Summary of Contents for Harman JBL QUANTUM ONE
- Page 1 Q U I C K S T A R T G U I D E...
-
Page 2: Software Requirements
JBL QuantumENGINE Download JBL QuantumENGINE to gain full access to features on your JBL Quantum headsets - from headset calibration to adjusting 3D audio to suit your hearing, from creating customized RGB lighting effects to determining how the boom microphone side-tone works. jblquantum.com/engine Software requirements PLATFORM: Windows 7 / Windows 10 (64 bit) only 500MB of free hard drive space for installation... - Page 3 WHAT'S IN THE BOX Windshield foam for microphone Calibration Detachable Type-C to A cable with QSG | WARRANTY CARD | 3.5MM AUDIO WARNING CARD JBL QUANTUMOne headset CABLE Microphone Boom Microphone Game / Chat Balance Dial...
- Page 4 Requirements SOFTWARE REQUIREMENTS PLATFORM: Windows 7 / Windows 10 (64 bit) only 500MB OF FREE HARD DRIVE SPACE FOR INSTALLATION System compatibility PC | Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR...
- Page 5 OVERVIEW ANC / TALKTHRU LED ANC / TALKTHRU button Re-centering button for head tracking Flat-fold ear cup Volume Control RGB-Lit earcup Microphone Mute/unMute power status LED USB-C port 3.5mm Audio Jack Boom Microphone Jack Detachable boom microphone Game audio-chat balance dial power status LED Volume Control MIC MUTE BUTTON...
- Page 6 Calibration microphone 15-30 sec Go to JBL for detailed setup instructions.
- Page 7 SETUP Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR PC | Mobile | LAPTOP| Nintendo Switch™ * USB-C to USB-C cable is not included by-pack. Connectivity with USB-C may not work with all models of said devices.
- Page 8 BUTTON COMMAND ANC on/off TALKTHRU ON/OFF >2 Re-centering button for head tracking INCREASE GAME VOLUME INCREASE CHAT VOLUME INCREASE MASTER VOLUME DECREASE MASTER VOLUME Microphone Mute / unMute ON/OFF >5S...
- Page 9 First time setup Go to Sound Settings UNDER "PLAYBACK" HIGHLIGHT JBL QUANTUMOne GAME AND SELECT "SET DEFAULT DEVICE" HIGHLIGHT JBL QUANTUMOne CHAT AND SELECT "SET DEFAULT JBL QUANTUMOne JBL QUANTUMOne COMMUNICATION DEVICE" Game Chat UNDER "RECORDING" HIGHLIGHT JBL QUANTUMOne CHAT AND SELECT "SET DEFAULT DEVICE"...
- Page 10 MICROPHONE MIC MUTE MIC UNMUTE...
- Page 11 TECH SPEC Driver size: 50 mm Dynamic drivers Frequency response: 20 Hz - 40 kHz Microphone frequency response: 100 Hz -10 kHz Max input power 20 mW Sensitivity: 95 dB @ 1 kHz, 1 mW Maximum SPL: 97 dB Microphone sensitivity: -41 dBV @1 kHz / Pa Impedance: 32 Ohm...
- Page 12 HP_JBL_QUANTUM ONE_QSG_SOP_V7...
- Page 13 Every sound matters. Features Get the professional edge with head- Make your game epic. The JBL Quantum ONE wired headset gives you pro-level audio with tracking enhanced JBL QuantumSPHERE head-tracking enhanced JBL QuantumSPHERE 360 spatial surround sound and Active Noise ™...
-
Page 14: Features And Benefits
JBL’s algorithm with the integrated head-tracking sensor and by-pack mic is built exclusively for the JBL Quantum ONE giving gamers next-gen accuracy audio positioning and a fixed, independent soundscape, improving your natural instincts. JBL Quantum ONE is also equipped with DTS Headphone X: v2.0.
