need to download the Ocular APP and register for an account following instructions from Section 2, Step 1.
- Page 7 Confirm. An invitation will be sent to their Ocular App shortly after, to accept it, first go to My/Profile tab, then click on the message symbol on the top right...
- Page 8 START AND STOP A CHARGING SESSION OPTION 1 : USING THE APP Under Energy tab, choose your desired charging mode: Solar only, Solar assist or Fast mode by pressing the drop down and selecting the desired mode. You can change the mode on the energy tab at any point in the charging session, you do not have to unplug or restart.
- Page 9 Plug your charger into the car, then start a charging session by pressing the 'start' button. This will then change to a 'stop' button, press this to stop the charging session or stop charging through the vehicle. To delay start, press the delay start button and choose up to a 3 hour delay. If your charger is not providing max charging speed, your current limit may be set too low.
- Page 10 1. Change charging speed during a charging session (Smart Charging Speed): Once the charging session has begun, there will be a slider appearing on the screen for you to adjust the speed up to 32 A. However, the maximum charging speed depends on the Maximum Current Limit set on the charger.
- Page 11 OPTION 2 : PLUG & CHARGE Go to the 'Group' tab and select your charger. Turn on the plug and charge feature by pressing the button. When you plug the car in, you will start charging on the saved mode settings and override any scheduled charging sessions, you do not have to press 'start'.
- Page 12 OPTION 3 : SCHEDULED CHARGING SESSIONS Press the plus button on the top right of the Schedule tab, and set the start time and end time. Please scan QR Code or CLICK HERE to watch this video on how to connect your charger and start charging! Select repeat to choose which days to utilise this charging schedule.
-
Page 13: Energy Tab
ENERGY TAB On the top is the grid, the middle is your home and the bottom you will see your charger. In the grid section, you will see either one number or three numbers, depending on whether you have a single or three-phase charger. A positive number means your home is drawing power from the grid. -
Page 14: Charging Modes
CHARGING MODES FAST MODE In this mode, the vehicle will be charged at maximum power. This power can come from a renewable energy source or the grid. If you have set a current limit on the schedule or by the electrician during installation that will determine maximum power. - Page 15 GUIDE TO CHARGING RECORDS & COST ESTIMATES RECORDS Go to the 'Record' tab for a complete overview of your charging history. You can choose the time frame of your records: 7 days, 30 days, 90 days up to 1 year, by pressing the days and selecting from the drop down menu.
- Page 16 IQ HOME SOLAR DOES THE CHARGER NEED TO BE CONNECTED TO THE INTERNET? The charger must be connected to the internet to function normally. • Ethernet using a CAT 6 cable to your internet modem • WI-FI to the charger ▪...
- Page 17 Yes. If you have a solar system that is constantly exporting electricity to the grid, then the Ocular IQ Home Solar will allow you to use that excess solar efficiently to recharge your vehicle’s battery. CT Clamps installed on the incoming mains supply are used to measure the excess solar being sent to the grid in real time.
- Page 18 For the most part, any excess solar produced by the system will be absorbed by the battery. The Ocular IQ Home Solar modes work by using CT clamps to understand what you are exporting out to the grid. You may find that the home battery is absorbing most of your excess solar generated first and so what’s going out to the grid is minimal.
- Page 19 HOW MUCH EXCESS SOLAR ENERGY IS MY HOME IS PRODUCING? You can tell this from the Energy tab on the Ocular app. This will differ slightly depending on whether your system is single or three phase. For single-phase, only one (1) value will be shown on this screen.
- Page 20 Single Phase The negative sign indicates that power is in excess and is being exported from the solar panels to the grid. When this number is consistently between 0 and -7 amps there is not sufficient excess solar to use solar only. Three Phase There will be three numbers presented on the app.
- Page 21 WHERE DO I DOWNLOAD THE OCULAR APP? The Ocular App is required to use the charger. Click on the Apple or Google App store to download the Ocular App or search via your relevant app store.
- Page 22 IS THE OCULAR IQ HOME SOLAR OCPP COMPATIBLE? Yes, the Ocular IQ Home Solar is OCPP compatible. Please note, if an OCPP software platform is enabled on the charger, the Ocular App and some of the local functions of the unit will not be available.
