Miniatures Basic Room Box Kit Step By Step Assembly Instructions

#9053 Basic Room Box Kit
Step-by-step assembly instructions
Copyright miniatures.com 2015, 2024
PARTS LIST:
Floor/ceiling panels (2)
Back panel, with window opening
Side panel, with door opening
Side panel, no openings
Trim pieces, 2 ea. shorter for sides,
2 ea. longer for top and bottom
SUPPLIES NEEDED:
Masking tape
White glue (such as #1249 Weldbond)
Smooth, flat work surface, protected
from glue
Assembly Instructions
1. Start with the back wall and a floor/ceiling piece. Stand
the pieces on edge so that the long joint is vertical (Fig 1).
Apply tape across the joint with the back piece outside,
over the edge of the floor/ceiling piece and flush along
the edge. Tape the next joint like the first, back piece
outside over the edge of the floor/ceiling piece.
2. From the inside of the box, open the taped joints and
apply glue along the length. Fold the joints closed again
and add tape if necessary to correct any warping. Wipe
away any excess glue.
2388 Pleasantdale Road, Atlanta, GA 30340 • 1.800.926.6464 • www.miniatures.com
Fig. 1
GENERAL INSTRUCTIONS
• Identify and inspect all parts using the Parts List.
• Thoroughly read the directions before starting.
• Set up a dedicated work area to avoid the need to unpack,
repack, or move the project frequently.
• Use a clean, level, and dry work surface protected from glue spills.
• Dry fit the parts using masking tape to ensure everything aligns
correctly before permanent assembly.
Tips:
•
The kit is made of 3.6 mm luan plywood, and is sturdy
and lightweight when assembled. The thin panels may
sometimes seem slightly warped when the package is
opened, but that is easily corrected during assembly
and will not affect the completed kit.
•
100 grit sandpaper will help smooth edges and
reduce splintering, but finer grades (220 or above)
are needed for a smoother surface. Be careful not to
round off the panel edges before assembly. Use wood
filler for any voids in the panel surfaces. For finishing,
high quality semi-gloss paint is recommended.
•
The die-cut window and door openings do not have
to be used; the cutout pieces may be left in place and
concealed by finishing materials (wallpaper, etc.).
The cutting grooves may be filled in with wood putty
for better appearance, if needed. Either side of the
panels may be used, to allow alternate placement
of the door and window openings.
•
Punch out the openings you want to use and check
that your window and door units will fit properly.
Adjust openings as necessary, allowing for thickness
of floor at door opening.
WARNING:
Not Suitable for Children
under 15 years old.
CHOKING HAZARD — Small parts
0824
