Stream Wireless
O W N E R ' S M A N U A L

Advertisement

loading
Need help?

Need help?

Do you have a question about the JBL QUANTUM STREAM WIRELESS and is the answer not in the manual?

Questions and answers

Related Manuals for Harman JBL QUANTUM STREAM WIRELESS

Summary of Contents for Harman JBL QUANTUM STREAM WIRELESS

  • Page 1 Stream Wireless O W N E R ’ S M A N U A L...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION......................1 WHAT’S IN THE BOX ....................2 PRODUCT OVERVIEW ....................3 Microphone ...............................3 2.4GHz receiver ..............................4 Charging case ..............................5 GETTING STARTED ...................... 6 JBL Headphones app ...........................6 First-time setup on PC (for USB-C version only) ................6 First-time setup on Mac (for USB-C version only) ..............7 How to wear ..............................8 USING YOUR MICROPHONE ..................

  • Page 3: Introduction

    Introduction Congratulations on your purchase! This manual includes information on the JBL Quantum Stream Wireless. We encourage you to take a few minutes to read this manual, which describes the product and includes step-by-step instructions to help you to set up and get started. Read and understand all the safety instructions before using your product.

  • Page 4: What's In The Box

    What’s in the box Microphone 2.4GHz receiver (for USB-C version only) 2.4GHz receiver (for Lightning version only) Charging case Windscreen USB charging cable (USB-A to USB-C) QSG, warranty card and safety sheet - 2 -...

  • Page 5: Product Overview

    Product overview Microphone Windscreen mount LED indicator • Indicates the status of 2.4GHz wireless connection. • Indicates the status of noise cancelling. • Indicates the status of microphone mute/unmute. • Indicates the status of microphone battery. Press button Microphone clip - 3 -...

  • Page 6: 2.4Ghz Receiver

    2.4GHz receiver USB-C port (for USB-C version only) USB-C connector (for USB-C version only) LED indicator • Indicates the status of 2.4GHz wireless connection. • Indicates the status of noise cancelling. • Indicates the status of microphone mute/unmute. Lightning port (for Lightning version only) Lightning connector (for Lightning version only) - 4 -...

  • Page 7: Charging Case

    Charging case Microphone holder 2.4GHz receiver holder LED indicator • Indicates the status of charging case battery. Charging port - 5 -...

  • Page 8: Getting Started

    First-time setup on PC (for USB-C version only) Download from www.jblquantum.com/engine to gain full access to features on your JBL Quantum Stream Wireless, such as microphone gain, EQ settings, and voice quality meter. Software requirements Platform: Windows 10 (64 bit only) / Windows 11...

  • Page 9: First-Time Setup On Mac (For Usb-C Version Only)

    1. Connect the 2.4GHz receiver to your Mac via USB-C connection (See “Power on & connect”). 2. Go to “System Preferences” -> “Sound” -> “Input”. 3. Select “JBL Quantum Stream Wireless” for sound input. JBL Quantum Stream Wireless - 7 -...

  • Page 10: How To Wear

    How to wear Clip the microphone to your desired position to capture sound from all directions. TIP: • Install the windscreen to reduce wind noise while recording. - 8 -...

  • Page 11: Using Your Microphone

    Using your microphone First time use Before first time use, put the microphone into the charging case for activation. Charging • It takes around two hours to fully charge your microphone through the charging case. • As a fast charging feature, a fifteen minute charge powers up your microphone for one hour of use.

  • Page 12: Power On & Connect

    TIPS: • During charging, make sure that the charging pins on the microphone and charging case are aligned and in good contact. • Open the lid to check the battery level of the charging case. See “LED behaviors”. Use the provided USB cable to charge the charging case when necessary.

  • Page 13: Controls

    Manual pairing 1. Short press then hold the button on the microphone for more than 5 seconds until the LED flashes white quickly. 2. Plug the 2.4GHz receiver into your mobile device, PC, or Mac.  The microphone starts to pair with the 2.4GHz receiver.  After successful connection, the LEDs on the microphone and the 2.4GHz receiver turn solid white.
  • Page 14 Tap the button to enable noise cancelling, then slide the slider to adjust the noise cancelling level. Tap the button to select microphone effect. Slide the slider to adjust the LED brightness, or tap the button to turn off the LEDs. - 12 -...

  • Page 15: Charge & Record (For Mobile Device Only)

    Personalize your sound settings in JBL QUANTUMENGINE (For USB-C version only) Download and launch on your PC to personalize your sound settings, such as microphone volume, noise cancelling, microphone effect and LED brightness. Charge & record (for mobile device only) USB TYPE-C Lightning Connect the 2.4GHz receiver with a charging cable to charge your mobile device...

  • Page 16: Power Off

    NOTE: • Lightning to USB-A cable is not included by pack. Power off To power off, put the microphone into the charging case and close the lid. - 14 -...

  • Page 17: Led Behaviors

    LED behaviors LED on microphone: LED indication Status Meaning Flashing white 2.4GHz pairing quickly Solid white 2.4GHz connected (noise cancelling off ) Solid pink 2.4GHz connected (noise cancelling on) Solid red Microphone muted Flashing red slowly Low battery Flashing white slowly Charging Fully charged LED on 2.4GHz receiver: LED indication Status...
  • Page 18 LED on charging case: LED indication Status Meaning LED flashing Low battery white slowly or 3 Charging flashing white slowly All three LEDs are off Fully charged - 16 -...

  • Page 19: Product Specifications

    Product specifications • Model: QUANTUM STREAM WIRELESS • Power supply: 5 V • Type: Condensor microphone • Polar patterns: Omnidirectional • Frequency response: 20 Hz - 20 kHz • Sensitivity: -36 dBV/Pa@1 kHz • Maximum SPL: 100 dB SPL (1 kHz @ 1m) dBu •...

  • Page 20: Troubleshooting

    Increase the microphone gain and noise cancelling to appropriate levels. • Make sure you have chosen JBL Quantum Stream Wireless as the default device in the sound settings of your PC or Mac (for USB-C version only). - 18 -...
  • Page 21 HP_JBL_Quantum Stream Wireless_OM_EN_V1...
