Miniatures 2-Window Shop Kit Step By Step Assembly Instructions

#9993 2-Window Shop Kit
Step-by-step assembly instructions
Copyright miniatures.com 2013, 2024
PARTS LIST:
Front Wall.
Left Side Wall
Right Side Wall.
Back Wall
Base
Grooved Trim for top (4)
Plexiglass for top
Top Facade
Plexiglass for large windows (2).
SUPPLIES NEEDED:
Masking tape
White glue (such as #1249 Weldbond)
Damp clean cloth
Exterior and interior finishes
Assembly Instructions
1. Follow the assembly exploded diagram looking at each
piece from the outside. Use the Base as a guide to place
shop on during assembly but do not glue in place at
this time.
2. Glue the right side of Left Side Wall (trim at top on the out-
side with notch to the front) into the groove on the back of
the left side of Front Wall. Be sure bottom and top edges
of walls are flush and notch of Left Side Wall fits over trim
on Front Wall. Secure with masking tape. Allow to dry.
3. Glue the left side of Right Side Wall (trim at top on the out-
side with notch to the front) into the groove on the back of
the right side of Front Wall. Be sure bottom and top edges
of walls are flush and notch of Right Side Wall fits over trim
on Front Wall. Secure with masking tape. Allow to dry.
4. Glue the left side of Left Side Wall and the right side of
Right Side Wall into grooves and corner trims on the Back
Wall. Flush at the bottom with the corner trims and trims
extending above the walls at the top. Secure with masking
tape. Allow to dry.
5. The completed assembly can be secured in place on the
Base with masking tape to keep it square during drying.
2388 Pleasantdale Road, Atlanta, GA 30340 • 1.800.926.6464 • www.miniatures.com • Made in Thailand
GENERAL INSTRUCTIONS
• Identify and inspect all parts using the Parts List and Parts Diagram.
• Thoroughly read the directions before starting.
• Set up a dedicated work area to avoid the need to unpack,
repack, or move the project frequently.
• Use a clean, level, and dry work surface protected from glue spills.
• Dry fit the parts using masking tape to ensure everything aligns
correctly before permanent assembly.
Tips:
•
Remove paper from plexiglass before installing in the
front windows.
•
Remember, it is easier to work on the individual walls
on your work table before assembling the shop.
•
Suggested Finishing Techniques BEFORE Construction:
•
Stain or Paint walls, facade and trims before assem-
bling the store.
•
Apply any outside finish, such as: Brick or Clapboard.
•
Decide how you are going to finish the inside of the
store ; the walls, are going to electrify the store, hard
wire or tape wire?
•
Fit and match wallpaper, wainscoting, paneling, etc.
to inside of walls and apply.
•
The plexiglass included for the front windows can
be used clear or made into "stained glass" windows.
(See "stained glass" windows in "Everything You
Wanted To Know About Dollhouses But Didn't Know
Who To Ask" instruction book.) Glue the plexiglass
into the windows. Be careful to only put glue on the
edges. "Stained glass" windows should be finished
before gluing in place.
•
Fit any window treatments and secure in place.
•
Glue hardware on door.
•
If Framed Plexiglass Top is not assembled, fit the
four pieces of grooved trim around large piece of
plexiglass and glue at joints. Do not get glue on vis-
ible area of plexiglass. Secure with masking tape
and allow to dry.
WARNING:
Not Suitable for Children
under 15 years old.
CHOKING HAZARD — Small parts
0824
