Feature
1 USB Type-C Charging Ports x 4
2
Mounting Plate
3 Mounting Plate, Desk Mounting Holes x 4
4 Security Slots
5
AC Power Input
6
Anti-Slip Rubber Pads
7 Mounting Plate, Mounting Holes x 4
Package Contents
• Charger (A) x1
• Mounting Plate (Installed) (B) x 1
• M3x4mm (5/32") Phillips Countersunk Machine Screws (Installed) (C) x 4
• M4x12mm (1/2") Phillips Countersunk Wood Screws (D) x 4
• M4x20mm (3/4") Phillips Countersunk Wood Screws (E) x 4
• (Only for 424D3x-USB-C-CHARGER ) S2CEPR3M-USBSL-CABLE (F) x 2
• 6ft IEC-C5 Power Cord (G) x 1
Requirements
For the latest manuals, product information, technical specifications, and declarations of conformance, please visit:
www.StarTech.com/support
• Phillips head screwdriver
• (Optional) Appropriate mounting hardware and tools for the wall type
• (Optional) Power drill with an appropriate drill bit according to the wall type
• (Optional) Pencil or marker
• (Optional) Bubble level
• (Optional) Laptop Cable Lock
Warnings!
• StarTech.com Ltd. is not responsible for any property damage and/or personal injury resulting from the installation procedures
outlined in this technical document.
• The mounting instructions and/or hardware included with this product may not be suitable for the specific wall structure used.
If you lack the necessary expertise required to attach this product to the wall structure or to assess the suitability of the hardware
provided, please contact a professional installer.
• Read the entire Quick-Start Guide and ensure the instructions are fully understood before using this product.
• Never operate this product if parts are missing or damaged.
• Do not touch the product under power if the product has an exposed printed circuit board or electrical wire.
Over Temperature Protection
Over Temperature Protection (OTP) has been implemented to prevent the unit from overheating in abnormal scenarios.
OTP activation is based on the transformer temperature and will reduce the aggregate power from 240W to a lower level to
ensure that the device stays within safe operating limits. Following an OTP trigger and sufficient cooling time, the connected
device(s) should be hot-plugged to reset the power profile allocation.
Operational Notes
• It is recommended to keep the bracket always installed to ensure optimal thermal performance of the unit via the
additional clearance and airflow that the bracket provides.
• It is recommended to install the unit in a well-ventilated area, away from other sources of significant heat.
• If there are multiple units, they should NEVER be stacked on top of each other.
• Locking USB Type-C Ports supports up to 140W
• Supported power profiles: 5V 3A, 9V 3A, 12V 3A, 15V 3A, 20V 5A, 28V 5A
(140W Max)
• Programmable Power Supply (PPS) Mode: 5 - 11V 5A (45W Max)
Note: Refer to the Power Behavior table for power allocation among ports.
• Enables fastening of the Mounting Plate onto the 4-Port Charger
• Enables fastening of the Mounting Plate under a desk or onto a wall
• VESA compatible 100x100mm
• Enables securing of the 4-Port Charger with a Laptop Cable Lock
• Compatible with Nano, Noble Wedge®, and K-slot security slots
• Use to provide power with the included IEC-C5 Power Cord
• Help prevent the 4-Port Charger from sliding when placed on a surface
• Enables fastening of the Mounting Plate onto the 4-Port Charger with
the included M3 Phillips Countersunk Machine Screws
• Mounting Holes are spaced 40mm
• The mounting pattern is compatible with StarTech.com's Docking
Station VESA Mount Plates
Quick-Start Guide
Function
