- Page 1 Charging the EV revolution IQ SERIES INSTRUCTION MANUAL B01-0001-0056...
- Page 2 How to Operate How To Start Normal Charge Connect to the charger 1. Follow the instruction displayed on the screen. (RFID or OCPP App Authentication may be required) 2. Firmly insert the charging cable into the charging station. 3. Insert plug into the electric vehicle and ensure the plug is fully seated. 4.
- Page 3 Functions Meter Charging Time RFID Reader Voltage OCPP Connection Current Ethernet Energy Usage In-built 4G Wifi...
- Page 4 Scan the QR code or swipe Welcome Screen Connect the charging plug the RFID card to start charging Charging in process Suspended by EV Suspended by EVSE Software downloading Remove the charging plug Automatic upgrade mode activated and upgrading automatically Network upgrade mode Micro SD card upgrade mode Factory reset activated...
-
Page 5: Troubleshooting
Ocular Charging. MAINTENANCE & REPAIR • Regularly inspect the Charger. If damage is found, contact your installer or Ocular Charging. • The Charger contains no user-serviceable components. If unit is not operating correctly, contact your installer or Ocular Charging.
