Gree GKH(09)DA-D6DNA1B/I Owner's Manual

Gree GKH(09)DA-D6DNA1B/I Owner's Manual

One-way cassette type air conditioner
Hide thumbs

Advertisement

Quick Links

Download this manual
Change for life
Owner's Manual
Original Instructions
One-Way Cassette Type Air Conditioner
9,000Btu-20,000Btu
Thank you for choosing our product.
Please read this Owner's Manual carefully before operation and
retain it for future reference.
If you have lost the Owner's Manual, please contact the local agent
or visit www.gree.com or send an email to global@cn.gree.com for
the electronic version.

Advertisement

loading
Need help?

Need help?

Do you have a question about the GKH(09)DA-D6DNA1B/I and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gree GKH(09)DA-D6DNA1B/I

Summary of Contents for Gree GKH(09)DA-D6DNA1B/I

  • Page 1 Thank you for choosing our product. Please read this Owner’s Manual carefully before operation and retain it for future reference. If you have lost the Owner's Manual, please contact the local agent or visit www.gree.com or send an email to global@cn.gree.com for the electronic version.
  • Page 2 Indoor Unit Indoor Unit OWC09HP230V1R32AH GKH(09)DA-D6DNA1B/I OWC12HP230V1R32AH GKH(12)DA-D6DNA1B/I OWC18HP230V1R32AH GKH(18)DA-D6DNA1B/I OWC20HP230V1R32AH GKH(20)DA-D6DNA1B/I...

  • Page 3: Table Of Contents

    Contents 1 Safety Notices (Please be sure to abide)················································· 1 2 Product Introduction ············································································· 3 2.1 Names of Key Components ································································· 3 2.2 Rat ed Working Condition ···································································· 4 2.3 Operation and Introduction of Remote Controller ······································· 4 3 Preparations for Installation ································································· 11 3.1 Installation Position Selection·····························································...

  • Page 4: Explanation Of Symbols

    Explanation of Symbols WARNING This symbol indicates the possibility of death or serious injury. This symbol indicates the possibility of injury or damage to CAUTION property. Indicates important but not hazard-related information, used NOTICE to indicate risk of property damage. Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons.

  • Page 5: Installation Notes

    7KH UHIULJHUDQW SURFHVV RU WR FOHDQRWKHU WKDQ WKRVH UHFRPP 5HIULJHUDQW %HIRUH LQVWDOO WKH HQGHG E\ WKH PDQXIDFWXUHU 6DIHW\ *URXS DSSOLDQFH UHDG 6HUYLFLQJ VKDOO EH SHUIRUPHG RQO\ DV UHFRPP WKH LQVWDOODWLRQ HQGHG E\ WKH PDQXIDFWXUHU $SSOLDQFH ILOOHG ZLWK PDQXDO ILUVW 6KRXOG UHSDLU EH QHFHVVDU\FRQWDFW \RXU QHDUHVW IODPPDEOH PDJDV 5 DXWKRUL]HG 6HUYLFH &HQWUH $Q\ UHSDLUV FDUULHG RXW %HIRUH UHSDLU WKH...
  • Page 6 6DIHW\ RSHUDWLRQ RI IODPPDEOH UHIULJHUDQW table a - Minimum room area ( m &KHFN ZKHWKHU WKHUH LV ILUH VRXUFH RU SRWHQWLDO %DVHG RQ 8/  UHTXLUHPHQWV ILUH VRXUFH LQ WKH PDLQWHQDQFH DUHD 7KH IROORZLQJ LQVWDOODWLRQ KHLJKW DQG DUHD IRU  7KH QDNHG IODPH LV SURKLELWHG LQ WKH PDLQWH FXVWRPHU UHIHUHQFH QDQFH DUHD DQG WKH ³QR VPRNLQJ´...

  • Page 7: Safety Operation Of Flammable Refrigerant

    Safety operation of flammable refrigerant Field-made refrigerant joints indoors shall Safety of Construction be tightness tested. The test method shall For appliances using FLAMMABLE REFRIG- have a sensitivity of 5 grams per year of ERANTS, all joints made in the installation refrigerant or better under a pressure of at between parts of the REFRIGERATING least 0,25 times the maximum allowable...

  • Page 8: Operation And Maintenance

    GENERAL INFORMATION WARNING Operation and Maintenance 7KLV DSSOLDQFH FDQ EH XVHG E\ FKLOGUHQ DJHG IURP  \HDUV DQG DERYH DQG SHUVRQV ZLWK UHGXFHG SK\VLFDO VHQVRU\ RU PHQWDO FDSDELOLWLHV RU ODFN RI H[SHULHQFH DQG NQRZOHGJH LI WKH\ KDYH EHHQ JLYHQ VXSHUYLVLRQ RU LQVWUXFWLRQ FRQFHUQLQJ XVH RI WKH DSSOLDQFH LQ D VDIH ZD\ DQG XQGHUVWDQG WKH KD]DUGV LQYROYHG &KLOGUHQ VKDOO QRW SOD\ ZLWK WKH DSSOLDQFH...
  • Page 9 GENERAL INFORMATION WARNING ,I WKH DLU FRQGLWLRQHU RSHUDWHV XQGHU DEQRUPDO FRQGLWLRQV LW PD\ FDXVH PDOIXQFWLRQ，HOHFWULF VKRFN RU ILUH KD]DUG :KHQ WXUQLQJ RQ RU WXUQLQJ RII WKH XQLW E\ HPHUJHQF\ RSHUDWLRQ VZLWFK SOHDVH SUHVV WKLV VZLWFK ZLWK DQ LQVXODWLQJ REMHFW RWKHU WKDQ PHWDO 'R QRW VWHS RQ WRS SDQHO RI RXWGRRU XQLW RU SXW KHDY\ REMHFWV ,W PD\ FDXVH GDPDJH RU SHUVRQDO LQMXU\ )RU DSSOLDQFHV PDGH XS RI PRUH WKDQ RQH IDFWRU\ PDGH DVVHPEO\ VSHFLILHG...
  • Page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
  • Page 11 GENERAL INFORMATION WARNING FLUFXLW RU GDPDJH WR DLU FRQGLWLRQHU 3URKLELW RSHUDWLQJ KHDWLQJ HTXLSPHQW DURXQG WKH DLU FRQGLWLRQHU 3URKLELW RSHUDWLQJ WKH XQLW LQ WKH EDWKURRP RU ODXQGU\ URRP )DU DZD\ IURP ILUH VRXUFH LQIODPPDEOH DQG H[SORVLYH REMHFWV .HHS FKLOGUHQ IURP SOD\LQJ RU FOLPELQJ RQ WKH DLU FRQGLWLRQHU 'R QRW SXW RU KDQJ GULSSLQJ REMHFWV DERYH WKH DLU FRQGLWLRQHU 'R QRW UHSDLU RU GLVDVVHPEOH WKH DLU FRQGLWLRQHU E\ \RXUVHOI 'R QRW EORFN DLU RXWOHW RU DLU LQOHW...

  • Page 12: Safety Notices (Please Be Sure To Abide)

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit 1 Safety Notices (Please be sure to abide) WARNING! If not abide strictly, it may cause severe damage to the unit or the people. NOTE! If not abide strictly, it may cause slight or medium damage to the unit or the people.
  • Page 13 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit Diameter of power cord must After the power cord is be large enough. Damaged Connected, please install the power cord and connecting wire cover of electric box to avoid must be replaced by danger.

  • Page 14: Product Introduction

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit If abnormal condition occurs (e.g. unpleasant smell), please Do not repair the air turn off the unit at once and conditioner by yourself. disconnect power supply. Then Improper repair will cause contact service center.

  • Page 15: Rated Working Condition

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit 2.2 Rated Working Condition Indoor Side Condition Outdoor Side Condition Test condition Dry Bulb Temp ( ) Wet Bulb Temp ( ) Dry Bulb Temp ( ) Wet Bulb Temp ( ) Rated Cooling 26.7(80) 19.4(67)
  • Page 16 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit When selecting heat mode, the air conditioner Introduction for buttons on remote controller operates under heat mode. Press " + " or " - " button to adjust set temperature. Press "Fan" NOTE button to adjust fan speed.
  • Page 17 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit swing angle . When reaching your required + / - button angle, release the button. Press " + " or " - " button once increase or decrease NOTE set temperature 1 ( ). Holding " + " or " - " button, Press this button continuously more than 2s, the main 2s later, set temperature on remote controller will unit will swing back and forth from up to down, and...
  • Page 18 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit Function introduction for Timer on / Timer off button combination buttons TIMER ON button "TIMER ON" button can set the time for timer Energy-saving function on. After pressing this button, " "...

  • Page 19: Auto Clean Function

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit following: NOTE blank No Setting Once the reminder function is turned on, only this cycle reminder can be cleared. This function is only available for some models. Maximum power limited under the mode is lower than that of mode.

  • Page 20: Sleep Function

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit Sleep 3 the sleep curve setting under Sleep mode according to the detected temperature. Press by DIY could be inquired: "Health" and " + " buttons simultaneously again to The user could accord to sleep curve setting method turn off I FEEL function and "...

  • Page 21: Replacement Of Batteries In Remote Controller

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit Replacement of batteries in remote controller reinstall battery remove Cover of battery box Press the back side of remote c ontroller marked with " ", as shown in the fig, and then push out the cover of battery box along the arrow direction.

  • Page 22: Preparations For Installation

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit 3 Preparations for Installation NOTE! This picture is for reference only, please refer to the actual product, the unit of dimension is mm. 3.1 Installation Position Selection (1) The appliance shall not be installed in the laundry. (2) The location should be able to withstand the weight of unit.

  • Page 23: Wiring Requirement

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit 3.2 Wiring Requirement Dimension of power cord. Power Supply Fuse Capacity Min. Power Supply Cord Indoor Units V/Ph/Hz 09K、12K 208/230V~ 60Hz 4xAWG18 18K、20K NOTES! An all-pole disconnection switch having a contact separation of at least 3mm in all poles should be connected in fixed wiring.
  • Page 24 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit Fig 4.1.2 Fig 4.1.3 Insert the M10 expansion bolt into the hole and then knock the nail into the bolt, as shown in fig 4.1.4. NOTE! The length of bolt depends on the installation height of the unit, bolts are field supplied.

  • Page 25: Refrigerant Pipe Connection

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit (6) Remove the washer locating plate and then tighten the nut on it. (7) Remove the paper pattern. Fig 4.1.5 Fi 4 1 5 NOTE! ① Drilling of ceiling opening and installation of air conditioner must be performed by professionals! ②...
  • Page 26 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit (2) It is not allowed to connect the condensate drain pipe into rain pipe to prevent rain water from pouring in and cause property loss or personal injury. (3) Condensate drain pipe should be connected into special drain system for air conditioner.
  • Page 27 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit (8) The installation height of raising pipe for drainage should be lower than B. The gradient from raising pipe towards drainage direction should be at least 1%~2%. If the raising pipe is vertical with the unit, the raising height should be less than C. Fig 4.3.3 model A(inch)

  • Page 28: Panel Installation

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit Fig 4.3.5 4.4 Panel Installation 4.4.1 Notices for Installation (1) Improper decorative panel installation could cause the following problems. Fig 4.4.1 (2) Ensure that it’s clearance-free between decoration panels and ceiling board after installation, if not, please adjust the body position.
  • Page 29 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit Fig 4.4.3 4.4.2 Panel Installation (1) Remove the grille from the panel, and then open the horizontal louver. (2) Aim the screw hole on panel at the corresponding screw hole on main unit. (3) Screw up the screws on corresponding holes and then install the corresponding screw cover.

  • Page 30: Wired Controller Installation

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit 4.5 Wired Controller Installation Wired controller is optional accessory. If wired controller is needed, please contact your local dealer and install the wired controller according to the instruction manual. NOTE! Do perform the commissioning operation before first use, automatic addressing or other settings, please refer to the manual of ODU.
  • Page 31 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit (2) The connection of stranded wire (as shown in fig 5.1.2) Strip about 10mm insulation of the end of stranded wire by stripping and cutting tool. Loosen the wiring screws on terminal board. Insert the wire into the ring tongue terminal and tighten by crimping tool.

  • Page 32: Installation Of Controllers

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit (4) Electric wiring between the indoor and outdoor units Si ngle-phase units(09~.) N(1) green white black (yellow- (blue) (brown) green) Outdoor unit connection (5) Electric wiring of indoor unit side Re move the electric box cover from the electric box sub-assy and then connect the wire. CAUTION! Tighten the power cord respectively on the terminal boards with screws.

  • Page 33: Routine Maintenance

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit 6 Routine Maintenance 6. Maintenance before the Seasonal Use (1) Check if the air inlet and air outlet of indoor and outdoor unit are blocked. (2) Check if securely grounded. (3) Check if all power cords are securely connected. (4) Check if any error code displayed after energized.

  • Page 34: Trial Operation And Testing

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit Trial Operation and Testing  The meaning of error codes as shown below: Number Error code Error Compressor high pressure protection Indoor anti-freeze protection Compressor low pressure protection, refrigerant lack protection and refrigerant colleting mode Compressor high discharge temperature protection AC over-current protection Communication error...

  • Page 35: Troubleshooting

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit 8 Troubleshooting If your air-conditioning unit suffers from abnormal operation or failure, please first check the following points before repair: Failure Possible Reasons The power supply is not connected. Electrical leakage of air-conditioning unit causes tripping of the leakage The unit cannot be started.

  • Page 36: Specialist's Manual

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit 9 Specialist’s Manual Aptitude requirement for maintenance If any hot work is to be conducted on the refriger- man(repairs s hould be done only be ating equipment or any associated parts, appro- priate fire extinguishing equipment shall be avail- specialists).
  • Page 37 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit resistant to being corroded or are suitably protect- most refrigerants but the use of detergents con- ed against being so corroded. taining chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the Checks to electrical devices copper pipe-work.

  • Page 38: Charging Procedures

    Multi Variable Air Conditioners One-way Cassette Type Indoor Unit Charging procedures Do not overfill cylinders. (No more than 80% volume liquid charge). In addition to conventional charging procedures, Do not exceed the maximum working pressure the following requirements shall be followed. of the cylinder, even temporarily.
  • Page 39 Multi Variable Air Conditioners One-way Cassette Type Indoor Unit to an acceptable level to make certain that flam- mable refrigerant does not remain within the lubricant. The compressor body shall not be heated by an open flame or other ignition sources to accelerate this process.
  • Page 40 GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai, Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: global@cn.gree.com Web: www.gree.com 600005068097 CAT No. 09182024...
