Harman JBL QUANTUM ONE Quick Start Manual

Harman JBL QUANTUM ONE Quick Start Manual

Hide thumbs Also See for JBL QUANTUM ONE:

Advertisement

Quick Links

Download this manual
ONE
Q U I C K S T A R T G U I D E

Advertisement

loading

Related Manuals for Harman JBL QUANTUM ONE

Summary of Contents for Harman JBL QUANTUM ONE

  • Page 1 Q U I C K S T A R T G U I D E...

  • Page 2: Software Requirements

    JBL QuantumENGINE Download JBL QuantumENGINE to gain full access to features on your JBL Quantum headsets - from headset calibration to adjusting 3D audio to suit your hearing, from creating customized RGB lighting effects to determining how the boom microphone side-tone works. JBLquantum.com/engine Software requirements PLATFORM: Windows 7 / Windows 10 (64 bit) only 500MB of free hard drive space for installation...
  • Page 3 WHAT'S IN THE BOX Windshield foam for boom microphone Calibration Detachable Type-C to A cable with QSG | WARRANTY CARD | 3.5MM AUDIO WARNING CARD JBL QUANTUMOne headset CABLE Microphone Boom Microphone Game / Chat Balance Dial...

  • Page 4: System Compatibility

    Requirements SOFTWARE REQUIREMENTS PLATFORM: Windows 7 / Windows 10 (64 bit) only 500MB OF FREE HARD DRIVE SPACE FOR INSTALLATION System compatibility PC | Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR...

  • Page 5: Volume Control

    OVERVIEW ANC / TALKTHRU LED ANC / TALKTHRU button Re-centering button for head tracking Flat-fold ear cup Volume Control RGB Lighting Zones Microphone Mute/unMute power status LED USB-C port 3.5mm Audio Jack Boom Microphone Jack Detachable boom microphone Game audio-chat balance dial power status LED Volume Control MIC MUTE BUTTON...
  • Page 6 Calibration microphone 15-30 sec Go to JBL for detailed setup instructions.
  • Page 7 SETUP Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR PC | Mobile | LAPTOP| Nintendo Switch™ * USB-C to USB-C cable is not included by-pack. Connectivity with USB-C may not work with all models of said devices.
  • Page 8 BUTTON COMMAND ANC on/off TALKTHRU ON/OFF >2 Re-centering button for head tracking INCREASE GAME VOLUME INCREASE CHAT VOLUME INCREASE MASTER VOLUME DECREASE MASTER VOLUME Microphone Mute / unMute >5 ON/OFF...
  • Page 9 First time setup Connect the headset to your PC via USB connection. Go to “Sound Settings” -> “Sound Control Panel”. Under “Playback” highlight “JBL QUANTUMONE GAME” and select “Set Default” -> “Default Device”. Highlight “JBL QUANTUMONE CHAT” and select “Set Default” -> JBL QUANTUMOne JBL QUANTUMOne “Default Communication Device”.
  • Page 10 MICROPHONE MIC MUTE MIC UNMUTE...
  • Page 11 TECH SPEC Driver size: 50 mm Dynamic drivers Frequency response: 20 Hz - 40 kHz Microphone frequency response: 100 Hz -10 kHz Max input power 20 mW Sensitivity: 95 dB @ 1 kHz, 1 mW Maximum SPL: 97 dB Microphone sensitivity: -41 dBV @1 kHz / Pa Impedance: 32 Ohm...
  • Page 12 001 Hvad er der i æsken ØG LYDSTYRKEN FOR SPIL; ØG LYDSTYRKEN FOR CHAT 001 Verpackungsinhalt Mikro stumm/Stummschaltung aufheben; EIN/AUS JBL QUANTUMOne headset; 3,5MM LYDKABEL; Kalibreringsmikrofon; JBL QUANTUMOne Headset; 3,5-MM-AUDIOKABEL; Kalibriermikrofon; GAME-LAUTSTÄRKE ERHÖHEN; CHAT-LAUTSTÄRKE ERHÖHEN 007 IBRUGTAGNING Aftagelig boom-mikrofon; Type-C til A kabel med justeringsskive Abnehmbares Bügelmikrofon;...
  • Page 13 ΑΥΞΗΣΗ ΚΕΝΤΡΙΚΗΣ ΕΝΤΑΣΗΣ ΗΧΟΥ, ΜΕΙΩΣΗ ΚΕΝΤΡΙΚΗΣ 001 Contenido de la caja AUMENTAR EL VOLUMEN MAESTRO; DISMINUIR EL VOLUMEN MAESTRO 001 ΤΙ ΕΙΝΑΙ ΣΤΗ ΣΥΣΚΕΥΑΣΙΑ ΑΚΟΥΣΤΙΚΑ JBL QUANTUMONE, ΚΑΛΩΔΙΟ ΗΧΟΥ 3,5 MM, ΕΝΤΑΣΗΣ ΗΧΟΥ Auriculares JBL QUANTUMOne; CABLE DE AUDIO DE 3,5 MM; Micrófono Silenciar/reactivar el micrófono;...
  • Page 14 001 Pakkauksen sisältö Mikrofonin mykistys/mykistyksen poisto; PÄÄLLÄ/POIS 001 Contenu de la boîte AUGMENTATION VOLUME PRINCIPAL ; DIMINUTION VOLUME PRINCIPAL JBL QUANTUMOne -kuulokkeet; 3,5 MM ÄÄNIKAAPELI; LISÄÄ PELIN ÄÄNENVOIMAKKUUTTA; LISÄÄ CHATIN Casque micro JBL QUANTUMOne ; CÂBLE AUDIO 3,5 MM ; Étalonnage Coupure / activation du microphone ; MARCHE/ARRÊT Kalibrointimikrofoni;...
  • Page 15 001 A doboz tartalma 007 Első beállítás 001 Contenuto della confezione AUMENTA IL VOLUME MASTER; DIMINUISCE IL VOLUME MASTER JBL QUANTUMOne headset; 3,5 MM AUDIO KÁBEL; kalibrációs Csatlakoztasd a fejhallgatót a PC–hez USB–kapcsolaton Cuffie JBL QUANTUMOne; CAVO AUDIO 3.5MM; Microfono per la Microfono Mute / unMute;...
  • Page 16 001 VERPAKKINGSINHOUD Microfoon dempen/dempen opheffen; AAN/UIT 001 Innhold i esken ØK SPILLVOLUM; ØK CHAT-VOLUM JBL QUANTUMOne hoofdtelefoon; 3,5 MM AUDIOKABEL; GAMEVOLUME VERHOGEN; CHATVOLUME VERHOGEN JBL QUANTUMOne hODESETT; 3,5 MM LYDKABEL; 007 Førstegangsoppsett Kalibratiemicrofoon; Afneembare boommicrofoon; Type-C kalibreringsmikrofon; avtagbar boom-mikrofon; Type-C-til-A- 007 Eerste installatie Koble hodesettet til PC-en med USB-forbindelsen.
  • Page 17 PT-BR 001 Zawartość opakowania Przycisk centrowania do śledzenia ruchów głowy 001 Conteúdo da caixa Botão de recentralização para sensor de posição da cabeça Zestaw słuchawek JBL QUANTUMOne; PRZEWÓD AUDIO 3,5 MM; ZWIĘKSZANIE POZIOMU GŁOŚNOŚCI; ZMNIEJSZANIE POZIOMU GŁOŚNOŚCI Headset JBL QUANTUMOne; CABO DE ÁUDIO DE 3,5 mm; Microfone de AUMENTA OU DIMINUI O VOLUME TOTAL Mikrofon z funkcją...
  • Page 18 001 Detta finns i lådan Mikrofon PÅ/AV 001 Kutu içeriği ANA SESİ YÜKSELTİR; ANA SESİ AZALTIR JBL QUANTUMOne-headset; 3,5 MM LJUDKABEL; HÖJA SPELVOLYMEN; HÖJA CHATT-VOLYMEN JBL QUANTUMOne kulaklık; 3.5MM SES KABLOSU; Kalibrasyon Mikrofon Sessiz / Sesi aç; AÇMA/KAPATMA Kalibreringsmikrofon; Löstagbar bommikrofon; Typ-C till Mikrofon;...
  • Page 19 ZH-CN 001 产品清单 007 首次设置 001 Комплект поставки 006 ФУНКЦИИ КНОПОК JBL QUANTUMOne 耳机； 3.5mm 音频线； 校准麦克风； 可拆 通过USB连接将耳机连接到您的PC。 Вкл./выкл. активного ШУМОПОДАВЛЕНИЯ (ANC); вкл./выкл. Гарнитура JBL QUANTUMOne; АУДИОКАБЕЛЬ НА 3,5 ММ; 卸吊杆式麦克风； Type-C 转 A 口线， 带有游戏/对讲 打开 “Sound Settings （ 声音设置） ” -> “Sound Control функции...
  • Page 20 ZH-TW 001 包裝盒內物品 增大遊戲音量 ； 增大聊天音量 001 ISI KOTAK 006 TOMBOL PERINTAH JBL QUANTUMOne 耳機 ； 3.5MM 音訊纜線 ； 校準麥克風 ； 可 007 首次設定 Headset JBL QUANTUMOne; KABEL AUDIO 3,5 MM; Mikrofon Kalibrasi; ANC aktif/nonaktif; TALKTHRU AKTIF/NONAKTIF 拆分懸吊式麥克風 ； 帶遊戲/聊天平衡旋鈕的 C 型 透過...
  • Page 21 001 同梱品 007 初期設定 001 구성품 게임 볼륨 증가, 채팅 볼륨 증가 USB接続を通してヘッ ドセッ ト本体をPCに接続して JBL QUANTUMOne 헤드셋, 3.5mm 오디오 케이블, 마이크 007 초기 설정 JBL QUANTUMOneイヤホン本体; 3.5MMオーディオケーブル;調 整用マイク;着脱可能ブームマイク;ゲーム用Type-C-Aケー ください。 보정, 탈착식 붐 마이크, Type-C~A 케이블 - 게임/챗 USB 연결을 통해 헤드셋을 PC에 연결합니다. ブル/チャッ...
  • Page 22 ; " 3.5 ;JBL QUANTUMOne QUANTUMOne USB-C .USB Sound <- ( ) Sound Settings ) Control Panel .USB , JBL QUANTUMONE GAME ) Playback - Sound Control” <- ( ) “Sound Settings” <- ( ) Set Default ) “Panel Windows : ) Default Device Windows 7/Windows 10 (64 Set”...
  • Page 23 Китай Импортер в Россию: OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, г.Москва, ул. Двинцев, д.12, к 1 Гарантийный период: 1 год Информация о сервисных центрах: www.harman.com/ru тел. +7-800-700-0467 Срок службы: 2 года Товар сертифицирован Дата производства: Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы символов серийного номера изделия, следующих после...
  • Page 24 HP_JBL_QUANTUM ONE_QSG_CR_V13...
