Factory Reset the Sensor
A factory reset removes customized programming, returning the
device to its out-of-the-box configuration (Factory Mode) and
removes provisioning, allowing the device to be provisioned as a
new device.
To factory reset a sensor from the Mobile App:
Open communication to configure the Acoustic Ceiling
Sensor.
Next to Factory Reset, tap
continue. The sensor will disconnect from the Mobile App as
it performs the factory reset.
Note: Once the factory reset is complete, if the device is scanned
or identified in Stand-Alone Mode, it will display Factory Mode to
indicate it has not been configured.
View Acoustic Ceiling Sensor Status
The status screen will allow visibility to the sensor's motion/occupancy or no motion/not occupied activity reading.
Bring the mobile device close to the Acoustic Ceiling Sensor
(within 60 feet/18 meters of the device).
Open the WaveLinx LITE Mobile App in Stand-Alone Mode .
Tap Occupancy Status from the screen or the menu. A SCAN
will immediately start.
Note: The WaveLinx PRO IR Remote can also be used to identify
specific sensors. See page 8 for details on using the remote.
Wait for the scan to complete. The closest device will show
the strongest signal indicator. Tap the identify icon
the device to verify that the correct device responds (LEDs
flash magenta and the load cycles ON/OFF for 15 sec).
WaveLinx LITE Quick Start Guide: Configuring Acoustic Ceiling Sensors in Stand-Alone Mode
. When prompted, tap YES to
OR
next to
If the device is not communicating to the WaveLinx LITE Mobile
App, use the onboard reset button to issue the factory reset. This
button is located under the sensor's front coverplate.
To issue a factory reset from the onboard button:
Press the onboard reset button for greater than 5 seconds
and release before 10 seconds.
The sensor LEDs should flash yellow to indicate the sensor
has received the factory reset command.
The screen will display the last status of the motion sensor
along with the current hold time countdown. This display will
not automatically update.
To change to live updates, tap the checkbox next to the
desired sensor(s) or choose Select All. Tap
cause the status/hold time to update approximately every 5
seconds.
Tap STOP to end the status refresh.
LIVE DATA to
