- Page 1 Operation manual Daikin Altherma 4 H F+W EPVX10S(U)18A▲4V▼ EPVX10S(U)23A▲4V▼ EPVX10S18A▲9W▼ EPVX10S23A▲9W▼ EPVX14S(U)18A▲4V▼ EPVX14S(U)23A▲4V▼ EPVX14S18A▲9W▼ EPVX14S23A▲9W▼ EPBX10A▲4V▼ EPBX10A▲9W▼ EPBX14A▲4V▼ EPBX14A▲9W▼ Operation manual English ▲= 1, 2, 3, …, 9, A, B, C, …, Z Daikin Altherma 4 H F+W ▼= , , 1, 2, 3, …, 9...
-
Page 2: Table Of Contents
▪ Detailed step-by-step instructions and background information 5.4.1 To turn ON or OFF............10 for basic and advanced usage Reading out information ............10 ▪ Format: Digital files on https://www.daikin.eu. Use the search Space heating/cooling control ........... 10 function to find your model. 5.6.1 Setting the space operation mode ...... -
Page 3: User Safety Instructions
8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction EPVX10+14S(U)18+23A + EPBX10~14A Operation manual Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 4: Instructions For Safe Operation
Reason: Refrigerant might leak into the water circuit, and subsequently into the room when you purge air from the heat emitters or collectors. Operation manual EPVX10+14S(U)18+23A + EPBX10~14A Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 5: About The System
– if enabled– can still activate. However, for external room thermostat control, the protection is only active in case of a thermostat request. EPVX10+14S(U)18+23A + EPBX10~14A Operation manual Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 6: Domestic Hot Water
Tapping the touchscreen turns the backlight back on. 1 Go to [4.5]: Tank > Reheat setpoint. Touch gestures Interaction with the touchscreen display can be done with the following gestures: Operation manual EPVX10+14S(U)18+23A + EPBX10~14A Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 7: Menu Structure: Overview User Settings
[1.34] Heating target baseline [4.25] Reheat schedule [1.35] Cooling target baseline [5] Settings [1.36] Leaving water shift heating mode [5.3] Time/date [1.37] Leaving water shift cooling mode [5.4] Breadcrumbs (on/off) EPVX10+14S(U)18+23A + EPBX10~14A Operation manual Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 8: Possible Screens: Overview
The home screen gives an overview of the unit configuration and the room and setpoint temperatures. Only symbols applicable for your configuration are visible on the home screen. Operation manual EPVX10+14S(U)18+23A + EPBX10~14A Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 9: Main Menu Screen
For setting the most important initial settings. [12] Touchscreen options and testing. Touch [13] Restriction: Only for the installer. Field IO Terminal pin mapping for certain functions. EPVX10+14S(U)18+23A + EPBX10~14A Operation manual Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 10: Setpoint Screen
It is recommended to set disinfection mode to once a day (setting [4.10] Disinfection > Every day). ▪ there is only one zone (main zone), ▪ and the main zone is controlled by an external room thermostat, Operation manual EPVX10+14S(U)18+23A + EPBX10~14A Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 11: To Change The Desired Room Temperature
In case no weather-dependent curve is used, you can adjust the tank temperature setpoint screen to adjust the domestic hot water desired leaving water temperature as follows: temperature. 1 Go to [4.5]: Tank > Reheat setpoint. EPVX10+14S(U)18+23A + EPBX10~14A Operation manual Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 12: Scheduled Mode
When powerful operation is active, the risk of space Example: heating/cooling and capacity shortage comfort problems is significant. In case of frequent domestic hot water operation, frequent and long space heating/cooling interruptions will happen. Operation manual EPVX10+14S(U)18+23A + EPBX10~14A Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 13: Using Dhw Manual Tank Heat-Up
00:00 choose between the setpoints Eco and Comfort ). Activate 7 Confirm with the button. 8 Add more time blocks if needed. 3 Confirm with the button. EPVX10+14S(U)18+23A + EPBX10~14A Operation manual Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 14: Weather-Dependent Curve
3 Rename the schedule using the on-screen keyboard. ▪ Main zone - Cooling 4 Confirm with the button. ▪ Additional zone - Heating ▪ Additional zone - Cooling Operation manual EPVX10+14S(U)18+23A + EPBX10~14A Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 15: Using Weather-Dependent Curves
Each saved degree can save up to 6% of heating/cooling costs. ▪ Do NOT increase/decrease the desired room temperature to speed up space heating/cooling. The space will NOT heat up/cool down faster. EPVX10+14S(U)18+23A + EPBX10~14A Operation manual Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 16: Maintenance And Service
Increase the desired leaving Any repair and service work that would relate to refrigerant needs to cannot be reached. water temperature in accordance be done by a Daikin certified technician. with the heat emitter type. See "5.6.3 To change the desired WARNING temperature" [ 4 11]. -
Page 17: Symptom: The Water At The Tap Is Too Cold
LWT = Leaving water temperature Heat pump is damaged. "8.1 To display the help text Water temperature at the water outlet of the unit. malfunction" [ 4 16]. in case of a EPVX10+14S(U)18+23A + EPBX10~14A Operation manual Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... -
Page 18: Installer Settings: Tables To Be Filled In By Installer
Main zone Ext thermostat type [1.13] Additional zone (if applicable) Ext thermostat type [2.13] Domestic hot water Comfort setpoint [4.21] Eco setpoint [4.22] Information Dealer information [6.2] Operation manual EPVX10+14S(U)18+23A + EPBX10~14A Daikin Altherma 4 H F+W 4P773378-1 – 2024.11... - Page 20 4P773378-1 0000000X 4P773378-1 2024.11...
