- Page 1 EMX32 16-Channel IP Decoder Quick Installation Guide Copyright © EverFocus Electronics Corp, Release Date: July, 2014 Notice: This content is subject to be changed without notice.
-
Page 2: System Requirements
(1080P) or standard definition (720P) video streams, and display those streams in up to four division screens on a monitor. The EMX32 IP Decoder can display its views on HD monitors or televisions. -
Page 3: Packing List
Note: 1. Equipment configurations and supplied accessories vary by country. Please consult your local EverFocus office or agents for more information. Please also keep the shipping carton for possible future use. 2. Contact the shipper if any items appear to have been damaged in the shipping process. -
Page 4: Optional Accessories
EMX32 Optional Accessories • EKB200 (USB controller keyboard: connect to the PC or the IP decoder to control the PTZ cameras connected to the IP decoder). • EKB500 (RS-485 keyboard: connect to the RS-485 port to control OSD or the PTZ cameras connected to the IP decoder). -
Page 5: Rear Panel
EKB200 keyboard. Power Switch Press to turn On / Off the IP decoder. Connects to the RS-485 device, such as EverFocus’ EKB-500 RS-485 Port keyboard. Please refer to 2.3.4 RS-485 Port. Connects to the power using the supplied Power Adaptor and Power Port Power Cord. -
Page 6: Installation
EMX32 Installation You can simply place the IP decoder, EMX32, on the desk or install it behind a VESA monitor. (VESA Mount Bracket: 50mmx 50mm / 75mm x 75mm / 100mm x 100mm / 200mm x 200 mm). EMX32 VESA Mount Bracket Unit: mm 2.1 VESA Monitor Mount... - Page 7 EMX32 2. You just need to use two Washer Head Screws to fix the EMX32 onto the back of the monitor, and the front panel of the EMX32 has to be facing UPWARD. Note: VESA mount (50x50 / 75x75 / 100x100 mm): Use the Washer Head Sliver Screws.
-
Page 8: Basic Connection
EMX32 2.2 Basic Connection The instructions below describe the basic connection for EMX32. Network Power Mouse or EKB200 supply Keyboard Main Monitor Main Monitor (VGA) (HDMI) Web Remote Client ONVIF/RTSP Analog Camera IP Camera 1. To view videos, connect a monitor to the HDMI or VGA port using the HDMI or VGA cable supplied by the monitor manufacturer. -
Page 9: Accessing The Ip Decoder
3. Accessing the IP decoder You can look up the IP address and access the Web interface of the IP decoder using the IP Utility (IPU) program, which is contained in the CD. It can also be downloaded from EverFocus’ Website: http://www.everfocus.com/HQ/Support/DownloadCenter_p1.aspx. Please connect the IP decoder in the same LAN of your computer. - Page 10 11111111. 5. When first connecting to the IP decoder’s IP address, the following dialog may appear. Please check the “Always trust content from this publisher” box and click the Run button to run the EverFocus Viewer application.
- Page 11 EMX32 6. You might be required to download ActiveX and JAVA software for viewing the camera feed. If asked, click Yes. For more details, please refer to 5. Install JAVA Runtime and 6. Browser Security Setting. 7. You may need to turn User Account Control off if you still can’t see the Remote Live View, please see the step below.
-
Page 12: Installing Java Runtime
EMX32 4. Installing JAVA Runtime You need to install the latest JAVA software for stable operation. 1. When first connecting to the IP decoder’s IP address, the following dialog will show up if you didn’t install the JAVA software or its latest version on your computer. - Page 13 EMX32 6. Scroll to “Check for certificate revocation using”, and select the Online Certificate Status Protocol (OCSP). Also, check Place JAVA icon in system tray in “Miscellaneous” option. 7. Scroll to “Default JAVA for Browser” and check Mozilla family. 8. Connect the IP decoder’s IP address again and the yellow bar may pop up on the top of...
-
Page 14: Browser Security Setting
EMX32 5. Browser Security Setting 5.1 Installing ActiveX Controls Follow the steps below to install the ActiveX Controls when you first connect to the IP decoder’s IP address. If you do not see the images below, your security settings may be too high. - Page 15 EMX32 5.2 Enabling Active Controls Note this section is only necessary if you DO NOT see the image in step 1 of the 5.1 Installing ActiveX Controls popping up when you first connect to the IP decoder. 1. At the top of the Internet Explorer Window, click on Tools and then select Internet Options.
- Page 16 EMX32 3. In the Security Settings window, scroll to “ActiveX controls and plug-ins”. Set the controls as follows: “Enable”: Allow previously unused ActiveX controls to run without prompt (Internet Explorer 7 only) Allow scriptlets (IE7 only) Automatic prompting for ActiveX controls ...
- Page 17 EMX32 6. Click the Refresh button to reload the page. 7. You may need to run the EverFocusViewer application when prompted to do so. 8. The login page will show up. Type in the user name and password and click Login to...
- Page 18 TEL: +91 22 6128 8700 FAX: +91 22 6128 8705 www.everfocus.in sales@everfocus.in Ihr EverFocus Produkt wurde entwickelt Your EverFocus product is designed and und hergestellt mit qualitativ manufactured with high quality materials hochwertigen Materialien und and components which can be recycled Komponenten, die recycelt und wieder and reused.
