Summary of Contents for AVer CP10 G2

  • Page 1 CP10 Collaboration Controller — — User Manual...
  • Page 2 Federal Communications Commission Statement NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radiofrequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 3 © 2024 AVer Information Inc. All rights reserved. | October 16, 2024 All rights of this object belong to AVer Information Inc. Reproduced or transmitted in any form or by any means without the prior written permission of AVer Information Inc. is prohibited. All information or...
  • Page 4 お客様サポートセンター（固定電話のみ）: +81 (0) 120 008 382 Vietnam Branch Office Korea Office 한국 에버 인포메이션 (주) Công ty TNHH AVer Information (Việt Nam) Tầng 5, 596 Nguyễn Đình Chiểu, 서울시 종로구 새문안로 92 (신문로 1 가, 광화문오피시아빌딩) 1831, 1832 호 P.3, Quận 3, Tel: +82 (0) 2 722 8535 Thành phố...

  • Page 5: Table Of Contents

    Contents Overview ..........................1 Package Contents ....................... 1 Optional Accessories ......................1 Parts Info ..........................2 LED Indicators ........................3 Ethernet Cable Holder Installation ..................3 Connection ......................... 4 Get Started ......................... 6 Basic Gestures ........................6 Home Page ......................... 7 Zoom Rooms Controller ......................

  • Page 6: Overview

    Overview Package Contents Power Adapter & Ethernet Cable Holder CP10 G2 Power Cord* *The power cord will vary depending on the standard power outlet of the country where it is sold. Optional Accessories 1-Port PoE+ Injector Wall Mount Bracket* * Use three M3 (L: 20mm) screws (not included).

  • Page 7: Parts Info

    Parts Info Top View 1. 10.1-inch Touch Screen 2. Microphone 3. Status LED (left & right) Bottom View 4. Speaker 5. Rubber Feet 6. Bracket for Ethernet Cable Holder* Back View 7. Kensington Lock 8. USB 2.0 Type A Port (for diagnostics) 9.

  • Page 8: Led Indicators

    LED Indicators Color Status  Start-up Solid red  Room occupied  MIC muted in the meeting.  Meeting in progress. Solid green  Room available Meeting is over. Ethernet Cable Holder Installation You may optionally install the Ethernet cable holder to prevent the Ethernet cable from loosening. Pinch the holder and then push it down into Thread the Ethernet cable through the the bracket.

  • Page 9: Connection

    Connection  Basic Connections Port Function DC 12V Connect your device to the power outlet with the power adapter.  Connect your device to with the Ethernet cable for Internet connection. PoE+  Power up your device using the PoE+ injector (optional accessory) and the Ethernet cable to power up your device.
  • Page 10  Zoom Rooms Controller Connection Your CP10 G2 comes with the Zoom Rooms Controller app pre-installed. Pair it with a Zoom Rooms-enabled Android Bar (for example, AVer VB370A) to control and configure settings during Zoom Rooms meetings. 1. Connect your CP10 G2 and the Android Bar to the power outlet to power up.

  • Page 11: Get Started

    Get Started Basic Gestures  Tap: To open an app or make a selection.  Swipe right: Swipe right from the left edge of the screen to return to the home page.  Scroll up and down: To browse the page.

  • Page 12: Home Page

    Home Page 1. App List View pre-installed Zoom Rooms Controller app. Tap the star icon to enable auto-start. 2. Date and Time View current date and time. Tip: To change date and time, go to Setting Page > System > Time Zone to select a time zone based on your location.

  • Page 13: Zoom Rooms Controller

    1. Open Zoom Rooms Controller app on your CP10 G2 > select Zoom Rooms Controller > tap Next. 2. Enter the pairing code on CP10 G2. Check your pairing code on the HDMI screen or your computer. HDMI Screen CP10 G2 3.
  • Page 14 4. Tap the Sign In button on CP10 G2 to sign in with your Zoom Rooms email account or the activation code to start a Zoom Rooms meeting. Note:  If you don’t have a Zoom Rooms account, go to Zoom official website to sign up an account.

  • Page 15: Setting Page

    Tap to check Zoom Rooms Controller app software version or update to Software Update the latest version. Firmware Update Tap to check firmware version or update CP10 G2 firmware. Network Configure CP10 G2 network settings. System Configure CP10 G2 system settings.

  • Page 16: Network

    Network Name Function Hostname Check or edit device hostname. Tap to switch between Static IP and DHCP. RJ45 If you select Static IP, manually enter the IP Address, Gateway, Netmask, and DNS.

  • Page 17: System

    System Name Function Your CP10 G2 is built-in with Android OS. Select a system language. Android System Language Swipe right and left on the letter options for more languages. Android System Country Select a country based on your location. Sleep Timer Set up a dwell time for CP10 G2 to enter sleep mode.
  • Page 18 Time Format Select a time format. Time Correction Mode Select Manual to configure time and date manually. NTP Server Tap the pencil icon to edit NTP Server website. Tap to confirm the current NTP server, then select a time zone based Time Zone on your location.
