- Page 1 FA02117-EN ETI XIP CONFIGURATION MANUAL English...
-
Page 2: Table Of Contents
CONTENTS DESCRIPTION AND SYSTEM REQUIREMENTS Description Minimum PC requirements CONFIGURING THE ETI XIP SERVER Accessing the first configuration page MENU Device data Network Connections Ethernet parameters Multimedia parameters Date and time Access control Standard programming Example of access-control application Installation description... -
Page 3: Description And System Requirements
CONFIGURING THE ETI XIP SERVER Accessing the first configuration page Once your PC has been configured and connected to the ETI XIP device, enter the address http://192.168.1.2 in your browser to access the network interface configuration page The configurator login webpage will show after a few seconds. - Page 4 Diagnosis Interface name IP address Subnet Mask English Copyright © 2024 CAME S.p.A - All rights reserved - VAT ID No. 03481280265 Before starting configuration, you can select the Language icon for your preferred language. User General information General information...
-
Page 5: Menu
MENU Device data In the [Device data] window, view general information about the device. ETI XIP device ID data. ETI XIP device firmware version. User Device data General information Model Device data Name Network Serial number Date and time Firmware version... -
Page 6: Ethernet Parameters
Ethernet parameters Under the [Ethernet parameters] tab, set advanced configuration settings for the Ethernet port parameters, and view information about the communication and Ethernet port statuses. Once you have finished, press [Save]. User Network General information Connections Ethernet parameters Multimedia parameters Device data Network Port 1... -
Page 7: Date And Time
Device data Mode Manual Network Date and time Date and time Time zone Access control Save Reload Video entry system Maintenance Diagnosis Manual March 2024 Manual Copyright © 2024 CAME S.p.A - All rights reserved - VAT ID No. 03481280265 English... -
Page 8: Access Control
Access control Standard programming Under [Access Control] in the [Routine Programming] tab, program access to one or more passages for a group of users. The [User management] icon allows you to: - search for a user; - create a new user; - show a list of all created users. - Page 9 From [Add user], select the users to associate with the group. User Access control General information Standard programming Device data Network User management Date and time Group name Access control Group name Users Weekly programming Passages Video entry system Add user Add time slot Add passage Maintenance...
- Page 10 From [Add time slot], set a weekly time interval. User Access control General information Standard programming Device data Network User management Date and time Group name Access control CLEANING COMPANY Passages Users Weekly programming Video entry system Add passage Cleaning operator 1 Add time slot Maintenance Cleaning operator 2...
- Page 11 Under [Non-standard programming], add non-standard programming (e.g. public holidays or company closures). User Access control General information Standard programming Device data Network User management Date and time Group name Access control CLEANING COMPANY Passages Weekly programming Video entry system Users From: Add passage Cleaning operator 1...
- Page 12 Select one or more passages to give the user group access to. Once you have finished, press [Save]. User Access control General information Standard programming Device data Network User management Date and time Group name CLEANING COMPANY Access control Users Weekly programming Video entry system Passages...
-
Page 13: Example Of Access-Control Application
Example of access-control application Installation description You need to program access control for the complex shown in the figure below, consisting of two office buildings and an enclosed car park divided by pedestrian entrances. The access-control devices positioned at each passage are shown in red. ENTRANCE EAST ENTRANCE... -
Page 14: Programming
Programming After creating and programming the system using PCS/XIP software, inserting entry panels with RFID readers and internal receives as shown in the image, the next step is to program access control. For this example, start by creating all users who will be able to access the buildings. To assign a badge to a user, position the cursor in the [Badge code] field ;... - Page 15 Next, create groups containing different categories of users. User Access control General information Standard programming Device data Network User management Date and time Group name Users Weekly programming No group found Access control Video entry system Reload Add group Maintenance Diagnosis The client’s first request is to allow pedestrian access to the buildings for all employees, but only to the company they work for;...
- Page 16 The client’s second request is to allow access from any passage to managers only on any day of the year; to fulfil this request, the following permissions must be created: ALFATECH managers and EURORAC managers. ALFATECH managers User Access control General information Standard programming Device data...
- Page 17 The client’s third request is to allow service personnel access only after office hours without passing through the EAST and WEST entrances; to fulfil this request, the following permissions must be created: CLEANING COMPANY. Cleaning company User Access control General information Standard programming Device data Network...
-
Page 18: Video-Entry System
In a system with several ETI-XIP gateways, the ETI XIP must be the master and will be the first to be programmed. Device mode Under [Video entry system] in the [Device mode] tab, choose a communication port through which slaves will communicate with the ETI XIP Master (permitted range: 20050-20166). Unless otherwise indicated, set to 20050. -
Page 19: Passages And Video Cameras
Save Reload Diagnosis Once all slaves in the system have been added, one of them (the one with the [Backup] box flagged) can be set to back up the ETI XIP master continuously. Assign a port (20050 to 20166). If the ETI XIP master fails, it will be replaced by the ETI-XIP slave with backup flagged, and the remaining slaves will communicate with it via the assigned port. -
Page 20: Maintenance
Maintenance Firmware Under [Maintenance] in the [Firmware] tab, view and update the installed firmware version. Firmware version installed. Press [Select file] to select the firmware update file saved on your PC and proceed with the update. User Maintenance General information Firmware Restore device System configuration... -
Page 21: System Configuration
System configuration Under [Maintenance] in the [System configuration] tab, import and export the system configuration backup file. User Maintenance General information Firmware Restore device System configuration Device data Network Export system configuration Date and time Access control Video entry system Maintenance Diagnosis Diagnosis... - Page 22 CAME S.p.A. Via Martiri della Libertà, 15 31030 Dosson di Casier Treviso – Italy Tel. (+39) 0422 4940 Fax (+39) 0422 4941 info@came.com - www.came.com...
