BUILT-IN COMBINATION STEAM OVEN
Read these instructions carefully before using your
steam
oven , and keep it carefully.
If you follow the instructions, your oven will provide you with
many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
Guangdong Midea Kitchen Appliances Manufacturing Co., Ltd.
No.6, Yong An Road, Beijiao, Shunde, 528311 Foshan,
Guangdong, People's Republic of China
www.midea.com
WITH HOT AIR
OPERATION MANUAL
MODEL:TQN50E4AQ
TQN50E4AN
TQN50E4AL
TQN50E4EH
TQN50E4EO
TQN50E4EG
Advertisement
Table of Contents
Related Manuals for Midea TQN50E4AQ
Summary of Contents for Midea TQN50E4AQ
- Page 1 If you follow the instructions, your oven will provide you with many years of good service. SAVE THESE INSTRUCTIONS CAREFULLY Guangdong Midea Kitchen Appliances Manufacturing Co., Ltd. No.6, Yong An Road, Beijiao, Shunde, 528311 Foshan, Guangdong, People's Republic of China...
-
Page 2: Table Of Contents
CONTENTS CONTENTS PRECAUTIONS ADDENDUM SPECIFICATIONS IMPORTANT SAFETY INSTRUCTIONS TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION SETTING UP YOUR OVEN IMPORTANT INFORMATION ABOUT INSTALLING FITTED UNITS INSTALLATION DIMENSIONS 10-11 BUILDING IN IMPORTANT INFORMATION BEFORE FIRST USE 13-2 OPERATION INSTRUCTION TROUBLESHOOTING... -
Page 3: Precautions
If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation. Specifications Model: TQN50E4AQ -T00E00 50Hz Rated Frequency: Rated Voltage: 230V Rated Iutput Power(Grill): 2 200W... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS I M PO RTANT SAFET Y I NS TRUC TIONS IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, injury to persons when using your appliance, follow basic precautions, including the following: 1. Read and follow the specific:"PRECAUTIONS". 2. - Page 5 8. Only use the temperature probe recommended for this oven.(for ovens provided with a facility to use a temperature-sensing probe.) 9.This appliance is intended to be used in household and similar place . 10. The appliance shall not be cleaned with a steam cleaner.
-
Page 6: Read Carefully And Keep For Futurereference
18. The water in the receiving tank, inside the oven and in the water tank should be cleaned up after each use. 19. Do not use the paper cups and plastic containers with temperature resistance below 120 degrees. The glass, ceramic, stainless steel utensils can be used. -
Page 7: To Reduce The Risk Of Injury To Persons Grounding Installation
TO REDUCE THE RISk OF INjury to Persons Grounding Installation DANGER 2)The extension cord must be a grounding- type 3-wire cord. Electric Shock Hazard 3)The long cord should be arranged so that Touching some of the internal components it will not drape over the counter top or can cause serious personal injury or death. -
Page 8: Setting Up Your Oven
SETTING UP YOUR OVEN Names of Oven Parts and Accessories Remove the oven and all materials from the carton and oven cavity Your oven comes with the following accessories: Instruction Manual Side-rack Layer 3 Layer 2 Layer 1 Steam tray Side-racks Rack Meat probe holder... -
Page 9: Important Information About Installing
IMPORTANT INFORMATION ABOUT INSTALLING • This appliance is NOT intended for use in a commercial environment. • Please observe the installation instructions provided and note that this appliance should only be installed by a quali fied technician. • The appliance is fitted with a plug and must only be connected to a properly installed earthed socket. -
Page 10: Fitted Units
Fitted units • • • • • • • • • Installation dimensions min 45 min 45 Ventilation grid Cupboard feet Note: There should be gap above the oven. Building in Do not hold or carry the appliance by the door handle. The door handle cannot hold •... -
Page 11: Electrical Connection
Fully insert the appliance and centre it. Do not kink the connecting cable. Screw the appliance into place. The gap between the worktop and the appliance must not be closed by additional battens. Electrical connection The appliance is fitted with a plug and must only be connected to a properly installed earthed socket. Only a qualified electrician who takes the appropriate regulations into account may install the socket or replace the connecting cable. -
Page 12: Before First Use
Initial cleaning and heating Removing the steam oven all of the protection foil on the front. Before the first use of the appliance: Remove all accessories and wash out of the oven. Electric heating empty containers. New appliances typically smell when first used. Before using the electrical appliance to cook food faster to heat it helps to banish odors. -
Page 13: Operation Instruction
OPERATION INSTRUCTION Control Panel This steam oven uses modern electronic control to adjust cooking parameters to meet your needs better for cooking. ON / Cancel Switch on steam oven or cancel. Lamp ON / OFF Switch on and off lamp. Press this symbol to change heating mode. - Page 14 " " Pad instructions Order Function Temperatue setting Time setting Conventional °C - 230 °C 0:00min - 9:00hr Convection °C - 250 °C 0:00min - 9:00hr ECO Convection °C - 200 °C 0:00min - 9:00hr Conventional + Fan °C - 230 °C 0:00min - 9:00hr Radiant Heat...
- Page 15 Your steam oven has various operating modes which make your appliance easier to use. To enable you to find the correct type of heating for your dish, we have explained the differences and scopes of application here. Function For traditional baking and roasting on one level. Conventional Especially suitable for cakes with moist toppings.
- Page 16 1. Clock Setting When the steam oven is electrified, "00:00" will display, buzzer will ring once. 1) Touch " " once, the hour figures will flash. 2) Touch " " or " " or slide the to set the hour figures. The input time should be within 0--23.
- Page 17 Example: if you want to cook with Radiant Heat cooking. The steps are as following: 1) Touch " " five times to activate the function. The default temperature "150" °C will be displayed and the Radiant Heat icon appears. Touch " "...
- Page 18 4. Steam Function In standby mode, press " " key once, enter the steam mode. The icon is displayed, "100 ° C "symbol light . Touch " " to select the time setting mode. Touch" "or " " or slide to select the cooking time.
- Page 19 Water Box Function Steam note: Press water box and take it out , then take out sealing gasket and add water. 1) Use pure water with a TDS value greater than 3. Before steam cooking: Before starting the steam cooking mode, if the tank is short of water, press " "...
- Page 20 8. Descaling Function For best cleaning results, we recommend that you use detergent citric acid. Follow the manufacturer's instructions. Power up the system, remove the water tank, inject 1000ml of pure water into the water tank, adding a pack of citric acid about (5~10g). Push the water tank into the appropriate location of the steam oven.
- Page 21 5) Touch" "or " " or slide to adjust temperature setting. 6) Touch " " key to start cooking. 7) If the core temperature of the food reach the setting temperature of the prob, the buzzer will sound 5 times and the cooking is finished. Pull out the probe, oven will turn back to standby state or clock. Note: 4) The cooking time can't be set in the function.
- Page 22 MENU MENU DISPLAY WEIGHT T I ME POWER POSITION Steam100 °C Layer 2 of Stea m tray Steamed fish 500g 10:00 Steamed shrim p Steam100 °C Layer 2 of Stea m tray 500g 12:00 wit h garli c powder Steamed baby 500g 11:30 Steam100 °C...
-
Page 23: Troubleshooting
TROUBLE SHOOTING Unusual sound at the A pump makes noise at the beginning beginning and end and end of pumping. It is forbidden to run the unit without any food inside. It is very dangerous. According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated.
