Installation
The GCF3/GWF3 loudspeaker can be installed both on the
ceiling and on a vertical surface. It is strongly recommended
that the mounting surface is flat (not curved).
Ensure that the mounting surface is free from
obstructions, pipes or studs, either in front
and behind the surface.
The cable runs and cable pipes shall be
set according to the loudspeaker system
configuration. The cables must be of
adequate quality, suitable for the installation's
environmental conditions and with proper
copper section to minimize power loss.
1
Remove the grill from the loudspeaker and keep it
in a safe place.
Position the cutout template and mark the surface
2
accordingly.
3
Drill a pilot hole, then cut all of the way around the
circular outline with a cutting saw.
Pull the speaker wire out of the hole and connect
4
it to the loudspeaker.
Lift one clamp of the loudspeaker and insert it into
5
the hole paying attention to not hurting the hands.
Lift the other clamp and insert in into the hole in
6
order to set the loudspeaker in its final position.
7
Reposition the grill on the loudspeaker.
GCF3 / GWF3
3" ceiling/in-wall full range loudspeaker
