- Page 1 TRADITIONAL SAUNA SERIES Installation and Operating Instructions Tylö® Halmstad™ 3 Tylö® Halmstad™ 4...
- Page 2 THIS PAGE IS INTENTIONALLY BLANK 71-0190 10/1/24 Tylö® Halmstad™ 3 and 4 Revision C...
- Page 3 Before you begin reviewing the manual, please take a moment to register your warranty. Doing so will assist us in contacting you for any important notification. Prior to registering, you will need the serial number(s) located on the equipment. To register, please go to http://tylo.com/en-us/warranty FOR YOUR RECORDS Sauna Room Model/Serial Number: Control Model/Serial Number:...
- Page 4 HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page iv THIS PAGE IS INTENTIONALLY BLANK 71-0190 10/1/24 Tylö® Halmstad™ 3 and 4 Revision C...
-
Page 5: Table Of Contents
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page i Table of Contents SECTION 1. BEFORE YOU BEGIN ......................1 SECTION 2. SAFETY INFORMATION ....................... 2 2.1. CONSTRUCTION and INSTALLATION SAFETY ................2 2.2. USER and OPERATIONAL SAFETY ....................3 SECTION 3. -
Page 6: Section 1. Before You Begin
This manual is for installation and operation of an Tylö® Halmstad™ 3 and 4 sauna room with Sense UB heater (1802-60- 1902) mated with a Bliss control (1601-52, 1601-52-1) and CB23-1 (1201-23-1) contactor (CB) box. CB Box Tylö® Halmstad 3 Sauna Room Sense UB Heater Bliss Control... -
Page 7: Section 2. Safety Information
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 2 SECTION 2. SAFETY INFORMATION 2.1. CONSTRUCTION and INSTALLATION SAFETY WARNING - ELECTRIC SHOCK HAZARD: High voltage exists within this equipment. There are no user-serviceable parts within this equipment. Have the equipment installed and serviced only by qualified and licensed personnel in accordance with local and national codes. -
Page 8: User And Operational Safety
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 3 2.2. USER and OPERATIONAL SAFETY WARNING: Prolonged exposure to elevated temperatures can induce hyperthermia. Hyperthermia occurs when internal body temperature reaches several degrees above normal (98.6°F). Symptoms of hyperthermia include an increase in body temperature, dizziness, lethargy, drowsiness, and fainting. Effects of hyper- thermia include failure to perceive heat, failure to recognize the need to exit the room, unawareness of impending hazard, fetal damage in pregnant women, physical inability to exit the room and unconsciousness. -
Page 9: Section 3. Installation Requirements
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 4 SECTION 3. INSTALLATION REQUIREMENTS To ensure safe use of the sauna room, verify the following criteria are met: • At least three (3) adults are required for the assembly and installation of the room. •... -
Page 10: Section 4. Part List And Tool Requirements
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 5 SECTION 4. PART LIST and TOOL REQUIREMENTS PART LIST Before starting the assembly process, inspect packaging and verify contents. Each box label indicates the model of the sauna room and serial number. -
Page 11: Tool Requirements
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 6 Should it become necessary to contact your dealer or technical support for assistance, record the model and serial numbers from each box. Box Number Serial Number Model Number Box Number Serial Number Model Number Box Number... -
Page 12: Section 5. Sauna Room Assembly
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 7 SECTION 5. SAUNA ROOM ASSEMBLY Use these instructions for assembling a 3- and 4-person Traditional sauna room. For ease of illustration, instructions are written for a 4-person sauna room. LAYING THE FLOOR PANEL 1. - Page 13 HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 8 INSTALLING BACK LEFT WALL SECTION 8. Place the hangers of the back Left wall section into the mating hangers located on the back Left edge of the floor panel labeled #2. NOTE: Wall #2 includes a hole on the lower-left corner for the power cord.
-
Page 14: Connecting Cables
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 9 INSTALLING RIGHT WALL SECTION 13. Place the hangers of the right wall section into the mating hangers located on the right edge of the floor panel labeled #4. 14. Lift up the right wall and slide the edge brackets into the mating brackets located on the back wall. - Page 15 32. Align and slide the upper bench (C) over the side braces located on the left and right walls and drop into place. • For the Halmstad 3 (return bench not included), refer to the upper image of Figure 10. 33. Connect the upper bench light cable to the mating cable on the back wall.
- Page 16 Figure 11. Installing Front Edge Trim INSTALLING ARMREST AND RETURN BENCH NOTE: These steps apply only to the Halmstad 4 sauna room. For the Halmstad 3, proceed to instructions on Installing Backrests. Use Figure 12. for the following steps. 39. Bring the armrest into the room and position it in the right front corner next to where the glass will be (A).
- Page 17 HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 12 INSTALLING BACKRESTS Use Figure 13. for the following steps. 46. Attach the rear backrest onto the attachment bracket located on the upper back wall (A). 47. Attach the right backrest onto the attachment bracket located on the upper right wall (B).
-
Page 18: Installing Door Handle
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 13 HEAVY OBJECT: The door assembly is extremely heavy and fragile. It is best practice to have three (3) people assist during installation. DOOR SEAL ORIENTATION 57. Orient the door assembly so that the attached door seal will mate correctly with the door seal on the single pane. -
Page 19: Preparing The Ceiling
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 14 PREPARING THE CEILING NOTE: The ceiling is heavy and handling is awkward. It is best to stand inside the sauna room while guiding the ceiling into position. 67. From the top of the left, right, and back wall sections, Pull the ends of the cables out and away, over the outside edges. - Page 20 HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 15 INSTALLING CORNER STIFFENING BRACKETS NOTE: The brackets provided with this kit may have a different appearance than what is shown in Figure 22. 74. If pilot holes were not provided on the top corners, it may be necessary to pre-drill holes for installation of the bracket screws.
- Page 21 HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 16 ELECTRICAL CONNECTIONS - Ceiling, Front Right Corner 88. Fish out the two (2) cables from the hatch. 89. Connect front right corner #6 cable to #6 ceiling cable. 90. Connect the front right corner CN1 cable connector to the CN1 ceiling cable.
-
Page 22: Mounting The Heater
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 17 MOUNTING THE HEATER 103. Prepare the heater for installation. See the appropri- ate sauna heater installation and operating instructions manual. 104. Using the measurements provided in Figure 28. verify the position of the pre-drilled mounting holes for the heater. -
Page 23: Section 6. Electrical Hook-Up
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 18 SECTION 6. ELECTRICAL HOOK-UP Use Figure 29. for the following steps. Electrical installation must be made by a licensed Electrician in accordance with the National Electric Code and local regulations. 1. - Page 24 HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 19 DIAGRAM 1. ELECTRICAL, 240VAC 1 PHASE 71-0190 10/1/24 Tylö® Halmstad™ 3 and 4 Revision C...
- Page 25 HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 20 DIAGRAM 2. CB BOX INTERNAL VIEW 71-0190 10/1/24 Tylö® Halmstad™ 3 and 4 Revision C...
-
Page 26: Section 7. Control Installation
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 21 SECTION 7. CONTROL INSTALLATION The Bliss control is weather resistant and water resistant, allowing it to mount either on the interior or exterior of the sauna room. Unless the control is already pre-installed, use the following steps to install the control. 1. -
Page 27: Section 8. Operating The Control
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 22 Section 8. OPERATING the CONTROL The instructions provided here are for operating a tradi- HEATER TEMPERATURE SETTING tional sauna heater. See Bliss Operating Instructions for further details on the control. The temperature setting of the heater is displayed in small colored text. -
Page 28: Section 9. Installing Safety Placards
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 23 SECTION 9. INSTALLING SAFETY PLACARDS Three (3) metal safety placards are included inside the installation instruction envelope packaged with the sauna system. Figure 32. Caution Placard 1. Position the CAUTION placard in plain sight on the interior wall directly above the sauna heater and attach with the two (2) screws provided. -
Page 29: Section 10. Placing Sauna Rocks
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 24 SECTION 10. PLACING SAUNA ROCKS The rocks supplied with the heater were selected with the 2. For the firs layers, place smaller rocks around the outer best traditional sauna performance in mind. perimeter of the heating elements. -
Page 30: Section 11. How To Take A Sauna
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 25 SECTION 11. HOW TO TAKE A SAUNA • Devote adequate time to completely relax while taking a sauna bath. • Remove clothing and jewelry. Apply a towel loosely about the body. •... -
Page 31: Section 12. Maintenance
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 26 SECTION 12. MAINTENANCE 13.1. PRE-HEAT MODE Inspect sauna room at the end of each day the room to If the air temperature inside the sauna is below 10°F ensure the control and system is off. (-12°C) at startup, or if the temperature sensor is not detected, the CAUTION Pre-Heat Mode screen appears. -
Page 32: Sensor Not Detected
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 27 13.2. SENSOR NOT DETECTED 13.3. HIGH LIMIT ERROR When the sensor is not detected, power to the heater is When the high limit switch trips/activates, power to the disabled. heater is disabled. While the heater is on and if the temperature at the heater rises above the high limit threshold, the heater shuts off, an audible control alarm is sounded, and the WARNING High... -
Page 33: Door Open
HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 28 13.4. DOOR OPEN 13.5. JUMPER ERROR If an optional door switch (not provided by Sauna360) is This error occurs when the control detects an electrical installed, this message occurs when the control detects the jumper is open on the main board located in the CB Box. - Page 34 HALMSTAD™ 3 | 4 INSTALLATION and OPERATING INSTRUCTIONS Page 29 ©2024 Sauna360 Inc. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sauna360 is under license. Apple® is a registered trademark of Apple Inc. Tylö®...
