EHA-FTX/FRX
HD-SDI to Fiber Converter
User's Manual
Copyright © EverFocus Electronics Corp,
Release: Nov. 2010
Please read this manual first for correct installation and operation. This manual should be
retained for future reference. The information in this manual was current when published. The
manufacturer reserves the right to revise and improve its products. All specifications are
therefore subject to change without notice.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EverFocus EHA-FTX
Summary of Contents for EverFocus EHA-FTX
- Page 1 EHA-FTX/FRX HD-SDI to Fiber Converter User’s Manual Copyright © EverFocus Electronics Corp, Release: Nov. 2010 Please read this manual first for correct installation and operation. This manual should be retained for future reference. The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products.
- Page 2 Touching a wet power cord with hands or touching the power cord with wet hands may result in electric shock. Never install the EHA-FTX/FRX in areas exposed to water, oil or gas. Water, oil or gas may result in equipment failure, electric shock or, in extreme cases, fire.
- Page 3 EHA-FTX 1. INTRODUCTION The EHA-FTX / FRX are a pair of converters for transporting high definition digital video in HD-SDI standards over fiber optics. The EHA-FTX modulates the HD-SDI video signal to be transmitted over fiber optics, while EHA-FRX offloads the video signal at the receiving end and converts it back to HD-SDI video compliant with SMPTE 292M, 296M standards, at data rates up to 1.485Gb/s.
-
Page 4: Specifications
1.8 W max. Operation temperature 0~50°C / 32~122°F Relative humidity (20%~80% Humidity) 4. PACKAGE CONTENTS - EHA-FTX / FRX HD-SDI to Fiber Converter - Accessory packet (x1) - Power adaptor (x1) - Printed Installation Guide (x1) 5. OPTIONAL FIBER MODULE... -
Page 5: Front Panel
EHA-FTX 6. FRONT PANEL 1. Fiber Transmitter 7. REAR PANEL 2. Power LED indicator 3. Link LED indicator 4. Power 12VDC 5. SDI Input... - Page 6 EHA-FTX 8. CABLE REQUIREMENTS FOR BNC CONNECTOR 8.1 Cable Types Attenuation at 1 GHz: < 32 dB per 100m (328 feet) Return Loss attenuation: > 20 dB Impedance: 75 Ω The table below gives an orientation for achievable cable distances:...
- Page 7 London: 0845 430 9999 Bandra (East), Mumbai 400 051 Telford: 0845 430 8888 Tel: +91 22 6128-8700 Ihr EverFocus Produkt wurde entwickelt und Your EverFocus product is designed and hergestellt mit qualitativ hochwertigen manufactured with high quality materials and Materialien und Komponenten, die recycelt und components which can be recycled and reused.
