- Page 1 Operating Instructions Hot Runner Controller and TEMPSoft2 Rev. 1.00.04 01/2020 Translation of original operating instructions...
-
Page 3: Table Of Contents
Meusburger Deutschland GmbH Operating Instructions profiTEMP with TEMPSoft2 1 Introduction 1.1 Typographical Conventions 1.2 Additional and continuative documents 2 Applications 3 Security References 3.1 Security References for User 3.1.1 Intended use 3.1.2 Maintenance 3.2 Warranty Conditions 3.3 Transport and Storage 3.3.1 Transport... -
Page 4: Introduction
Chapter 1 Introduction Introduction These operating instructions describe the interaction of hot runner controller profiTEMP and TEMPSoft2 software. Further information on TEMPSoft2 software, configuration and adjustment over parameters of the hot runner con- troller, etc., can be found in the specific operating manuals. 1.1 Typographical Conventions Symbols and conventions are used in this document for faster orientation for you. -
Page 5: Additional And Continuative Documents
Information on this topic are in the protocol description Modbus/TCP and the corresponding object lists. Modbus/TCP Protocol Information on this topic are in the protocol description CANopen and the cor- responding object lists. CANopen Data sheets and op- Available by Internet see www.meusburger.com erating manuals Rev. 1.00.04 Technical changes reserved... -
Page 6: Applications
Chapter 2 Applications Applications The hot runner controller profiTEMP controls hot runner nozzles as well as manifolds for particular plastics in an optimal adapted temperature range. profiTEMP has a uniform and clear build- and operating concept from the smallest desktop with 6 zones up to the biggest tower with 250 zones. -
Page 7: Security References
Meusburger Deutschland GmbH Operating instructions profiTEMP with TEMPSoft2 Security References Before installation, handling or operation of the device, please read through this operating in- structions completely and carefully. 3.1 Security References for User All persons, responsible for the mounting/start-up/operation/maintenance/servicing of the device, have to ... -
Page 8: Intended Use
Chapter 3 Security References Maintenance and repair work may be carried out by authorized persons only. Only skilled and on the risks trained persons may use the device. The relevant accidental regulations as well as other general approved safety-rele- vant, occupational-medical norms have to be obeyed. Unauthorized modifications of the device exclude liability of the manufacturer for resultant damages. -
Page 9: Transport And Storage
Meusburger Deutschland GmbH Operating instructions profiTEMP with TEMPSoft2 3.3 Transport and Storage 3.3.1 Transport The hot runner controller is packed fully-mounted in a robust carton, cushioned with foamed material. This assures sufficient protection in normal case. To avoid damage, the hot runner controllers must be transported STANDING. -
Page 10: Setup Profitemp With Tempsoft2
Chapter 4 Setup profiTEMP with TEMPSoft2 Setup profiTEMP with TEMPSoft2 Before installation, handling or operation of the device, please read through this operating in- structions completely and carefully. 4.1 Scope of supply 1 Hot Runner Controller profiTEMP *** Dt Desktop with mounted TEMP-Touch XPC15 V and/or profiTEMP *** De Desktop with external TEMP-Touch XPC15 V and/or profiTEMP *** Tt... -
Page 11: Installation
Meusburger Deutschland GmbH Operating instructions profiTEMP with TEMPSoft2 Installation 5.1 Installation References Unpacking The device is packed fully-mounted in a robust carton. Check the packaging and then the device for identifiable damage incurred during transit. If damage is identified, then please get in touch with the transportation company. -
Page 12: Sensor Inputs And Power Outputs (Plug Xa)
Chapter 5 Installation 5.2.3 Sensor inputs and power outputs (Plug XA) Connect the thermocouples TC of type J, L, K to the sensor inputs and heaters to the control outputs of the con- nection of hot runner mold. Consider terminal assignment (see specifications). Output power Max. -
Page 13: Digital In- / - Outputs
Meusburger Deutschland GmbH Operating instructions profiTEMP with TEMPSoft2 5.2.5 Digital in- / - outputs Digital input (24 VDC), digital output (24 VDC / 500 mA) 4 Digital In- /3 Digital Outputs D-SUB, socket Function and/or signal Digital input 1 Digital input 3... -
Page 14: Interfaces
Chapter 5 Installation 5.2.6 Interfaces Serial interface COM RS485 D-SUB, socket Function and/or signal RS422 RS422 n.a. RS422 RS422 n.a. RS422 Interface CANopen D-SUB, plug Function and/or signal n.a. CAN-L CAN 2 CAN 1 n.a. n.a. n.a. n.a. CAN-H CAN 2 CAN 1 n.a. - Page 15 Meusburger Deutschland GmbH Operating instructions profiTEMP with TEMPSoft2 Interface Ethernet RJ45 RJ45, Socket Interface USB Rev. 1.00.04 Technical changes reserved...
-
Page 16: Immediately After The Switch-On With Existing Display Unit Pt-Du
Chapter 6 Immediately after the switch-on with existing Display Unit pT-DU Immediately after the switch-on with existing Display Unit pT-DU Is profiTEMP equipped with a Display Unit pT-DU (LED and LCD display), immediately after switch ON, all seg- ments of the LED display are light. That identifies that all LED displays are intact. In the LCD display is the logo shown. -
Page 17: Connection Profitemp / Temp-Touch Xpc15
Meusburger Deutschland GmbH Operating instructions profiTEMP with TEMPSoft2 Connection profiTEMP / TEMP-Touch XPC15 V Lower side TEMP-Touch XPC15 V Ethernet connection internal profiTEMP *** Tower - Connection between Ethernet RJ45 on Display Unit pT-CU and Switch; Connection be- tween Switch and on TEMP-Touch XPC15 V. -
Page 18: Appendix
Chapter 8 Appendix Appendix 8.1 Consumable and Spare Parts Order number Article description Display Unit 025 400-06 pT-DU 06 profiTEMP Display Unit 6 Zones 025 400-12 pT-DU 12 profiTEMP Display Unit 12 Zones 025 400-18 pT-DU 18 profiTEMP Display Unit 18 Zones 025 400-24 pT-DU 24 profiTEMP Display Unit 24 Zones... -
Page 19: Version History
Meusburger Deutschland GmbH Operating instructions profiTEMP with TEMPSoft2 8.2 Version History Version Date Changes 1.00.04 1/31/2014 In detail, the following amendments/corrections were made: Connection pT/Touch D 1.00.03 11/30/2012 In detail, the following amendments/corrections were made: Connections of touch permuted ...
