VRCDWS*A VRC8WS*1A VRCTLDDWSC*A VRCTLRDDWSC*A VRCTL8WSC*1A VRCTLR8WSC*1A
Installation/Care/Use Manual
EZH2O Bottle Filling Station and Cooler
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER
LINES IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY
FROM THE BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREAT-
ING AN ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT
OF THE WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY
DRAIN FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISO-
LATE THE FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM. WE SUGGEST THAT THE BOTTLE FILLING
STATION AND WATER COOLER BE PROTECTED BY A GROUND FAULT CIRCUIT INTERRUPTER (GFCI).
INSTALLER
VRC8WS Bottle Fillers are among the easiest to install on the market today. To in-
sure you install these models easily and correctly, PLEASE READ THESE SIMPLE
INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR IN-
STALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL, AND
OTHER APPLICABLE CODES. After installation, leave these instructions with the
Fountain for future reference.
VRC8WS Factory Prep
IMPORTANT! INSTALLER PLEASE NOTE.
IMPORTANT
THIS IS AN INDOOR APPLICATION ONLY.
ALL SERVICE TO BE PERFORMED BY AN
AUTHORIZED SERVICE PERSON.
TOOLS REQUIRED
BUT NOT PROVIDED:
SAFETY GLASSES
GLOVES
ELECTRIC DRILL
3/4" WRENCH OR CRECENT WRENCH
UTILITY KNIFE
TAPE MEASURE
PENCIL
CENTER PUNCH
1/2" SOCKET & RATCHET WRENCH
5/32" ALLEN WRENCH
Page 1
98982C (Rev. A - 4/12)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Elkay VRC8WS 1A Series
Summary of Contents for Elkay VRC8WS 1A Series
- Page 1 VRCDWS*A VRC8WS*1A VRCTLDDWSC*A VRCTLRDDWSC*A VRCTL8WSC*1A VRCTLR8WSC*1A Installation/Care/Use Manual VRC8WS Factory Prep EZH2O Bottle Filling Station and Cooler IMPORTANT THIS IS AN INDOOR APPLICATION ONLY. ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON. TOOLS REQUIRED BUT NOT PROVIDED: SAFETY GLASSES GLOVES ELECTRIC DRILL 3/4”...
- Page 2 VRCDWS*A VRC8WS*1A VRCTLDDWSC*A VRCTLRDDWSC*A VRCTL8WSC*1A VRCTLR8WSC*1A Single Rough-In Fig. 1 98982C (Rev. A - 4/12) Page 2...
- Page 3 VRCDWS*A VRC8WS*1A VRCTLDDWSC*A VRCTLRDDWSC*A VRCTL8WSC*1A VRCTLR8WSC*1A Two-Level Rough-In Fig. 2 Page 3 98982C (Rev. A - 4/12)
- Page 4 VRCDWS*A VRC8WS*1A VRCTLDDWSC*A VRCTLRDDWSC*A VRCTL8WSC*1A VRCTLR8WSC*1A Two-Level Reversed Rough-In Fig. 2 98982C (Rev. A - 4/12) Page 4...
- Page 5 VRCDWS*A VRC8WS*1A VRCTLDDWSC*A VRCTLRDDWSC*A VRCTL8WSC*1A VRCTLR8WSC*1A MOUNTING SCREWS TOP COVER BOTTLE FILLER MOUNTING BRACKET FOR FASTENING UNIT MOUNTING SCREW TO WALL DO NOT REMOVE MOUNTING SCREWS DO NOT REMOVE NOTE: TRIM PLATES MUST BEINSTALLED ON THE INSIDE OF THE BOTTLE FILLER SIDE PANEL SLOTS WATER COOLER Fig.
- Page 6 VRCDWS*A VRC8WS*1A VRCTLDDWSC*A VRCTLRDDWSC*A VRCTL8WSC*1A VRCTLR8WSC*1A REMOVAL OF BOTTLE FILLER FOR SERVICING 1) Turn off the water supply to the Water Cooler(s). Unplug and/or turn off Circuit Braker to Cooler(s) and Bottle Filler. NOTE: the Lower Front Panel of the cooler(s) may need to be removed. To prevent scratching the basin place a towel or soft cloth over the entire basin when working above it.
-
Page 7: Replacement Part Kits
INFORMATIONS POUR LE SERVICE PAR NUMERO SANS FRAIS 1.800.260.6640 POUR OBTENIR DES PIÈCES, CONTACTEZ VOTRE DISTRIBUTEUR LOCAL OU COMPOSEZ LE 1.800.323.0620 ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484 Page 7 98982C (Rev. A - 4/12)
