- Page 1 INSTALLATION GUIDE IOCAW13-7S-Solar / IOCAW13-22S-Solar ocularcharging.com.au IOCAW13-7T-Solar / IOCAW13-22T-Solar sales@ocularcharging.com.au Version 2.0 1300 912 650...
-
Page 2: Table Of Contents
Charger Configuration - CT Clamp Set Up ............13 Charger Configuration - Grid Supply Set Up ............14 Installation Verification.................... 15 Connect Charger to Ocular Smart Home App ............16 Appendix A - Troubleshooting ................17 Appendix B - Charger Screen Details..............18 Appendix C - CT Clamp Specifications .............. -
Page 3: Specifications
SPECIFICATIONS Model Number IOCAW13-7S / 7T-SOLAR IOCAW13-22S / 22T-SOLAR 230V AC single-phase: 400V AC three-phase: Voltage & Wiring LIVE, NEUTRAL ,& EARTH. L1, L2, L3, NEUTRAL, & EARTH. Current and Power Maximum 32A and 7kW Maximum 32A and 22kW Frequency 50-60 Hz Internal RCD AC 30mA, DC 6mA... -
Page 4: Product Overview
PRODUCT OVERVIEW Item LED indicator 2.8’’ LCD screen Status indicator, Fault, Online, Charging RFID card reader Physical button Type-2 charging socket... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS This document contains important instructions and warnings that must be followed when installing and maintaining the workplace pedestal charger WARNINGS Do not install or use the charger near flammable, explosive, harsh, or combustible materials, chemicals, or vapors. Turn off input power at the circuit breaker before installing or maintaining. Do not use or stop using the charger if it is defective, appears cracked, frayed, broken or otherwise damaged, or fails to operate. -
Page 6: Installation Notes And Box Contents
NOTES BEFORE INSTALLATION The charger should be protected by an external Residual Current Device (RCD) to be installed in the upstream circuit which complies with the following: • Type-A Rated residual operating current not exceeding 30 mA • Required as per Appendix P, AS 3000:2018 Australia Standard for EV charging stations. -
Page 7: Wall Mounting
WALL MOUNTING AND WIRING Remove the backplate from the charger by sliding it down. Mount the backplate to the wall with the included screws. Connect the cable through the bottom of the junction box. Ensure conduit is connected to the bottom of the power box. -
Page 8: Internet Connection And Charger Mounting
INTERNET CONNECTION AND CHARGER MOUNTING Connect the charger to the internet. The charger can be connected via ethernet or WIFI. Ethernet is recommended for stability. Connect the ethernet cable to the top port. Install the charger to the backplate. Line up the mounting screws and then slide the charger down to lock the connection. -
Page 9: Ct Clamp Installation
CT CLAMP INSTALLATION CT Clamps need to be installed on the of the main switch board. grid side Isolator Main Switch Board Note: The CT Clamp cable is 20 meters long. The Charger must be installed within 20 meters of the incoming supply. -
Page 10: Single Phase Ct Installation Diagram
SINGLE PHASE CT INSTALLATION Live Neutral RS485 The arrow on the CT must be pointing towards the Main Board and away from the grid supply THREE PHASE CT INSTALLATION Live Neutral RS485 The arrow on the CT must be pointing towards the Main Board and away from the grid supply... -
Page 11: Ct Clamp Wiring
CT CLAMP INSTALLATION & WIRING Run the CT clamp wires through the grey gland/hole located at the bottom of the charger. Wire into terminal block as indicated in the picture below. For Single Phase, use the first two ports on the right. N3 P3 N2 P2 N1 P1... -
Page 12: Web-Interface Access And Wifi Setup
Password : Evcharging123 After entering the username and password the Ocular web-interface will load. (Optional): Set up WIFI configuration (not needed if ethernet is used). • Navigate to the Network tab (see picture below). • Click the “Scan” button to start scanning for available WiFi network. -
Page 13: Charger Configuration - Settings Access
CHARGER CONFIGURATION - ACCESSING THE ADVANCED SETTINGS PAGE Do not change settings other than outlined below as this may affect operations. 1. Log in to the web-interface of the charger. (Refer to page 11). 2. Click on the Balance tab, and then click on “Advanced Settings”. 3. -
Page 14: Charger Configuration - Ct Clamp Set Up
CHARGER CONFIGURATION - CT CLAMP SET UP 1. Scroll down the page until you can see the settings boxes for HUB1 and Grid Current. 2. Ensure HUB1 is switched on (Blue indicator). 3. Configure HUB1 settings as in the pictures below. Note the differences between the Single Phase and 3 Phase setups. -
Page 15: Charger Configuration - Grid Supply Set Up
CHARGER CONFIGURATION - GRID SUPPLY SET UP Set the Rated Current and Safe Current. This is the maximum current that the main MCB can handle. Rated Current: This is the safe current reserved to prevent the circuit from Safe Current: overloading. -
Page 16: Installation Verification
4. Turn on the charger and check for any errors on the screen. 5. Verify that the charger is connected to the Ocular Server by checking Icons on charger screen. A. If the charger is showing (Server Error) then the charger will not function and this will likely require a return to site. -
Page 17: Connect Charger To Ocular Smart Home App
CONNECT CHARGER TO OCULAR SMART HOME APP 1. Search “Ocular Smart Home” or Ocular Charging” on the google play or apple app store. 2. Download, install, and launch the app. 3. Navigate to the Group page and click “Add Station”. -
Page 18: Appendix A - Troubleshooting
It usually takes less than 10 seconds. If the status indicator doesn’t return to blue, turn OFF the charger and then back ON. If the situation persists, contact Ocular Charging for Technical Support. Status indicator There is a critical error. -
Page 19: Appendix B - Charger Screen Details
APPENDIX B – CHARGER SCREEN DETAILS LCD DISPLAY DETAILS This page contains icons displayed on the top left of the charger that may help diagnose or verify the operation of the charger. Active - Charger component/feature is enabled and operating effectively. Inactive - Charger component/feature has been disabled in the configuration settings for the charger. - Page 20 APPENDIX B – CHARGER SCREEN DETAILS Connect the charging plug Remove the charging plug Scan the QR code or swipe the Charging in process - Shows RFID card to start charging Session Duration, Total power used, charging current and voltage per phase Suspended by EV - Indicator Suspended by EVSE - that charging session has...
-
Page 21: Appendix C - Ct Clamp Specifications
Prior to setting up the CT clamps, please ensure that you have the correct CT and CT Ratio setup. Only use CT clamps provided by Ocular – The wrong CT clamps will cause a misreading and void warranty. If you must use your own CT please speak to Ocular and confirm suitability.
