- Page 1 Series ARP REPAIR KIT MANUAL...
-
Page 2: Product Safety Instructions
Always wear the proper safety equipment required by local authorities and current legislative regulations. For proper maintenance of Camozzi actuators, follow the instructions in this manual. Before removing the actuator, ensure the correct procedure is followed to isolate the valve and piping system. -
Page 3: Kit Content
Driveshaft Upper O-ring Endcap O-ring Piston Guidebar Piston O-ring Stop Adjustment O-ring Wear Pads Piston Some parts will not be needed, depending on the type of actuator that is going to be repaired. Ball Bearing 3000549639 Ver.00 Camozzi Automation S.p.A. -
Page 4: Actuator Disassembly
1.4 Actuator Disassembly 1.4 Actuator Disassembly • The cover screws of all Camozzi actuators are long enough to allow the release of the springs. • It is recommended to use a hydraulic press for better assistance for simple disassembly Unscrew two diagonal screws of the cover (on opposite... - Page 5 After removing the gaskets and plastics, use kerosene or an equivalent to clean the components before reas- sembling. This step is to ensure that any contaminants have been removed so that the actuator continues to function properly after reassembly. 3000549639 Ver.00 Camozzi Automation S.p.A.
-
Page 6: Actuator Assembly
• Check that the piston accessory parts do not show excessive wear. If so, replace all the parts. All components are included in the Camozzi Distribution Kit. • In the Simple Effect actuator, check that the springs are not damaged. If so, replace them. The springs must all be replaced by requesting a “Spring Kit”. - Page 7 90 degrees to the cylinder (plus a little extra), in the possible. closed position. Attention! Larger actuators require more than one person to service. Make sure you follow your company and government safety regulations rooms when working with heavy objects 3000549639 Ver.00 Camozzi Automation S.p.A.
- Page 8 Using the appropriate tool, fix the base to the cylinder via the pinion, making sure that the holes for the adjustment the 4 screws. screws up to the same side as the doors of the air. 3000549639 Ver.00 Camozzi Automation S.p.A.
- Page 9 45 degrees or at 90 degrees. Attention! If you have any questions regarding the maintenance of our products, please contact your local Camozzi represen- tative. Always follow your company’s safety procedures and national safety regulations. 3000549639 Ver.00...
- Page 10 A Camozzi Group Company c a m o z z i . c o m Contacts Camozzi Automation S.p.A. Customer Service Società Unipersonale Tel. +39 030 3792790 service@camozzi.com REGISTERED OFFICE Via R. Rubattino, 81 Export Department 20134 Milano Tel. +39 030 3792253 Italy sales@camozzi.com...
