KGEAR GH8 Manual

GH8
8" high performance full-range loudspeaker
Thank you for choosing KGEAR!
To ensure proper operation, please carefully read
this owner's manual and safety instruction before
using the product. After reading this manual, be sure
to keep it for future reference.
If you have any questions about your new
device please contact K-array customer service at
support@k-array.com or contact the local distributor
in your country.
The GH8 is a medium-sized, compact, and
functional addition to the GH family. It features an
8" full-range dual-cone driver, delivering clear and
powerful sound across a wide frequency range, even
in challenging acoustic environments. The cardioid
dispersion pattern reduces rear sound emission,
minimizing energy loss and residual noise, achieving
up to 129dB SPL per unit.
Housed in a durable stainless steel enclosure with
an IP64 rating, the GH8 is designed to withstand
outdoor applications. It integrates Pure Array
Technology (PAT) and Slim Array Technology (SAT)
for optimized sound coverage and performance. The
speaker is equipped with 2x SpeakON connectors
for signal input and linking, as well as a 4-pin
Euroblock connector for secure connections in fixed
installation applications.
The GH8 is ideal for live performances, events, or
fixed installations, offering flexibility in setup and
exceptional sound quality.
Unpacking
Each KGEAR device is inspected before leaving the
factory. Upon arrival, carefully inspect the shipping
carton, then examine and test your new device. If
you find any damage, immediately notify the shipping
company. Check that the following parts are supplied
with the product:
A. 1 x GH8 - 8" full-range loudspeaker
B. 1x Euroblock speaker connector (MC 1.5/4-ST-3.1:
1N)
A
B
USER GUIDE
GH8 rear panel
IN NL4 LINK NL4
SpeakON port
SpeakON port
Eurblock 4-pin
p1 p2 p3 p4
