- Page 1 OWNER’S GUIDE & SERVICE MANUAL M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N Model: MLCP215-SS81A...
-
Page 2: Warranty Registration
• Tech Support: techsupport@marvelrefrigeration.com Got a Marvelous Design? We would love to see how your Marvel product looks in its new home. You can send us photos of your installed product at marketing@marvelrefrigeration.com, and we might feature your Marvel home design on our website and... -
Page 3: Table Of Contents
TABLE OF CONTENTS Tip: Click on any section below to jump directly there Safety Thermistor Important Safety Instructions Warranty Installation Unpacking Your Appliance Electrical Cutout & Product Dimensions Installing Your Appliance Side-by-Side & Stacking Installations Door Reversal Installing The Water Supply Installing the Drain plumbing Maintenance Care and Cleaning... -
Page 4: Important Safety Instructions Warranty
IMPORTANT SAFETY INSTRUCTIONS Important Safety Instructions Warnings and safety instructions appearing in this guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when installing, maintaining or operating this appliance. Recognize Safety Symbols, Words and Labels WARNING... -
Page 5: Unpacking Your Appliance
UNPACKING YOUR APPLIANCE WARNING CAUTION If the appliance was shipped, handled or stored in other EXCESSIVE WEIGHT HAZARD than an upright position for any period of time, allow the Use two or more people to move product. appliance to sit upright for a period of at least 24 hours Failure to do so can result in personal injury. -
Page 6: Electrical Shock Hazard
ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be Do not remove plugged into a mating grounding type receptacle in ground prong accordance with the National Electrical Code and applicable local codes and ordinances. -
Page 7: Cutout & Product Dimensions
CUTOUT & PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS “A” “B” “C” “D” “E” “F” “G” “H” “J” 15” 34” to 35” 24” 14 7/8” 33 3/4” to 34 3/4” 23 5/8” 25 1/2” 37 3/8” 16 5/8” (38.1 cm) (86.4 cm to 88.9 cm) (61 cm) (37.8 cm) - Page 8 CUTOUT & PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUITEMENTS # WEIGHT 105 lbs 115V/60Hz/15A (47.6 kg) “H” “D” “F” “E” Glass Door 21 1/2” 3 1/2” (8.9 cm) (54.6 cm) Shown Minimum Minimum rough-in opening is required to be larger than the adjusted height of the cabinet.
-
Page 9: Outdoor Installation
- even if they sit out for "just a few hours". the grille openings kept clean. Marvel does not recommend the use of a custom made grille as air flow may be If you are getting rid of your old refrigerator, please restricted. -
Page 10: Side-By-Side & Stacking Installations
SIDE-BY-SIDE & STACKING INSTALLATION Side-by-Side Installation Stainless steel models which include the standard stainless handle will require 4 9/16” (116 mm) to allow both doors to Other Site Requirements open to 90° at the same time. Units must operate from separate, properly grounded elec- trical receptacles places according to each unit’s electrical 4 9/16”... -
Page 11: Door Reversing Instructions
DOOR REVERSAL Door Reversing Instructions Tools Needed: • 1/8” Hex Key • 5/32” Hex Key • Phillips Screwdriver 1. Open door and remove hinge pin from the upper hinge using a 1/8” hex key tool, making sure to steady the door. Slowly remove the door from the upper hinge and lift to remove off the base lower hinge. - Page 12 DOOR REVERSAL 6. Remove the toe kick from the door and attach it to the opposite side. Toe Kick Reversal 7. Reattach the upper and lower hinges, and hinge brackets to opposite sides. Then install the door.
-
Page 13: Using Your Electronic Control
USING YOUR ELECTRONIC CONTROL Control Function Guide Function Command Notes ON/OFF Press and release. Unit will immediately turn ON or OFF. Option Open Door Closed Door White White Hold and press and release . Press Adjust Light Color scroll through lighting options. BrightShield®... - Page 14 USING YOUR ELECTRONIC CONTROL BrightShield® This model includes BrightShield® with Vyv™ Antimicrobial Light Technology. BrightShield® • Kills* and prevents the growth of viruses, bacteria, fungi, yeasts, mold, and mildew • Provides continuous antimicrobial action to keep surfaces clean • Is approved for continuous use around people, pets, & plants •...
-
Page 15: Installing The Water Supply
INSTALLING THE WATER SUPPLY Water Supply Water line from water valve CAUTION to ice-maker Observe and follow all local building codes when installing this appliance. Use 1/4" outside diameter copper tubing for your water supply which is available at any local hardware or plumbing supply store. -
Page 16: Drain Connection
2. Connect to your local plumbing per the local code. CAUTION 3. If necessary, insulate drain line to prevent condensation. If your Marvel unit did not come with a factory installed CAUTION drain pump you must use a gravity style drain connection. - Page 17 INSTALLING THE DRAIN PLUMBING NOTE The maximum lift for the P60 drain pump is 10 feet. This must be done as close to the rear of the unit as possible.
-
Page 18: The Ice Making Process
ICE MAKER OPERATION The Ice Making Process When the ice slab reaches the correct thickness, the ice sheet is released and slides onto the grid cutter. Here, the Your ice machine is unique in how it forms ice with ice slab is cut into squares by the grid cutter’s heated wires. fractional freezing to form a slab of ice that is clear and has The water containing the dissolved minerals is drained after less dissolved solids than the water it is produced from. -
Page 19: Ice Production
ICE MAKER OPERATION Ice Production The ice machine will keep producing ice until the ice machine’s bin is full and will restart automatically when ice In normal mode the ice machine will produce up to 39 needs to be replenished in the bin. The ice bin is not pounds (17.7 kg) of clear ice in a 24-hour period when refrigerated, and some melting will occur by design to installed in a 72°F ambient with a 55°F water supply. -
Page 20: Care And Cleaning
"nickel safe" ice maker cleaner. You can order ice machine cleaner (part # S41013789) at marvelrefrigeration.com. CAUTION Use only Marvel-approved ice machine cleaner and follow all label warnings and directions. Incorrect chemical usage, and any damage that may result, is not covered by... - Page 21 CARE & CLEANING Remove ice from bin. Pull plug from the reservoir. Once reservoir is empty, replace plug. Hold the button for 10 seconds to show "CL" on the display. Lift Fascia door to access evaporator plate. Lift or remove splash shield to expose evaporator plate.
- Page 22 CARE & CLEANING Front Grille Be sure that nothing obstructs the required air flow openings in front of the cabinet. At least once or twice a year, brush or vacuum lint and dirt from the front grille are. CAUTION SHOCK HAZARD: Disconnect electrical power from the appliance before cleaning with soap and water.
-
Page 23: Long-Term Storage / Winterization
LONG-TERM STORAGE / WINTERIZATION If the ice machine is moved, not used for an extended period of time, or will be in an area that will be near freez- ing temperatures, it is necessary to remove any remaining water in the ice-making system. CAUTION This ice machine must have all water drained and removed to prevent ice machine damage as well as possible water... - Page 24 LONG-TERM STORAGE / WINTERIZATION 7. Disconnect the water valve’s outlet water line to the 8. Reconnect the water valve outlet water line. reservoir and drain the remaining water left in the water 9. Reinstall the ice machine’s access cover. line trap area. 10.
-
Page 25: Drain Pump Removal Instructions
LONG-TERM STORAGE / WINTERIZATION To Restart the Ice Machine 14. Remove the top clamp from the vent tube, for easier access for the air hose. 1. Reconnect or turn on the water supply line. 15. Apply air pressure (approximately 10 psi) to the end of 2. -
Page 26: If Service Is Required
OBTAINING SERVICE If Service is Required: • If the product is within the first year warranty period please contact your dealer or call Marvel Customer Service at 616.754.5601 for directions on how to obtain warranty coverage in your area. •... -
Page 27: Before You Call For Service
TROUBLESHOOTING Before You Call for Service WARNING If the appliance appears to be malfunctioning, read through this manual first. If the problem persists, check the troubleshooting guide below. Locate the problem in the Electrocution Hazard guide and refer to the cause and its remedy before calling •... -
Page 28: Wire Diagram
WIRE DIAGRAM SERVICE CORD GROUND GREEN GREEN PUMP SWITCH N.O. POWER GROUND PUMP Interior LED Condenser Fan TRANSFORMER HIGH WATER LIMIT BLACK SWITCH N.C. OUTLET Interior LED Pro Model GREEN DRAIN PUMP (OPTIONAL) SERVICE CORD- DRAIN PUMP GROUND Fresh Food Thermistor HOT GAS VALVE Evap Thermistor B/Y B/Y... -
Page 29: Warranty Claims
Final billing - Remodel • 60 day submittal deadline from date of completed service Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial • Only one repair or unit per warranty claim number, part number and part description. -
Page 30: Service Parts List
MAIN CONTROL BOARD KIT 90-54002-54 GRILLE S41015692-BLK LED STRIP WHITE 90-54085-00 BLACK ROCKER LIGHT SWITCH 42246922 THERMISTOR ASSEMBLY S68092 UI DISPLAY KIT-MARVEL S68167-01 CONDENSER FAN MOTOR 42248161 CONDENSER FAN BLADE 42248160 10 CONDENSER SENSOR 90-54013-00 11 COMPRESSOR ASSEMBLY 90-54006-00 12 INVERTER-COMPRESSOR... -
Page 31: Ordering Replacement Parts
Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial number, part number and part description. Some parts will require color or voltage information. -
Page 32: System Diagnosis Guide
SYSTEM DIAGNOSIS GUIDE Refrigeration System Diagnosis Guide System Suction Suction Compressor Condenser Capillary Evaporator Wattage Condition Pressure Line Discharge Tube Normal Normal Slightly Very hot Very hot Warm Cold Normal below room temperature Overcharge Higher than Very cold Slightly warm Hot to warm Cool Cold... -
Page 33: Compressor Specifications
COMPRESSOR SPECIFICATIONS FMXA9C WARNING Refrigerant R600A Electrocution can cause death or serious injury. Burns Voltage 115 VAC from hot or cold surfaces can cause serious injury. Frequency 60 Hz Take precautions when servicing this unit. Start Winding 5 Ohm at 77°F Disconnect the power source. -
Page 34: Control Operation-Service
CONTROL OPERATION-SERVICE UI Button Layout Control Function Guide Function Command Display/Options ON/OFF Press Unit will immediately release turn ON or OFF 1. Hidden Button Sabbath Mode See "Sabbath -Access Service Menu Mode" section -No LED directly above. All LEDs turn on with button 2. -
Page 35: Thermistor Failure
THERMISTOR Thermistors Evaporator Thermistor Thermistors are used for various temperature readings. If the evaporator thermistor fails, the unit will rely on a Thermistors provide reliable temperature readings using a preset defrost timer during defrost cycles. The unit will resistance which varies based on surrounding otherwise operate normally. -
Page 36: Warranty
For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase. - Page 37 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
