SIMATIC Ident
RFID systems
SIMATIC RF200
System Manual
11/2022
J31069-D0227-U001-A12-7619
Introduction
Safety notes
System overview
Planning the RF200 system
Readers
Antennas
Transponder
System integration
System diagnostics
Appendix
Service & Support
1
2
3
4
5
6
7
8
9
A
B

Advertisement

loading
Need help?

Need help?

Do you have a question about the SIMATIC Ident RF200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens SIMATIC Ident RF200

Summary of Contents for Siemens SIMATIC Ident RF200

  • Page 1 Introduction Safety notes System overview SIMATIC Ident Planning the RF200 system RFID systems SIMATIC RF200 Readers Antennas System Manual Transponder System integration System diagnostics Appendix Service & Support 11/2022 J31069-D0227-U001-A12-7619...

  • Page 2: Qualified Personnel

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Table of contents Introduction ............................13 Safety notes ............................15 General safety instructions....................15 Security information ......................17 System overview..........................19 RFID components and their function .................. 20 Overview of transponders ....................24 Planning the RF200 system ......................... 27 Fundamentals of application planning................27 4.1.1 Selection criteria for SIMATIC RF200 components ...............
  • Page 4 Table of contents 4.4.1.4 Polyamide 6 and Polyamide 6.6 GF30................. 98 4.4.1.5 Polyamide 12 (PA 12)......................99 4.4.2 Transponder ........................100 4.4.2.1 Overview of the transponders and their housing materials..........100 4.4.2.2 Epoxy resin ........................102 4.4.2.3 Polyamide 6 and Polyamide 6.6 GF30................104 4.4.2.4 Polycarbonate (PC)......................
  • Page 5 Table of contents 5.5.2 Ordering data RF250R ...................... 130 5.5.3 Pin assignment RF250R ....................131 5.5.4 LED operating display....................... 131 5.5.5 Technical specifications ....................132 5.5.6 Approvals ........................133 5.5.7 Dimension drawing......................135 SIMATIC RF260R....................... 135 5.6.1 Features .......................... 135 5.6.2 Ordering data for RF260R....................
  • Page 6 Table of contents Antennas............................171 ANT 1 ..........................171 6.1.1 Characteristics ......................... 171 6.1.2 Ordering data ........................171 6.1.3 Transmission window....................... 172 6.1.4 Flush-mounted in metal ....................173 6.1.5 Minimum clearances......................173 6.1.6 Technical specifications ....................175 6.1.7 Dimension drawing......................176 ANT 3 ..........................
  • Page 7 Table of contents ANT 30 ..........................199 6.7.1 Features .......................... 199 6.7.2 Ordering data ........................200 6.7.3 Transmission window....................... 200 6.7.4 Flush-mounted in metal ....................201 6.7.5 Minimum spacing ......................201 6.7.6 Technical data........................202 6.7.7 Dimension drawing......................203 ANT 12 (stainless steel variant) ..................204 6.8.1 Features ..........................
  • Page 8 Table of contents 6.12.7 Dimension drawing......................231 6.13 ANT D6..........................232 6.13.1 Features .......................... 232 6.13.2 Ordering data ........................232 6.13.3 Transmission window....................... 233 6.13.4 Metal-free area ........................ 234 6.13.5 Minimum distance ......................234 6.13.6 Technical data........................235 6.13.7 Dimensional diagram ....................... 236 6.14 ANT D10..........................
  • Page 9 Table of contents 7.6.3 Mounting in metal ......................262 7.6.4 Technical specifications ....................263 7.6.5 Dimension drawing......................264 MDS D139 ........................265 7.7.1 Characteristics ......................... 265 7.7.2 Ordering data ........................265 7.7.3 Mounting on metal ......................265 7.7.4 Cleaning the transponder....................267 7.7.5 Use in hazardous areas.....................
  • Page 10 Table of contents 7.13.6 Technical specifications ....................293 7.13.7 Dimensional drawing ....................... 295 7.14 MDS D400 ........................296 7.14.1 Features .......................... 296 7.14.2 Ordering data ........................296 7.14.3 Metal-free area ........................ 296 7.14.4 Technical specifications ....................298 7.14.5 Dimension drawing......................299 7.15 MDS D421 ........................
  • Page 11 Table of contents 7.21.4 Technical specifications ....................323 7.21.5 Dimension drawing......................325 7.22 MDS D460 ........................325 7.22.1 Characteristics ......................... 325 7.22.2 Ordering data ........................326 7.22.3 Mounting on metal ......................326 7.22.4 Technical specifications ....................327 7.22.5 Dimension drawings ......................328 7.23 MDS D521 ........................
  • Page 12 Table of contents 7.29.4 Technical specifications ....................351 7.29.5 Dimension drawing......................353 7.30 MDS D560 ........................353 7.30.1 Characteristics ......................... 353 7.30.2 Ordering data ........................354 7.30.3 Mounting on metal ......................354 7.30.4 Technical specifications ....................355 7.30.5 Dimension drawings ......................356 System integration ..........................

  • Page 13: Introduction

    • System manual "MOBY D" • Operating Instructions "Mobile reader RF350M" • Product information "SIMATIC RF200 command set" You will find the latest versions of these manuals on the pages of the Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/14971/man). Registered trademarks The following and possibly other names not identified by the registered trademark sign ® are registered trademarks of Siemens AG: SIMATIC ®, SIMATIC RF ®...

  • Page 14: Recycling And Disposal

    Do not dispose of the products at public disposal sites. For environmentally compliant recycling and disposal of your electronic waste, please contact a company certified for the disposal of electronic waste or your Siemens representative. Note the different country-specific regulations.

  • Page 15: Safety Notes

    Safety notes General safety instructions SIMATIC RFID products comply with the salient safety specifications acc. to IEC, VDE, EN, UL and CSA. If you have questions about the permissibility of the installation in the planned environment, please contact your service representative. WARNING Power supply The equipment is designed for operation with Safety Extra-Low Voltage (SELV) by a Limited...

  • Page 16: Operating Temperature

    Safety notes 2.1 General safety instructions Operating temperature CAUTION Danger of burns Note that some outer components of the reader are made of metal. Depending on the environmental conditions temperatures can occur on the device that are higher than the maximum permitted operating temperature. Repairs WARNING Repairs only by authorized qualified personnel...

  • Page 17: Safety Distances

    In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks.
  • Page 18 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure...

  • Page 19: System Overview

    System overview SIMATIC RF200 is an inductive identification system that is compatible with the ISO 15693 standard and was specially designed for use in industrial production for the control and optimization of material flows. In contrast to SIMATIC RF300, SIMATIC RF200 is intended for RFID applications where performance requirements are not very high, for example with regard to data volume, transfer rate or diagnostics options.

  • Page 20: Rfid Components And Their Function

    System overview 3.1 RFID components and their function RFID components and their function RF200 system components Figure 3-1 RF200 system overview SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...
  • Page 21 System overview 3.1 RFID components and their function Table 3-1 Reader-transponder combination options - Part 1 Transponder RF210R/ RF220R RF240R RF260R RF280R RF350M RF210M MDS D100 ○ ✓ ✓ ✓ ✓ MDS D117 ○ ✓ MDS D124 ✓ ✓ ✓ ✓ ✓...
  • Page 22 System overview 3.1 RFID components and their function Table 3-2 Reader-transponder combination options - Part 2 Transponder RF250R with ANT 1 ANT 3 ANT 3S ANT 8 ANT 12 ANT 18 ANT 30 MDS D100 ✓ ○ MDS D117 ✓ ✓ ✓...
  • Page 23 System overview 3.1 RFID components and their function Table 3-3 Reader-transponder combination options - Part 3 Transponder RF285R with RF290R with ANT D1 ANT D5 ANT D6 ANT D1 ANT D5 ANT D6 ANT D10 MDS D100 ✓ ✓ ✓ ✓ ✓...

  • Page 24: Overview Of Transponders

    System overview 3.2 Overview of transponders Overview of transponders Overview of typical areas of application of ISO transponders for RF200 Transponder Area of application MDS D100 From simple identification such as electronic barcode replacement or supplementation, through warehouse and distribution logistics, right up to product identification. With this transponder, the maximum ranges are achieved in combination with the SIMATIC RF260R reader.
  • Page 25 System overview 3.2 Overview of transponders Transponder Area of application MDS D421 The MDS D421 is designed for tool coding according to DIN 69873. It can be used wherever small data carriers and exact positioning are required, e.g. tool identification, work‐ piece holders MDS D422 Identification of metallic workpiece holders, workpieces or containers...
  • Page 26 System overview 3.2 Overview of transponders SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 27: Planning The Rf200 System

    • Ambient conditions such as relative humidity, temperature, chemical impacts, etc. Support during selection The following tools support you in compiling and planning your Ident system with all relevant components: • TIA Selection Tool (http://www.siemens.com/tia-selection-tool) • SIMATIC Ident Configuration Guide (https://support.industry.siemens.com/cs/ww/en/view/ 67384964)
  • Page 28 Planning the RF200 system 4.1 Fundamentals of application planning The field strength of the alternating field decreases quickly in proportion to the distance from the reader. The distribution of the field depends on the structure and geometry of the antennas in the reader and transponder A prerequisite for the function of the transponder is a minimum field strength at the transponder, which is still barely achieved at distance S from the reader.
  • Page 29 Planning the RF200 system 4.1 Fundamentals of application planning Operating distance between transponder and reader Limit distance (maximum clear distance between upper surface of the reader and the transpond‐ er, at which the transmission can still function under normal conditions) Diameter of a transmission window Intersection of the axes of symmetry of the transponder Figure 4-1 RF210R/RF220R transmission window...
  • Page 30 Planning the RF200 system 4.1 Fundamentals of application planning Operating distance between transponder and reader Limit distance (maximum clear distance between upper surface of the reader and the transponder, at which the transmission can still function under normal conditions) Length of a transmission window Field centerpoint Figure 4-2 RF240R/RF260R transmission window...

  • Page 31: Width Of The Transmission Window

    Planning the RF200 system 4.1 Fundamentals of application planning 4.1.3 Width of the transmission window Determining the width of the transmission window The following approximation formula can be used for practical applications: Width of the transmission window Length of the transmission window Tracking tolerance The width of the transmission window (W) is particularly important for the mechanical tracking tolerance.
  • Page 32 Planning the RF200 system 4.1 Fundamentals of application planning Secondary fields without shielding The following graphic shows typical primary and secondary fields, if no shielding measures are taken. ① Main field ② Secondary field Figure 4-4 Secondary field without shielding In this arrangement, the reader can also read tags via the secondary field. Shielding is required in order to prevent unwanted reading via the secondary field, as shown and described in the following.
  • Page 33 Planning the RF200 system 4.1 Fundamentals of application planning ① Main field ② Secondary field Figure 4-5 Secondary field with shielding SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 34: Permissible Directions Of Motion Of The Transponder

    Planning the RF200 system 4.1 Fundamentals of application planning 4.1.5 Permissible directions of motion of the transponder Detection area and direction of motion of the transponder The transponder and reader have no polarization axis, i.e. the transponder can come in from any direction, assume any position as parallel as possible to the reader, and cross the transmission window.

  • Page 35: Dwell Time Of The Transponder

    Planning the RF200 system 4.1 Fundamentals of application planning Operation in dynamic mode When working in dynamic mode, the transponder moves past the reader. The transponder can be used as soon as the intersection (SP) of the transponder enters the circle of the transmission window.

  • Page 36: Communication Between Communications Module, Reader And Transponder

    Calculation examples for data transfer times You can find the calculation examples for data transfer time, depending on the components used, on the pages of the Siemens Industry Online Support. You can find the calculation examples using the following link (https://support.industry.siemens.com/cs/ww/en/view/...

  • Page 37: Field Data

    Planning the RF200 system 4.2 Field data of transponders and readers 4.2.1 Field data The limit distances (S ) and operating distances (S ) along with the length of the transmission window for each reader-transponder combination are listed in the tables below. Table 4-1 SIMATIC RF210R field data  ...
  • Page 38 Planning the RF200 system 4.2 Field data of transponders and readers   Length of the transmis‐ Operating distance (S Limit distance (S sion window (L MDS D460 1 ... 18 MDS D522 1 ... 10 MDS D522 1 ... 10 Special variant MDS D524 2 ...
  • Page 39 Planning the RF200 system 4.2 Field data of transponders and readers Table 4-4 Field data SIMATIC RF250R, with ANT 1   Length of the transmis‐ Operating distance (S Limit distance (S sion window (L MDS D100 5 ... 95 MDS D124 2 ...
  • Page 40 Planning the RF200 system 4.2 Field data of transponders and readers   Length of the transmis‐ Operating distance (S Limit distance (S sion window (L MDS D522 1 ... 12 Special variant MDS D524 1 ... 35 MDS D525 1 ... 12 MDS D526 2 ...
  • Page 41 Planning the RF200 system 4.2 Field data of transponders and readers   Length of the transmis‐ Operating distance (S Limit distance (S sion window (L MDS D521 0 ... 3 MDS D522 1 ... 7 MDS D522 1 ... 7 Special variant MDS D525 1 ...
  • Page 42 Planning the RF200 system 4.2 Field data of transponders and readers   Length of the transmis‐ Operating distance (S Limit distance (S sion window (L MDS D428 1 ... 18 MDS D460 1 ... 17 MDS D521 0 ... 4 MDS D522 1 ...
  • Page 43 Planning the RF200 system 4.2 Field data of transponders and readers   Length of the transmis‐ Operating distance (S Limit distance (S sion window (L MDS D160 1 ... 23 MDS D324 1 ... 22 MDS D422 0 ... 12 MDS D423 0 ...
  • Page 44 Planning the RF200 system 4.2 Field data of transponders and readers Table 4-14 SIMATIC RF260R field data   Length of the transmis‐ Operating distance (S Limit distance (S sion window (L) MDS D100 2 ... 110 MDS D124 2 ... 80 MDS D126 2 ...
  • Page 45 Planning the RF200 system 4.2 Field data of transponders and readers   Length of the transmission win‐ Operating distance Limit distance (S dow (L) in the x direc‐ in the y direc‐ tion (L tion (L MDS D425 2 ... 30 MDS D426 2 ...
  • Page 46 Planning the RF200 system 4.2 Field data of transponders and readers   Length of the transmis‐ Operating distance (S Limit distance (S sion window (L) MDS D528 0 ... 55 MDS D560 0 ... 60 All dimensions in mm. Table 4-17 Field data SIMATIC RF285R, with ANT D5  ...
  • Page 47 Planning the RF200 system 4.2 Field data of transponders and readers   Length of the transmission win‐ Operating distance Limit distance (S dow (L) X direction Y direction MDS D400 0 ... 400 MDS D424 0 ... 200 MDS D426 0 ... 300 MDS D524 0 ...
  • Page 48 Planning the RF200 system 4.2 Field data of transponders and readers   Length of the transmis‐ Operating distance (S Limit distance (S sion window (L) MDS D160 0 ... 130 MDS D165 0 ... 350 MDS D200 0 ... 400 MDS D261 0 ...

  • Page 49: Minimum Clearances

    Planning the RF200 system 4.2 Field data of transponders and readers Table 4-22 Field data SIMATIC RF290R, with ANT D10 (at 4 W)   Length of the transmission win‐ Operating distance Limit distance (S dow (L) X direction Y direction MDS D100 1050 0 ...
  • Page 50 Planning the RF200 system 4.2 Field data of transponders and readers   RF210R RF220R RF240R RF260R RF280R MDS D400 ≥ 240 ≥ 500 MDS D421 ≥ 10 MDS D422 ≥ 15 ≥ 20 ≥ 50 MDS D423 ≥ 80 ≥ 160 ≥ 250 MDS D424 ≥...
  • Page 51 Planning the RF200 system 4.2 Field data of transponders and readers   RF250R ANT 1 ANT 3 / ANT 3S / ANT 8 ANT 12 ANT 30 ANT 18 MDS D425 ≥ 150 ≥ 80 ≥ 60 ≥ 50 MDS D426 ≥...
  • Page 52 Planning the RF200 system 4.2 Field data of transponders and readers   RF285R RF290R ANT D1 ANT D5 ANT D6 ANT D1 ANT D5 ANT D6 ANT D10 MDS D460 ≥ 250 ≥ 800 ≥ 250 ≥ 800 MDS D521 MDS D522 MDS D522 Special variant MDS D524...

  • Page 53: Installation Guidelines

    Planning the RF200 system 4.3 Installation guidelines Note Effect on inductive fields by not maintaining the minimum distances of the readers If the values fall below those specified in the "minimum distance readers or antennas", there is a risk of the function being affected by inductive fields. In this case, the data transfer time would increase unpredictably or a command would be aborted with an error.

  • Page 54: Reduction Of Interference Due To Metal

    Planning the RF200 system 4.3 Installation guidelines 4.3.2 Reduction of interference due to metal Table 4-28 Interference due to metal rack Representation Description Problem: Metal rack Non-metallic spacer Sheet A metal rack is located above the transmission window of the reader. This affects the entire field.
  • Page 55 Planning the RF200 system 4.3 Installation guidelines Table 4-29 Flush-mounting of transponders and readers Representation Description Problem: Non-metallic spacer Sheet Flush-mounting of transponders and readers is possible in principle. How‐ ever, the size of the transmission win‐ dow is significantly reduced. The fol‐ Metal lowing measures can be used to counteract the reduction of the win‐...

  • Page 56: Effects Of Metal On Different Transponders And Readers

    Planning the RF200 system 4.3 Installation guidelines Mounting of several readers on metal frames or racks Any reader mounted on metal couples part of the field to the metal frame. There is normally no interaction as long as the minimum distance D and metal-free areas a, b are maintained. However, interaction may take place if an iron frame is positioned unfavorably.

  • Page 57: Impact Of Metal On The Transmission Window

    Planning the RF200 system 4.3 Installation guidelines 4.3.4 Impact of metal on the transmission window In general, the following points should be considered when mounting RFID components: • Direct mounting on metal is allowed only in the case of specially approved transponders. •...
  • Page 58 Planning the RF200 system 4.3 Installation guidelines The following table shows the different installation example of the reader with and without a metallic environment: Table 4-31 Installation examples RF210R Case Diagram Description Reader metal-free Reader on metal, distance from metal ≥ 12 mm Reader in metal, flush against M18 nut Reader in metal,...
  • Page 59 Planning the RF200 system 4.3 Installation guidelines Transponder RF210R without di‐ RF210R flush-moun‐ rect metal influence ted in metal (Case a, b and d) (Case c) MDS D127 Flush-mounted in metal; distance all round 0 mm MDS D160 Metal-free On metal, distance 10 mm MDS D324 Metal-free On metal, distance 15 mm...

  • Page 60: Rf220R

    Planning the RF200 system 4.3 Installation guidelines Mounting the transponder on or in metal is only possible with the appropriate spacer or if there is adequate clearance to the metal. Values of > 100% in relation to non-metal surroundings can occur if transponders were developed specifically for mounting in/on metallic surroundings.
  • Page 61 Planning the RF200 system 4.3 Installation guidelines Table 4-34 Reduction of field data due to metal, range as %: Transponder and RF220R Transponder RF220R without di‐ RF220R flush-moun‐ rect metal influence ted in metal (Case a, b and d) (Case c) MDS D124 Metal-free On metal, distance 15 mm...

  • Page 62: Rf240R

    Planning the RF200 system 4.3 Installation guidelines Transponder RF220R without di‐ RF220R flush-moun‐ rect metal influence ted in metal (Case a, b and d) (Case c) MDS D522 Metal-free Special variant Flush-mounted in metal; distance all round 0 mm MDS D524 Metal-free On metal, distance 0 mm Flush-mounted in metal;...
  • Page 63 Planning the RF200 system 4.3 Installation guidelines Table 4-35 Reduction of field data due to metal, range as %: Transponder and RF240R Transponder RF240R without RF240R on RF240R flush- direct metal mounted in met‐ metal influence (metal plate) (all round 20 mm) MDS D100 Without metal On metal, distance 20 mm...
  • Page 64 Planning the RF200 system 4.3 Installation guidelines Transponder RF240R without RF240R on RF240R flush- direct metal mounted in met‐ metal influence (metal plate) (all round 20 mm) MDS D424 Without metal On metal, distance 15 mm Flush-mounted in metal; distance all round 25 mm MDS D425 Without metal On metal, distance 0 mm...

  • Page 65: Rf250R

    Planning the RF200 system 4.3 Installation guidelines 4.3.4.4 RF250R The RF250R reader is operated with the external antennas ANT 1, 3, 3S, 8, 12, 18 and 30. The antennas can be flush-mounted in metal. Allow for a possible reduction in the field data. To prevent a reduction, the clearances a (all around) and b should be observed.
  • Page 66 Planning the RF200 system 4.3 Installation guidelines Transponder RF250R with ANT 1 Antenna with‐ Antenna on Antenna moun‐ out metal metal ted in metal (all round 40 mm) MDS D261 Without metal On metal; distance 25 mm MDS D324 Without metal On metal; distance 15 mm Flush-mounted in metal;...
  • Page 67 Planning the RF200 system 4.3 Installation guidelines Transponder RF250R with ANT 1 Antenna with‐ Antenna on Antenna moun‐ out metal metal ted in metal (all round 40 mm) MDS D526 Without metal On metal; distance 25 mm Flush-mounted in metal; distance all round 50 mm MDS D528 Without metal On metal;...
  • Page 68 Planning the RF200 system 4.3 Installation guidelines Transponder RF250R with ANT 3 Antenna without Antenna flush- metal mounted in metal (all round 20 mm) MDS D424 Without metal On metal, distance 15 mm Flush-mounted in metal; distance all round 25 mm MDS D425 Without metal On metal, distance 0 mm MDS D426...
  • Page 69 Planning the RF200 system 4.3 Installation guidelines Table 4-38 Reduction of field data due to metal, range as %: Transponder and RF250R with ANT 3S Transponder RF250R with ANT 3S Antenna without Antenna flush- metal mounted in metal MDS D117 Flush-mounted in metal; distance all round 20 mm MDS D127 Flush-mounted in metal;...
  • Page 70 Planning the RF200 system 4.3 Installation guidelines Transponder RF250R with ANT 12 Antenna without Antenna flush- metal mounted in metal (all round 7 mm) MDS D421 Without metal Flush-mounted in metal; distance all round 0 mm MDS D422 Without metal Flush-mounted in metal; distance all round 0 mm MDS D425 Without metal...
  • Page 71 Planning the RF200 system 4.3 Installation guidelines Transponder RF250R with ANT 18 Antenna without Antenna flush- metal mounted in metal (all round 10 mm) MDS D324 Without metal On metal, distance 15 mm Flush-mounted in metal; distance all round 25 mm MDS D421 Without metal Flush-mounted in metal;...
  • Page 72 Planning the RF200 system 4.3 Installation guidelines Mounting the transponder on or in metal is only possible with the appropriate spacer or if there is adequate clearance to the metal. Values of > 100% in relation to non-metal surroundings can occur if transponders were developed specifically for mounting in/on metallic surroundings.

  • Page 73: Rf260R

    Planning the RF200 system 4.3 Installation guidelines Transponder RF250R with ANT 30 Antenna without Antenna flush- metal mounted in metal (all round 20 mm) MDS D460 Without metal On metal, distance 10 mm MDS D522 Without metal Flush-mounted in metal; distance all round 0 mm MDS D522 Without metal Special variant...
  • Page 74 Planning the RF200 system 4.3 Installation guidelines Table 4-43 Reduction of field data due to metal, range as %: Transponder and RF260R Transponder RF260R with‐ RF260R on met‐ RF260R flush-moun‐ out direct ted in metal metal influ‐ (metal plate) (all round 20 mm) ence MDS D100 Without metal...
  • Page 75 Planning the RF200 system 4.3 Installation guidelines Transponder RF260R with‐ RF260R on met‐ RF260R flush-moun‐ out direct ted in metal metal influ‐ (metal plate) (all round 20 mm) ence MDS D424 Without metal On metal, distance 15 mm Flush-mounted in metal; distance all round 25 mm MDS D426 Without metal...

  • Page 76: Rf280R

    Planning the RF200 system 4.3 Installation guidelines 4.3.4.6 RF280R The RF280R can be flush-mounted in metal. Allow for a possible reduction in the field data. To avoid reduction, the distance a should be ≥ 20 mm. Figure 4-12 Metal-free area RF280R Table 4-44 Reduction of field data due to metal, range as %: Transponder and RF280R Transponder RF280R with‐...
  • Page 77 Planning the RF200 system 4.3 Installation guidelines Transponder RF280R with‐ RF280R on met‐ RF280R flush- out direct met‐ al (metal plate) mounted in al influence metal (20 mm all-round) MDS D261 Without metal On metal; distance 25 mm MDS D324 Without metal On metal;...

  • Page 78: Rf285R

    Planning the RF200 system 4.3 Installation guidelines 4.3.4.7 RF285R The RF285R reader is operated with the external antennas ANT D1, D5 and D6. The antennas can be flush-mounted in metal. Allow for a possible reduction in the field data. To avoid reduction, the distance a should be observed.
  • Page 79 Planning the RF200 system 4.3 Installation guidelines Transponder RF285R with ANT D1 Antenna with‐ Antenna on Antenna flush- out metal metal mounted in metal (all round 30 MDS D165 Without metal On metal; distance 25 mm MDS D200 Without metal On metal; distance 20 mm Flush-mounted in metal;...
  • Page 80 Planning the RF200 system 4.3 Installation guidelines Transponder RF285R with ANT D1 Antenna with‐ Antenna on Antenna flush- out metal metal mounted in metal (all round 30 MDS D526 Without metal On metal; distance 25 mm Flush-mounted in metal; distance all round 50 mm MDS D528 Without metal On metal;...
  • Page 81 Planning the RF200 system 4.3 Installation guidelines Transponder RF285R with ANT D5 Antenna on metal Antenna flush- mounted in metal (metal plate) (all round 150 mm) MDS D200 Without metal On metal, distance 20 mm Flush-mounted in metal; distance all round 20 mm MDS D261 Without metal On metal, distance 25 mm...
  • Page 82 Planning the RF200 system 4.3 Installation guidelines Transponder RF285R with ANT D6 Antenna on metal Antenna flush- mounted in metal (metal plate) (all round 200 mm) MDS D139 Without metal On metal, distance 30 mm MDS D160 Without metal On metal, distance 25 mm MDS D165 Without metal On metal, distance 20 mm...

  • Page 83: Rf290R

    Planning the RF200 system 4.3 Installation guidelines 4.3.4.8 RF290R The RF290R reader is operated with the external antennas ANT D1, D5, D6 and D10. The antennas can be flush-mounted in metal. Allow for a possible reduction in the field data. To avoid reduction, the distance a should be observed.
  • Page 84 Planning the RF200 system 4.3 Installation guidelines Transponder RF290R with ANT D1 Antenna with‐ Antenna on Antenna flush- out metal metal mounted in metal (all round 30 MDS D165 Without metal On metal; distance 25 mm MDS D200 Without metal On metal; distance 20 mm Flush-mounted in metal;...
  • Page 85 Planning the RF200 system 4.3 Installation guidelines Transponder RF290R with ANT D1 Antenna with‐ Antenna on Antenna flush- out metal metal mounted in metal (all round 30 MDS D526 Without metal On metal; distance 25 mm Flush-mounted in metal; distance all round 50 mm MDS D528 Without metal On metal;...
  • Page 86 Planning the RF200 system 4.3 Installation guidelines Transponder RF290R with ANT D5 Antenna on metal Antenna flush- mounted in metal (metal plate) (all round 150 mm) MDS D200 Without metal On metal, distance 20 mm Flush-mounted in metal; distance all round 20 mm MDS D261 Without metal On metal, distance 25 mm...
  • Page 87 Planning the RF200 system 4.3 Installation guidelines Transponder RF290R with ANT D6 Antenna on metal Antenna flush- mounted in metal (metal plate) (all round 200 mm) MDS D124 Without metal On metal, distance 25 mm MDS D126 Without metal On metal, distance 25 mm MDS D139 Without metal On metal, distance 30 mm...

  • Page 88: Installation And Connection Of 2 To 6 Antennas With One Reader

    Planning the RF200 system 4.3 Installation guidelines Transponder RF290R with ANT D10 Antenna on metal Antenna flush- mounted in metal (metal plate) (all round 200 mm) MDS D124 Without metal On metal, distance 25 mm MDS D126 Without metal On metal, distance 25 mm MDS D139 Without metal On metal, distance 30 mm...

  • Page 89: Installation Options With The Antenna Splitter (2-4 Antennas)

    Planning the RF200 system 4.3 Installation guidelines (RS-422). You can cascade the antenna splitters in such a way that up to 4 antennas can be connected at the same time. 4.3.5.1 Installation options with the antenna splitter (2-4 antennas) Possible configurations of the antennas The antenna installations described here have been designed for reading smartlabels (transponders) on goods on conveyor belts, conveyor systems or pallets.

  • Page 90: Installation Examples

    Planning the RF200 system 4.3 Installation guidelines Installation examples Figure 4-16 Installation example with 2 ANT D6 (portal) Figure 4-17 Installation example with ANT D6 (C arrangement) SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 91: Antenna Installation

    Planning the RF200 system 4.3 Installation guidelines Figure 4-18 Installation example with ANT D6 (tunnel) Note The minimum spacings between the antennas for operation with only one reader may be less than the distances described because this configuration has the same phase. 4.3.5.2 Antenna installation Configuring instructions...
  • Page 92 Planning the RF200 system 4.3 Installation guidelines The size of the sensing range depends on the label alignment. Note Sensing range Remember that the entire acquisition range of the antenna is larger than the transmission window in which the transponder is normally configured. This means there can be label alignments where even labels outside the transmission window will be identified.

  • Page 93: Required Components

    Planning the RF200 system 4.3 Installation guidelines Required components For installation with • 2 antennas (gate) • 3 antennas (C arrangement) • 4 antennas (tunnel) the following components are required: Table 4-52 Components required for setting up with 2, 3 or 4 antennas Number of required Component Article number...
  • Page 94 Planning the RF200 system 4.3 Installation guidelines Metal-free space To guarantee perfect functioning of the individual installation versions, all larger metal parts in the vicinity of the antennas must be removed. Figure 4-19 Metal-free space, side view (based on the example of a tunnel arrangement on a conveyor belt) approx.
  • Page 95 Planning the RF200 system 4.3 Installation guidelines • The metal parts in the immediate vicinity of the antenna must be grounded in a mesh with a good HF connection. • Since the write/read device is installed in a metal housing, and the antennas can couple into the cables to the write/read device, it must be installed at a distance of at least 500 mm from the antennas.

  • Page 96: Chemical Resistance Of The Reader And Transponders

    Top cover and bottom Aluminum RF290R Decorative membrane Polyester Component irrelevant for resistance of the overall housing If you have any questions, please contact Siemens Support, see section "AUTOHOTSPOT". 4.4.1.2 Polyester Table 4-54 Chemical Resistance - Polyester Substance Test conditions Rating Concentration [%] Temperature [°C]...

  • Page 97: Polymethylmethacrylate (Pmma)

    Planning the RF200 system 4.4 Chemical resistance of the reader and transponders Substance Test conditions Rating Concentration [%] Temperature [°C] Concentrated alkaline solutions ￮ Diluted alkaline solutions ++++ Methylene chloride ￮ Concentrated mineral acids ￮ Household cleaner ++++ Diluted acids ++++ Explanation of the rating ++++ Resistant...

  • Page 98: Polyamide 6 And Polyamide 6.6 Gf30

    Planning the RF200 system 4.4 Chemical resistance of the reader and transponders Explanation of the rating Conditionally resistant Less resistant Not resistant ￮ 4.4.1.4 Polyamide 6 and Polyamide 6.6 GF30 Table 4-56 Chemical resistance - PA6 and PA6.6 GF30 Substance Test conditions Rating Concentration [%] Temperature [°C] Mineral lubricants...

  • Page 99: Polyamide 12 (Pa 12)

    Planning the RF200 system 4.4 Chemical resistance of the reader and transponders 4.4.1.5 Polyamide 12 (PA 12) The resistance of the plastic housing to chemicals used in the automobile sector (e.g.: oils, greases, diesel fuel, gasoline, etc,) is not listed extra. Table 4-57 Chemical resistance - Polyamide 12 (PA 12) Substance...

  • Page 100: Transponder

    Planning the RF200 system 4.4 Chemical resistance of the reader and transponders Substance Test conditions Rating Concentration [%] Temperature [°C] Lactic acid, w. 20 ℃   20 ℃ 60 ℃ Sodium carbonate, w. (soda) c. s. 60 ℃ ++++ Sodium chloride, w. c.
  • Page 101 Planning the RF200 system 4.4 Chemical resistance of the reader and transponders The following table provides an overview of the housing materials of the transponders: Table 4-58 Overview of the housing materials of the transponders Housing material Transponder Polyphenylene sulfide (PPS) MDS D117 MDS D124 (6GT2600-0AC10) MDS D139...

  • Page 102: Epoxy Resin

    Planning the RF200 system 4.4 Chemical resistance of the reader and transponders 4.4.2.2 Epoxy resin Table 4-59 Resistance to chemicals - epoxy resin Substance Test conditions Rating Concentration [%] Temperature [°C] Allyl chloride 20 ℃ ++++ Formic acid 20 ℃ ++++ 100% 20 ℃...
  • Page 103 Planning the RF200 system 4.4 Chemical resistance of the reader and transponders Substance Test conditions Rating Concentration [%] Temperature [°C] Citric acid 20 ℃ ++++ Cyanamide 20 ℃ ++++ Cyanides (K–, Na– among others) 60 ℃ ++++ Dextrin, w. 60 ℃ ++++ Diethyl ether 20 ℃...

  • Page 104: Polyamide 6 And Polyamide 6.6 Gf30

    Planning the RF200 system 4.4 Chemical resistance of the reader and transponders Substance Test conditions Rating Concentration [%] Temperature [°C] Propanol 20 ℃ ++++ Nitric acid 20 ℃ ￮ Hydrochloric acid 20 ℃ ￮ Brine 60 ℃ ￮ Sulfur dioxide 100% 20 ℃...

  • Page 105: Polycarbonate (Pc)

    Planning the RF200 system 4.4 Chemical resistance of the reader and transponders Substance Test conditions Rating Concentration [%] Temperature [°C] Weak alkaline solutions Strong alkaline solutions ￮ Trichloroethylene ++++ Perchloroethylene ++++ Acetone ++++ Alcohols ++++ Hot water (hydrolysis resistance) Explanation of the rating ++++ Resistant Practically resistant...

  • Page 106: Polyphenylene Sulfide (Pps)

    Planning the RF200 system 4.4 Chemical resistance of the reader and transponders Explanation of the rating ++++ Resistant Practically resistant Conditionally resistant Less resistant Not resistant ￮ 4.4.2.5 Polyphenylene sulfide (PPS) The data memory has special chemical resistance to solutions up to a temperature of 200 °C. A reduction in the mechanical properties has been observed in aqueous solutions of hydrochloric acid (HCl) and nitric acid (HNO3) at 80 °C.

  • Page 107: Polyvinyl Chloride (Pvc)

    Planning the RF200 system 4.4 Chemical resistance of the reader and transponders Substance Test conditions Rating Concentration [%] Temperature [°C] FAM testing fluid 80 ℃ acc. to DIN 51 604-A Toluene 1, 1, 1-Trichloroethane 80 ℃ ++++ Xylene Zinc chloride (saturated) 80 ℃...

  • Page 108: Further Information

    Planning the RF200 system 4.5 Further information Further information Further information on "Fundamentals of application planning" and "EMC" can be found in RF300 system manual (https://support.industry.siemens.com/cs/ww/en/view/21738946). SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 109: Readers

    Note IO-Link variants of the RF200 readers The IO-Link variants of the readers are not included in the system manual. You will find these in the "SIMATIC RF200 IO-Link (https://support.industry.siemens.com/cs/ww/en/view/60641859)" operating instructions. SIMATIC RF210R 5.1.1...

  • Page 110: Pin Assignment Rf210R With Rs422 Interface

    You can find more information on error messages in the section "Error codes of the RF200 readers (Page 361)". The optical error display is only reset if the corresponding reset parameter ("option_1 = 2") is set (see product informa‐ tion "SIMATIC RF200 Command Set (https:// support.industry.siemens.com/cs/ww/en/view/44864850)"). SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 111: Minimum Distance Between Rf210R Readers

    Readers 5.1 SIMATIC RF210R 5.1.5 Minimum distance between RF210R readers RF210R side by side ≥ 60 mm Figure 5-1 Minimum distance between RF210R readers RF210R face to face ≥ 100 mm Figure 5-2 Face-to-face distance between two RF210Rs 5.1.6 Technical specifications Table 5-2 Technical specifications of the RF210R reader  ...
  • Page 112 Readers 5.1 SIMATIC RF210R     6GT2821-1AC10 Maximum range 20 mm Maximum data transmission speed ISO transponder reader ↔ transponder   • Read • Approx. 1500 bytes/s   • Write • Approx. 1500 bytes/s Typical transmission time for user data per byte  ...

  • Page 113: Approvals

    505 years 5.1.7 Approvals FCC information Siemens SIMATIC RF210R (MLFB 6GT2821-1AC10) FCC ID NXW-RF210R This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 114: Dimension Drawing

    Readers 5.2 SIMATIC RF210M 5.1.8 Dimension drawing Figure 5-3 RF210R dimension drawing Dimensions in mm SIMATIC RF210M 5.2.1 Features SIMATIC RF210M Characteristics ① Design RS422 interface ② Status display Application Reader for hand work and rework places, picking, track and trace, tool Ident 5.2.2 Ordering data RF210M  ...

  • Page 115: Installing The Rf210M Reader

    Readers 5.2 SIMATIC RF210M 5.2.3 Installing the RF210M reader The following figure shows the completely mounted reader. Note that you can mount the ① suspension bracket at two different points . If you do not mount the handle, we recommend ② that you close the opening with the protective cap.

  • Page 116: Led Operating Display

    RF200 readers (Page 361)". The optical error display is only reset if the corresponding reset parameter ("option_1 = 2") is set (see product informa‐ tion "SIMATIC RF200 Command Set (https:// support.industry.siemens.com/cs/ww/en/view/44864850)"). 5.2.6 Technical specifications Table 5-4 Technical specifications of the RF210M reader  ...
  • Page 117 Readers 5.2 SIMATIC RF210M     6GT2823-0AA00   Interfaces Electrical connector design M12, 8-pin Standard for interfaces for communication RS-422 Antenna integrated   Mechanical specifications Housing     • Material •   • Color • Black   Supply voltage, current consumption, power loss Supply voltage 24 VDC Typical current consumption...

  • Page 118: Approvals

    5.2 SIMATIC RF210M 5.2.7 Approvals FCC information Siemens SIMATIC RF210R (MLFB 6GT2821-1AC10) FCC ID NXW-RF210R This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 119: Dimension Drawing

    Readers 5.3 SIMATIC RF220R 5.2.8 Dimension drawing Figure 5-5 Dimension drawing RF210M All dimensions in mm, tolerances ± 1 mm SIMATIC RF220R 5.3.1 Features SIMATIC RF220R Characteristics ① Design RS422 interface ② Status display Application Identification tasks on assembly lines in harsh indus‐ trial environments SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 120: Rf220R Ordering Data

    You can find more information on error messages in the section "Error codes of the RF200 readers (Page 361)". The optical error display is only reset if the corresponding reset parameter ("option_1 = 2") is set (see product informa‐ tion "SIMATIC RF200 Command Set (https:// support.industry.siemens.com/cs/ww/en/view/44864850)"). SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 121: Minimum Distance Between Rf220R Readers

    Readers 5.3 SIMATIC RF220R 5.3.5 Minimum distance between RF220R readers RF220R side by side ≥ 100 mm Figure 5-6 Minimum distance between RF220R readers RF220R face to face ≥ 150 mm Figure 5-7 Face-to-face distance between two RF220Rs 5.3.6 Technical specifications Table 5-6 Technical specifications of the RF220R reader  ...
  • Page 122 Readers 5.3 SIMATIC RF220R     6GT2821-2AC10   Electrical data Maximum range 35 mm Maximum data transmission speed ISO transponder reader ↔ transponder   • Read • Approx. 1500 bytes/s   • Write • Approx. 1500 bytes/s Typical transmission time for user data per byte  ...

  • Page 123: Approvals

    501 years 5.3.7 Approvals FCC information Siemens SIMATIC RF220R (MLFB 6GT2821-2AC10) FCC ID NXW-RF220R This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 124: Dimension Drawing

    Readers 5.4 SIMATIC RF240R (2) l'utilisateur de l`appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d`en compromettre le fonctionnement. 5.3.8 Dimension drawing Figure 5-8 RF220R dimension drawing Dimensions in mm SIMATIC RF240R 5.4.1 Features SIMATIC RF240R Characteristics ①...

  • Page 125: Rf240R Ordering Data

    You can find more information on error messages in the section "Error codes of the RF200 readers (Page 361)". The optical error display is only reset if the corresponding reset parameter ("option_1 = 2") is set (see product informa‐ tion "SIMATIC RF200 Command Set (https:// support.industry.siemens.com/cs/ww/en/view/44864850)"). SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 126: Minimum Distance Between Several Rf240R Readers

    Readers 5.4 SIMATIC RF240R 5.4.5 Minimum distance between several RF240R readers RF240R readers side by side ≥ 120 mm (with 2 readers) ≥ 200 mm (with more than 2 readers) Figure 5-9 Minimum distance between several RF240R readers RF240R face-to-face ≥ 400 mm Figure 5-10 Face-of-face distance between two RF240R readers 5.4.6...
  • Page 127 Readers 5.4 SIMATIC RF240R     6GT2821-4AC10 6GT2821-4AC11 6GT2821-4AC40 Operating frequency, rated value 13.56 MHz   Electrical data Maximum range 65 mm Maximum data transmission speed ISO transponder reader ↔ transponder   • Read • Approx. 1500 bytes/s   • Write • Approx.

  • Page 128: Approvals

    5.4.7 Approvals FCC information Siemens SIMATIC RF240R (MLFB 6GT2821-4AC10) FCC ID NXW-RF240R Siemens SIMATIC RF240R (MLFB 6GT2821-4AC11) FCC ID NXW-RF240R Siemens SIMATIC RF240R (MLFB 6GT2821-4AC40) FCC ID NXW-RF240R This device complies with part 15 of the FCC rules. Operation is subject to the following two...

  • Page 129: Dimension Drawing

    Readers 5.4 SIMATIC RF240R Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. IC information This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired...

  • Page 130: Simatic Rf250R

    Readers 5.5 SIMATIC RF250R SIMATIC RF250R 5.5.1 Features SIMATIC RF250R Characteristics ① Structure RS-422 or RS-232 interface ② Operating indicator ③ Antenna connector, M8 Area of application Identification tasks on assembly lines in harsh indus‐ trial environments Note Reader requires external antennas Note that the RF250R reader is designed only for operation with external antennas and can only be operated in conjunction with the antennas ANT 3, ANT 8, ANT 12, ANT 18 or ANT 30.

  • Page 131: Pin Assignment Rf250R

    You can find more information on error messages in the section "Error codes of the RF200 readers (Page 361)". The optical error display is only reset if the corresponding reset parameter ("option_1 = 2") is set (see product informa‐ tion "SIMATIC RF200 Command Set (https:// support.industry.siemens.com/cs/ww/en/view/44864850)"). SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 132: Technical Specifications

    Readers 5.5 SIMATIC RF250R 5.5.5 Technical specifications Table 5-10 Technical specifications of the RF250R reader     6GT2821-5AC10 6GT2821-5AC40 Product type designation SIMATIC RF250R     Radio frequencies Operating frequency, rated value 13.56 MHz   Electrical data Maximum range 35 mm Maximum data transmission speed ISO transponder reader ↔...

  • Page 133: Approvals

    430 years 5.5.6 Approvals FCC information Siemens SIMATIC RF250R (MLFB 6GT2821-5AC10) FCC ID NXW-RF250R Siemens SIMATIC RF250R (MLFB 6GT2821-5AC40) FCC ID NXW-RF250R This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:...
  • Page 134 Readers 5.5 SIMATIC RF250R with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. IC information This device complies with Industry Canada licence-exempt RSS standard(s).

  • Page 135: Dimension Drawing

    Readers 5.6 SIMATIC RF260R 5.5.7 Dimension drawing Figure 5-12 Dimension drawing RF250R Dimensions in mm SIMATIC RF260R 5.6.1 Features SIMATIC RF260R Characteristics ① Structure RS-422 or RS-232 interface ② Operating indicator Field of application Identification tasks on assembly lines in harsh indus‐ trial environments SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 136: Ordering Data For Rf260R

    You can find more information on error messages in the section "Error codes of the RF200 readers (Page 361)". The optical error display is only reset if the corresponding reset parameter ("option_1 = 2") is set (see product informa‐ tion "SIMATIC RF200 Command Set (https:// support.industry.siemens.com/cs/ww/en/view/44864850)"). SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 137: Minimum Distance Between Several Rf260R

    Readers 5.6 SIMATIC RF260R 5.6.5 Minimum distance between several RF260R RF260R side by side ≥ 150 mm (with 2 readers) ≥ 250 mm (with more than 2 readers) Figure 5-13 Minimum distance between several RF260R RF260R face to face ≥ 500 mm Figure 5-14 Face-to-face distance between two RF260R SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 138: Technical Specifications

    Readers 5.6 SIMATIC RF260R 5.6.6 Technical specifications Table 5-12 Technical data of the RF260R reader     6GT2821-6AC10 6GT2821-6AC11 6GT2821-6AC40 Product type designation SIMATIC RF260R     Radio frequencies Operating frequency, rated value 13.56 MHz   Electrical data Maximum range 135 mm Maximum data transmission speed ISO transponder reader ↔...

  • Page 139: Approvals

    5.6.7 Approvals FCC information Siemens SIMATIC RF260R (MLFB 6GT2821-6AC10) FCC ID NXW-RF260R Siemens SIMATIC RF260R (MLFB 6GT2821-6AC11) FCC ID NXW-RF260R Siemens SIMATIC RF260R (MLFB 6GT2821-6AC40) FCC ID NXW-RF260R This device complies with part 15 of the FCC rules. Operation is subject to the following two...

  • Page 140: Dimension Drawing

    Readers 5.6 SIMATIC RF260R This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 141: Simatic Rf280R

    Readers 5.7 SIMATIC RF280R SIMATIC RF280R 5.7.1 Features SIMATIC RF280R Characteristics ① Design RS-422 or RS-232 interface ② Operating indicator Field of application Identification tasks on assembly lines in harsh indus‐ trial environments 5.7.2 Ordering data RF280R   Article number RF280R with RS422 interface (3964R) 6GT2821-8AC10 RF280R with RS232 interface (ASCII) 6GT2821-8AC40...

  • Page 142: Led Operating Display

    You can find more information on error messages in the section "Error codes of the RF200 readers (Page 361)". The optical error display is only reset if the corresponding reset parameter ("option_1 = 2") is set (see product informa‐ tion "SIMATIC RF200 Command Set (https:// support.industry.siemens.com/cs/ww/en/view/44864850)"). SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 143: Minimum Distance Between Rf280R Readers

    Readers 5.7 SIMATIC RF280R 5.7.5 Minimum distance between RF280R readers RF280R side-by-side ≥ 150 mm (with 2 readers) ≥ 250 mm (with more than 2 readers) Figure 5-16 Minimum distance between RF280R readers RF280R Face-to-Face ≥ 800 mm Figure 5-17 Face-to-face distance between two RF280R SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 144: Technical Specifications

    Readers 5.7 SIMATIC RF280R 5.7.6 Technical specifications Table 5-14 Technical specifications of the RF280R reader     6GT2821-8AC10 6GT2821-8AC40 Product type designation SIMATIC RF280R     Radio frequencies Operating frequency, rated value 13.56 MHz   Electrical data Maximum range 200 mm Maximum data transmission speed ISO transponder reader ↔...

  • Page 145: Approvals

    172.6 years 5.7.7 Approvals FCC information Siemens SIMATIC RF280R (MLFB 6GT2821-8AC10) FCC ID NXW-RF280R Siemens SIMATIC RF280R (MLFB 6GT2821-8AC40) FCC ID NXW-RF280R This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:...

  • Page 146: Dimension Drawing

    Readers 5.7 SIMATIC RF280R These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

  • Page 147: Simatic Rf285R

    Readers 5.8 SIMATIC RF285R SIMATIC RF285R 5.8.1 Characteristics SIMATIC RF285R Characteristics ①   Design RS 232 interface, 24 V power supply ② Antenna connection, TNC ③ Operating display, 4 LEDs: • Power (PWR) • Active (ACT) • Present (PRE) • Error (ERR) Field of application Identification tasks in production control and in in‐...

  • Page 148: Pin Assignment

    Readers 5.8 SIMATIC RF285R   Article number Wide-range power supply unit for SIMATIC RF systems EU: 6GT2898-0AC00 (100 - 240 VAC / 24 VDC / 3 A) UK: 6GT2898-0AC10 with country-specific power cable/plug, 2 m US: 6GT2898-0AC20 Antennas Antenna ANT D1 6GT2698-5AC00 Antenna ANT D5 6GT2698-5AA10 Antenna ANT D6 6GT2698-5AB00...

  • Page 149: Installing The Rf285R Reader

    Readers 5.8 SIMATIC RF285R Label Meaning Communication on the data line Transponder present Error when connecting the antenna or the interference level in the antenna environment is too high 5.8.5 Installing the RF285R reader 5.8.5.1 Wall mounting Use the holes in the housing to screw the device to the wall or onto a horizontal surface. The position of the drill holes is shown in the following figure: Figure 5-19 Drilling pattern for the RF285R (dimensions in mm)

  • Page 150: Installing On The S7-300 Standard Rail

    Readers 5.8 SIMATIC RF285R 5.8.5.2 Installing on the S7-300 standard rail Follow the steps below to mount the RF285R reader on a vertical S7-300 standard rail: 1. Place the device on the upper edge of the S7-300 standard rail (position A). 2.
  • Page 151 Readers 5.8 SIMATIC RF285R Figure 5-21 Mounting the DIN rail adapter Follow the steps below to mount the RF285R reader on a DIN rail: 1. Place the device on the upper edge of the DIN rail (position A). 2. Pull the spring-mounted DIN rail slider (position B) down and press the device against the DIN rail until it locks in place.

  • Page 152: Technical Specifications

    Readers 5.8 SIMATIC RF285R 5.8.6 Technical specifications Table 5-19 Technical specifications of the RF285R reader     6GT2821-7AC12 Product type designation SIMATIC RF285R     Radio frequencies Operating frequency, rated value 13.56 MHz   Electrical data Maximum range 550 mm Maximum data transmission speed ISO transponder reader ↔...

  • Page 153: Approvals

    18 years 5.8.7 Approvals FCC information Siemens SIMATIC RF285R (MLFB 6GT2821-7AC12) FCC ID NXW-RF285R This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 154 Readers 5.8 SIMATIC RF285R IC information This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 155: Note On Using The Rf285R As A Replacement For Slg D11

    Readers 5.8 SIMATIC RF285R Antennes utilisées: • ANT D1, max. gain: 0dB • ANT D5, max. gain: 0dB • ANT D6, max. gain: 0dB 5.8.8 Note on using the RF285R as a replacement for SLG D11 The RF285R reader is the successor to the MOBY D readers SLG D11 rounding off the RF200 family;...

  • Page 156: Dimension Drawing

    Readers 5.8 SIMATIC RF285R 5.8.9 Dimension drawing Figure 5-23 Dimension drawing RF285R (dimensions in mm) SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 157: Simatic Rf290R

    Readers 5.9 SIMATIC RF290R SIMATIC RF290R 5.9.1 Features SIMATIC RF290R Characteristics ①   Design RS422/RS232 interface, 24 V power supply ② Digital input/output, M12 ③ Antenna connection, TNC ④ Operating display, 4 LEDs: • Power (PWR) • Active (ACT) • Present (PRE) •...
  • Page 158 Readers 5.9 SIMATIC RF290R Table 5-22 Ordering data - accessories - RF290R   Article number 24 V connecting cable 6GT2491-1HH50 RS-232 connecting cable, with 4-pin M12 connector for 6GT2891-4KH50 24 V for connection to the wide-range power supply unit RS-232 connecting cable with open cable ends for 24 V 6GT2891-4KH50-0AX0 Adapter for mounting on a DIN rail (pack of 3) 6GK5798-8ML00-0AB3...

  • Page 159: Pin Assignment

    Readers 5.9 SIMATIC RF290R 5.9.3 Pin assignment RS422/RS232 Table 5-23 Pin assignment of the RS-422/RS 232 interface Pin assignment Device end 8- RS-422 RS232 pin M12 +24 V +24 V - Transmit + Transmit + Receive not used   - Receive not used not used Ground (shield) Ground (shield) Digital input/output...

  • Page 160: Led Operating Display

    Readers 5.9 SIMATIC RF290R Digital input (DI): The opto-coupler input is electrically isolated from the reader electronics. The external 24 V must be connected to the DI according to the circuit diagram. Make sure that the polarity of the 24 V is correct. The voltage is limited to < 10 mA by the integrated resistor. NOTICE Reader may be damaged If you exceed the maximum permitted supply voltage, the reader may be damaged.

  • Page 161: Installing The Rf290R Reader

    (Page 361)". The optical error display is only reset if the corre‐ sponding reset parameter ("option_1 = 2") is set (see Product In‐ formation " Product information "SIMATIC RF200 command set" (https://support.industry.siemens.com/cs/ww/en/view/ 44864850)"). PC mode: Error when connecting the antenna or the interference level in the antenna environment is too high 5.9.5...

  • Page 162: Installing On The S7-300 Standard Rail

    Readers 5.9 SIMATIC RF290R Figure 5-25 Drilling pattern for the RF290R (dimensions in mm) A: M4 threaded socket for potential connection of the reader. You will find further information on the potential connection in the section "Further information (Page 108)". 5.9.5.2 Installing on the S7-300 standard rail Follow the steps below to mount the RF290R reader on a vertical S7-300 standard rail: 1.

  • Page 163: Installation On A Din Rail

    Readers 5.9 SIMATIC RF290R Figure 5-26 Installing the RF290R reader on the S7-300 standard rail 5.9.5.3 Installation on a DIN rail The RF290R reader is suitable for installation on 35 mm rails that comply with DIN EN 50022. Note The adapter for mounting on a DIN rail does not ship with the RF290R The adapter for mounting on a DIN rail does not ship with the product.
  • Page 164 Readers 5.9 SIMATIC RF290R Figure 5-27 Mounting the DIN rail adapter Follow the steps below to mount the RF290R reader on a DIN rail: 1. Place the device on the upper edge of the DIN rail (position A). 2. Pull the spring-mounted DIN rail slider (position B) down and press the device against the DIN rail until it locks in place.

  • Page 165: Technical Specifications

    Readers 5.9 SIMATIC RF290R 5.9.6 Technical specifications Table 5-26 Technical specifications of the RF290R reader     6GT2821-0AC12 Product type designation SIMATIC RF290R     Radio frequencies Operating frequency, rated value 13.56 MHz   Electrical data Maximum range 650 mm Maximum data transmission speed ISO transponder reader ↔...

  • Page 166: Approvals

    18 years 5.9.7 Approvals FCC information Siemens SIMATIC RF290R (MLFB 6GT2821-0AC12) FCC ID NXW-RF290R This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 167: Note On The Use Of The Rf290R As A Replacement For Slg D10 / Slg D10S

    Readers 5.9 SIMATIC RF290R Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. IC information This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired...
  • Page 168 Readers 5.9 SIMATIC RF290R Properties SLG D10/SLG D10S Properties RF290R no digital I/O M12, 4-pin female connector for digital I/O (can only be used in PC mode) no operating display via LEDs operating display by four LEDs Maximum transmit power of 10 W Maximum transmit power of 5 W One securing option Different securing options...

  • Page 169: Dimension Drawing

    Readers 5.9 SIMATIC RF290R 5.9.9 Dimension drawing Figure 5-29 Dimensional drawing RF290R (dimensions in mm) SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...
  • Page 170 Readers 5.9 SIMATIC RF290R SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 171: Antennas

    Antennas Note The RF250R, RF285R and RF290R readers require external antennas. Note that the RF250R, RF285R and RF290R readers are designed for operation with external antennas. The RF250R reader can only be used in conjunction with the antennas ANT 1, 3, 3S, 8, 12, 18 or 30.

  • Page 172: Transmission Window

    Antennas 6.1 ANT 1 6.1.3 Transmission window Length of the transmission window Operating distance between antenna and transponder Limit distance (limit distance is the maximum clear distance between the upper surface of the antenna and the transponder at which the transmission can still function under normal conditions). Figure 6-1 Transmission window ANT 1 Please note that the figure is an example representation.

  • Page 173: Flush-Mounted In Metal

    Antennas 6.1 ANT 1 6.1.4 Flush-mounted in metal The tuning of the ANT 1 antenna is optimized for mounting in metal. a = 40 mm Figure 6-2 ANT 1 flush-mounted in metal 6.1.5 Minimum clearances Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected.
  • Page 174 Antennas 6.1 ANT 1 Minimum distances from antenna to antenna ≥ 300 mm Figure 6-3 Minimum distance ANT 1 ≥ 500 mm Figure 6-4 Face-to-face minimum distance ANT 1 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 175: Technical Specifications

    Antennas 6.1 ANT 1 6.1.6 Technical specifications     6GT2398-1CB00 Product type designation ANT 1   Electrical data Maximum write/read distance 140 mm ANT ↔ Transponder (S   Interfaces Plug connection M8, 4-pin (male)   Mechanical specifications Housing     • Material •...

  • Page 176: Dimension Drawing

    Antennas 6.2 ANT 3 6.1.7 Dimension drawing Figure 6-5 Dimensional drawing of ANT 1 (all values in mm) ANT 3 6.2.1 Features ANT 3 Characteristics Area of application Small assembly lines Writing/reading distance up to 50 mm (depending on the transponder) Connecting cable 3 m (plug-in antenna cable) Connectable readers RF250R...

  • Page 177: Ordering Data

    Antennas 6.2 ANT 3 6.2.2 Ordering data Table 6-2 Ordering data ANT 3 Antenna Article number ANT 3 6GT2398-1CD30-0AX0 (without antenna cable) ANT 3 6GT2398-1CD40-0AX0 (incl. one plug-in antenna cable 3 m) Table 6-3 Ordering data ANT 3 accessories Accessories Article number Antenna connecting cable 6GT2391-0AH30 drag-capable, 3 m...

  • Page 178: Mounting On/In Metal

    Antennas 6.2 ANT 3 Please note that the figure is an example representation. The values for L and S depend on the transponder type used and vary accordingly. You can find detailed information on this in the section "Field data of transponders and readers (Page 36)". 6.2.4 Mounting on/in metal The tuning of the ANT 3 antenna is optimized for mounting on metal.

  • Page 179: Minimum Spacing

    Antennas 6.2 ANT 3 6.2.5 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected. In this case, the data transmission time can increase unpredictably or a command is aborted with an error.

  • Page 180: Technical Data

    Antennas 6.2 ANT 3 6.2.6 Technical data     6GT2398-1CD30-0AX0 6GT2398-1CD40-0AX0 Product type designation ANT 3   Electrical data Maximum write/read distance 50 mm ANT ↔ Transponder (S   Interfaces Plug connection M8, 4-pin (female)   Mechanical specifications Housing     •...

  • Page 181: Dimension Drawing

    Antennas 6.3 ANT 3S 6.2.7 Dimension drawing Figure 6-11 Dimension drawing ANT 3 (all values in mm) ANT 3S 6.3.1 Features ANT 3S Characteristics Area of application Small assembly lines Writing/reading distance up to 4 mm (depending on the transponder) Connecting cable 3 m (plug-in antenna cable) Connectable readers RF250R...

  • Page 182: Ordering Data

    Antennas 6.3 ANT 3S 6.3.2 Ordering data Table 6-4 Ordering data ANT 3S Antenna Article number ANT 3S 6GT2398-1CD50-0AX0 (without antenna connecting cable) ANT 3S 6GT2398-1CD60-0AX0 (incl. one plug-in antenna connecting cable 3 m) Table 6-5 Ordering data ANT 3S accessories Accessories Article number Antenna connecting cable...

  • Page 183: Mounting On/In Metal

    Antennas 6.3 ANT 3S 6.3.4 Mounting on/in metal The tuning of the ANT 3S antenna is optimized for mounting on metal. ① ANT 3S ② Metal Figure 6-13 ANT 3S mounted on metal ① ANT 3S ② Metal = 10 mm Figure 6-14 ANT 3S flush-mounted in metal SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 184: Minimum Spacing

    Antennas 6.3 ANT 3S 6.3.5 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected. In this case, the data transmission time can increase unpredictably or a command is aborted with an error.

  • Page 185: Technical Data

    Antennas 6.3 ANT 3S 6.3.6 Technical data     6GT2398-1CD60-0AX0 6GT2398-1CD50-0AX0 Product type designation ANT 3S   Electrical data Maximum write/read distance 5 mm ANT ↔ Transponder (Sg)   Interfaces Plug connection M8, 4-pin (female)   Mechanical specifications Housing     • Material •...

  • Page 186: Dimension Drawing

    Antennas 6.4 ANT 8 6.3.7 Dimension drawing Figure 6-17 Dimension drawing ANT 3S (all values in mm) ANT 8 6.4.1 Features ANT 8 Characteristics Area of application Tool identification Writing/reading distance up to 4 mm (depending on the transponder) Connecting cable Connectable readers RF250R Degree of protection IP67...

  • Page 187: Transmission Window

    Antennas 6.4 ANT 8 Table 6-7 Ordering data ANT 8 accessories Accessories Article number Antenna connecting cable 6GT2391-0AH30 drag-capable, 3 m 6.4.3 Transmission window Length of the transmission window Operating distance between antenna and transponder Limit distance (limit distance is the maximum clear distance between the upper surface of the antenna and the transponder at which the transmission can still function under normal conditions).

  • Page 188: Flush-Mounted In Metal

    Antennas 6.4 ANT 8 6.4.4 Flush-mounted in metal Figure 6-19 ANT 8 flush-mounted in metal 6.4.5 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected.

  • Page 189: Technical Data

    Antennas 6.4 ANT 8 ≥ 50 mm Figure 6-21 Face-to-face distance between two ANT 8s 6.4.6 Technical data     6GT2398-1CF10 6GT2398-1CF00 Product type designation ANT 8   Electrical data Maximum write/read distance 5 mm ANT ↔ Transponder (S   Interfaces Plug connection M8, 4-pin (male)  ...

  • Page 190: Dimension Drawing

    Antennas 6.4 ANT 8     6GT2398-1CF10 6GT2398-1CF00   • During transportation and storage • -40 ... +85 °C Degree of protection according to EN 60529 IP67 Shock-resistant according to EN 60721-3-7 Class 7 500 m/s Vibration-resistant according to EN 60721-3-7 200 m/s Class 7 M2  ...

  • Page 191: Ant 12

    Antennas 6.5 ANT 12 ANT 12 6.5.1 Features ANT 12 Characteristics Area of application Tool identification Writing/reading distance up to 16 mm (depending on the transponder) Connecting cable 3 m or 0.6 m Connectable readers RF250R Degree of protection IP67 (front) 6.5.2 Ordering data Table 6-8...

  • Page 192: Transmission Window

    Antennas 6.5 ANT 12 6.5.3 Transmission window Length of the transmission window Operating distance between antenna and transponder Limit distance (limit distance is the maximum clear distance between the upper surface of the antenna and the transponder at which the transmission can still function under normal conditions). Figure 6-23 Transmission window ANT 12 Please note that the figure is an example representation.

  • Page 193: Minimum Spacing

    Antennas 6.5 ANT 12 6.5.5 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected. In this case, the data transmission time can increase unpredictably or a command is aborted with an error.

  • Page 194: Technical Data

    Antennas 6.5 ANT 12 6.5.6 Technical data     6GT2398-1CC00 6GT2398-1CC10 Product type designation ANT 12   Electrical data Maximum write/read distance 17 mm ANT ↔ Transponder (S   Interfaces Plug connection M8, 4-pin (male)   Mechanical specifications Housing     •...

  • Page 195: Dimension Drawing

    Antennas 6.6 ANT 18 6.5.7 Dimension drawing Figure 6-27 Dimension drawing ANT 12 (all values in mm) ANT 18 6.6.1 Features ANT 18 Characteristics Area of application Small assembly lines Writing/reading distance up to 35 mm (depending on the transponder) Connecting cable 3 m or 0.6 m Connectable readers RF250R...

  • Page 196: Transmission Window

    Antennas 6.6 ANT 18 6.6.3 Transmission window Length of the transmission window Operating distance between antenna and transponder Limit distance (limit distance is the maximum clear distance between the upper surface of the antenna and the transponder at which the transmission can still function under normal conditions). Figure 6-28 Transmission window ANT 18 Please note that the figure is an example representation.

  • Page 197: Flush-Mounted In Metal

    Antennas 6.6 ANT 18 6.6.4 Flush-mounted in metal = 10 mm = 10 mm Figure 6-29 ANT 18 flush-mounted in metal 6.6.5 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected.

  • Page 198: Technical Data

    Antennas 6.6 ANT 18 ≥ 100 mm Figure 6-31 Face-to-face distance between two ANT 18s 6.6.6 Technical data     6GT2398-1CA00 6GT2398-1CA10 Product type designation ANT 18   Electrical data Maximum write/read distance 35 mm ANT ↔ Transponder (S   Interfaces Plug connection M8, 4-pin (male)  ...

  • Page 199: Dimension Drawing

    Antennas 6.7 ANT 30     6GT2398-1CA00 6GT2398-1CA10 Shock-resistant according to EN 60721-3-7 Class 7 500 m/s Vibration-resistant according to EN 60721-3-7 200 m/s Class 7 M2   Design, dimensions and weight Dimensions (∅ x thread x L) M18 x 1 x 55 mm Thread (∅...

  • Page 200: Ordering Data

    Antennas 6.7 ANT 30 6.7.2 Ordering data Table 6-10 Ordering data ANT 30 Antenna Article number ANT 30 6GT2398-1CD00 (including one integrated antenna connecting cable 3 m) 6.7.3 Transmission window Length of the transmission window Operating distance between antenna and transponder Limit distance (limit distance is the maximum clear distance between the upper surface of the antenna and the transponder at which the transmission can still function under normal conditions).

  • Page 201: Flush-Mounted In Metal

    Antennas 6.7 ANT 30 6.7.4 Flush-mounted in metal = 20 mm = 20 mm Figure 6-34 ANT 30 flush-mounted in metal 6.7.5 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected.

  • Page 202: Technical Data

    Antennas 6.7 ANT 30 ≥ 200 mm Figure 6-36 Face-to-face distance between two ANT 30s 6.7.6 Technical data     6GT2398-1CD00 Product type designation ANT 30   Electrical data Maximum write/read distance 50 mm ANT ↔ Transponder (S   Interfaces Plug connection M8, 4-pin (male)  ...

  • Page 203: Dimension Drawing

    Antennas 6.7 ANT 30     6GT2398-1CD00 Shock-resistant according to EN 60721-3-7 Class 7 500 m/s Vibration-resistant according to EN 60721-3-7 200 m/s Class 7 M2   Design, dimensions and weight Dimensions (∅ x thread x L) M30 x 1.5 x 61 mm Thread (∅ x thread x L) M30 x 1.5 x 45 mm Weight 180 g...

  • Page 204: Ant 12 (Stainless Steel Variant)

    Antennas 6.8 ANT 12 (stainless steel variant) ANT 12 (stainless steel variant) 6.8.1 Features ANT 12 (stainless steel variant) Characteristics Area of application Tool identification Writing/reading distance Up to 16 mm (depending on the transponder) Connecting cable Plug-in 3 m Connectable readers RF250R Degree of protection IP67 with inserted cable...
  • Page 205 6.8 ANT 12 (stainless steel variant) CAUTION Minimum requirements for the antenna connecting cable We recommend that you use the antenna connecting cable "6GT2391-0AH30" from Siemens. Pay attention to the following minimum requirements if you want to configure an antenna cable yourself: •...

  • Page 206: Transmission Window

    Antennas 6.8 ANT 12 (stainless steel variant) 6.8.4 Transmission window Length of the transmission window Operating distance between antenna and transponder Limit distance (limit distance is the maximum clear distance between the upper surface of the antenna and the transponder at which the transmission can still function under normal conditions). Figure 6-38 Transmission window ANT 12 (stainless steel variant) Please note that the figure is an example representation.

  • Page 207: Flush-Mounted In Metal

    Antennas 6.8 ANT 12 (stainless steel variant) 6.8.5 Flush-mounted in metal a = 10 mm b = 10 mm Figure 6-39 ANT 12 (stainless steel variant) flush-mounted in metal 6.8.6 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected.

  • Page 208: Technical Data

    Antennas 6.8 ANT 12 (stainless steel variant) ≥ 100 mm Figure 6-41 Face-to-face minimum distance between two ANT 12 (stainless steel variant) 6.8.7 Technical data     6GT2398-1DC00 6GT2398-1DC10 Product type designation ANT 12 (stainless steel variant)   Electrical data Input voltage of the antenna max.
  • Page 209 Antennas 6.8 ANT 12 (stainless steel variant)     6GT2398-1DC00 6GT2398-1DC10   • During transportation and storage • -40 ... +85 °C Ambient conditions regarding UL approval • for indoor use only (dry location) • Degree of pollution 2 • Altitude < 2000 m •...

  • Page 210: Dimension Drawing

    Antennas 6.9 ANT 18 (stainless steel variant) 6.8.8 Dimension drawing ① The antenna connector may only be tightened by hand. ② The cable must be secured in front of/behind the support sleeve so that no bending strain can be transferred to the antenna connector. Figure 6-42 Dimension drawing ANT 12 (stainless steel variant) All dimensions in mm.

  • Page 211: Ordering Data

    Signal CAUTION Minimum requirements for the antenna connecting cable We recommend that you use the antenna connecting cable "6GT2391-0AH30" from Siemens. Pay attention to the following minimum requirements if you want to configure an antenna cable yourself: • Temperature: 80 ℃...

  • Page 212: Transmission Window

    Antennas 6.9 ANT 18 (stainless steel variant) 6.9.4 Transmission window Length of the transmission window Operating distance between antenna and transponder Limit distance (limit distance is the maximum clear distance between the upper surface of the antenna and the transponder at which the transmission can still function under normal conditions). Figure 6-43 Transmission window ANT 18 (stainless steel variant) Please note that the figure is an example representation.

  • Page 213: Flush-Mounted In Metal

    Antennas 6.9 ANT 18 (stainless steel variant) 6.9.5 Flush-mounted in metal a = 10 mm b = 10 mm Figure 6-44 ANT 18 (stainless steel variant) flush-mounted in metal 6.9.6 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected.

  • Page 214: Technical Data

    Antennas 6.9 ANT 18 (stainless steel variant) ≥ 100 mm Figure 6-46 Face-to-face minimum distance between two ANT 18 (stainless steel variant) 6.9.7 Technical data     6GT2398-1DA00 6GT2398-1DA10 Product type designation ANT 18 (stainless steel variant)   Electrical data Input voltage of the antenna max.
  • Page 215 Antennas 6.9 ANT 18 (stainless steel variant)     6GT2398-1DA00 6GT2398-1DA10   • During transportation and storage • -40 ... +85 °C Ambient conditions regarding UL approval • for indoor use only (dry location) • Degree of pollution 2 • Altitude < 2000 m •...

  • Page 216: Dimension Drawing

    Antennas 6.10 ANT 30 (stainless steel variant) 6.9.8 Dimension drawing ① The antenna connector may only be tightened by hand. ② The cable must be secured in front of/behind the support sleeve so that no bending strain can be transferred to the antenna connector. Figure 6-47 Dimension drawing ANT 18 (stainless steel variant) All dimensions in mm.

  • Page 217: Ordering Data

    Signal CAUTION Minimum requirements for the antenna connecting cable We recommend that you use the antenna connecting cable "6GT2391-0AH30" from Siemens. Pay attention to the following minimum requirements if you want to configure an antenna cable yourself: • Temperature: 80 ℃...

  • Page 218: Transmission Window

    Antennas 6.10 ANT 30 (stainless steel variant) 6.10.4 Transmission window Length of the transmission window Operating distance between antenna and transponder Limit distance (limit distance is the maximum clear distance between the upper surface of the antenna and the transponder at which the transmission can still function under normal conditions). Figure 6-48 Transmission window ANT 30 (stainless steel variant) Please note that the figure is an example representation.

  • Page 219: Flush-Mounted In Metal

    Antennas 6.10 ANT 30 (stainless steel variant) 6.10.5 Flush-mounted in metal a = 20 mm b = 20 mm Figure 6-49 ANT 30 (stainless steel variant) flush-mounted in metal 6.10.6 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected.

  • Page 220: Technical Data

    Antennas 6.10 ANT 30 (stainless steel variant) ≥ 200 mm Figure 6-51 Face-to-face minimum distance between two ANT 30 (stainless steel variant) 6.10.7 Technical data     6GT2398-1DD00 6GT2398-1DD10 Product type designation ANT 30 (stainless steel variant)   Electrical data Input voltage of the antenna max.
  • Page 221 Antennas 6.10 ANT 30 (stainless steel variant)     6GT2398-1DD00 6GT2398-1DD10   • During transportation and storage • -40 ... +85 °C Ambient conditions regarding UL approval • for indoor use only (dry location) • Degree of pollution 2 • Altitude < 2000 m •...

  • Page 222: Dimension Drawing

    Antennas 6.11 ANT D1 6.10.8 Dimension drawing ① The antenna connector may only be tightened by hand. ② The cable must be secured in front of/behind the support sleeve so that no bending strain can be transferred to the antenna connector. Figure 6-52 Dimension drawing ANT 30 (stainless steel variant) All dimensions in mm.

  • Page 223: Ordering Data

    Antennas 6.11 ANT D1 6.11.2 Ordering data Table 6-17 ANT D1 ordering data Antenna Article number ANT D1 6GT2698-5AC00 (incl. one plug-in antenna connecting cable 3.3 m) Table 6-18 Ordering data of ANT D1 accessories Accessories Article number Antenna connecting cable, 3.3 m 6GT2691-0CH33 6.11.3 Flush mounting on/in metal...
  • Page 224 Antennas 6.11 ANT D1 Minimum distances from antenna to antenna ≥ 600 mm with 2 antennas ≥ 800 mm with 3 antennas Figure 6-54 Minimum clearance ANT D1 ≥ 800 mm Figure 6-55 Face-to-face minimum clearance between two ANT D1 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 225: Technical Specifications

    Antennas 6.11 ANT D1 6.11.5 Technical specifications     6GT2698-5AC00 Product type designation ANT D1   Electrical data Maximum write/read distance 250 mm ANT ↔ Transponder (S Power rating (max.)   Interfaces Plug connection TNC socket, pins on antenna side   Mechanical specifications Housing  ...

  • Page 226: Dimension Drawing

    Antennas 6.12 ANT D5 6.11.6 Dimension drawing Figure 6-56 Dimension drawing ANT D1 (all values in mm) 6.12 ANT D5 6.12.1 Features ANT D5 Characteristics Area of application Storage, logistics and distribution Writing/reading distance up to 500 mm (depending on the transponder) Connecting cable 3.3 m Readers that can be connec‐...

  • Page 227: Transmission Window

    Antennas 6.12 ANT D5 Table 6-20 Ordering data of ANT D5 accessories Accessories Article number Antenna splitter 6GT2690-0AC00 (incl. one antenna connecting cable 3.3 m) Antenna cable Length 3.3 m 6GT2691-0CH33   Length 10.5 m 6GT2691-0CN10 Antenna extension cable, length 7.2 m 6GT2691-0DH72 6.12.3 Transmission window...

  • Page 228: Flush-Mounted In Metal

    Antennas 6.12 ANT D5 6.12.4 Flush-mounted in metal = 150 mm Figure 6-58 Metal-free area for ANT D5 6.12.5 Minimum spacing Note Extension of the data transmission time if distance values are undershot If the distance values specified in the tables are undershot, it is possible that the inductive fields will be affected.

  • Page 229: Technical Data

    Antennas 6.12 ANT D5 Minimum distances from antenna to antenna ≥ 1500 mm in conjunction with RF285R ≥ 2000 mm in conjunction with RF290R Figure 6-59 Minimum clearance ANT D5 6.12.6 Technical data     6GT2698-5AA10 Product type designation ANT D5   Electrical data Maximum write/read distance ANT ↔...
  • Page 230 Antennas 6.12 ANT D5     6GT2698-5AA10 Degree of protection to EN 60529 IP65 (UL: For indoor use only) Shock-resistant according to EN 60721-3-7 Class 7 300 m/s Vibration-resistant according to EN 60721-3-7 • 10 m/s (9 ... 200 Hz) Class 7 M2 • 15 m/s (200 ...

  • Page 231: Dimension Drawing

    Antennas 6.12 ANT D5 6.12.7 Dimension drawing Figure 6-60 Dimension drawing for ANT D5 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 232: Ant D6

    Antennas 6.13 ANT D6 6.13 ANT D6 6.13.1 Features ANT D6 Characteristics Area of application • Storage, logistics and distribution • Suitable for high-speed applications with large writing/reading distance Writing/reading distance up to 650 mm (depending on the trans‐ ponder) Connecting cable 3.3 m;...

  • Page 233: Transmission Window

    Antennas 6.13 ANT D6 6.13.3 Transmission window = 520 mm = 420 mm Figure 6-61 Transmission window for ANT D6 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 234: Metal-Free Area

    Antennas 6.13 ANT D6 6.13.4 Metal-free area Flush-mounted in metal Figure 6-62 Metal-free area for ANT D6 6.13.5 Minimum distance Minimum distances from antenna to antenna Distance D ¡ˆ 2 m ≥ 1500 mm in conjunction with RF285R ≥ 2000 mm in conjunction with RF290R Figure 6-63 Minimum clearance ANT D6 SIMATIC RF200...

  • Page 235: Technical Data

    Antennas 6.13 ANT D6 6.13.6 Technical data     6GT2698-5AB00 Product type designation ANT D6   Electrical data Maximum write/read distance ANT ↔ transponder 650 mm   Interfaces Plug connection 1-pin TNC plug   Mechanical specifications Housing     • Material •...

  • Page 236: Dimensional Diagram

    Antennas 6.13 ANT D6 6.13.7 Dimensional diagram M6 threaded bush Figure 6-64 Dimension drawing for ANT D6 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 237: Ant D10

    Antennas 6.14 ANT D10 6.14 ANT D10 6.14.1 Features ANT D10 Characteristics Area of application • Storage, logistics and distribution, e.g. clothing industry, laun‐ dries • Particularly when small MDS are used (e.g. MDS D124, MDS D160) and when there is a long transmission field Writing/reading distance up to 480 mm (depending on the transponder) Connecting cable...

  • Page 238: Transmission Window

    Antennas 6.14 ANT D10 6.14.3 Transmission window 1050 mm 350 mm Figure 6-65 Transmission window for ANT D10 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 239: Metal-Free Area

    Antennas 6.14 ANT D10 6.14.4 Metal-free area Flush-mounted in metal Figure 6-66 Metal-free area for ANT D10 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 240: Minimum Distance

    Antennas 6.14 ANT D10 6.14.5 Minimum distance Minimum distances from antenna to antenna Distance D ¡ˆ 2 m ≥ 2000 mm in conjunction with RF290R Figure 6-67 Minimum clearance ANT D10 6.14.6 Technical data     6GT2698-5AF00 Product type designation ANT D10   Electrical data Maximum write/read distance ANT ↔...
  • Page 241 Antennas 6.14 ANT D10     6GT2698-5AF00 Shock-resistant according to EN 60721-3-7 Class 7 300 m/s Vibration-resistant according to EN 60721-3-7 • 10 m/s (9 ... 200 Hz) Class 7 M2 • 15 m/s (200 ... 500 Hz)   Design, dimensions and weight Dimensions (L x W x H) 1150 x 365 x 115 mm (with cover) Weight...

  • Page 242: Dimensional Diagram

    Antennas 6.14 ANT D10 6.14.7 Dimensional diagram MOBY D Figure 6-68 Dimension drawing for ANT D10 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 243: Transponder

    Transponder Memory configuration of ISO the transponders Figure 7-1 Memory configuration of ISO the transponders Memory areas Depending on the manufacturer of the transponder chip, the memory configuration of an ISO transponder consists of varying sizes of user memory. The typical sizes are 112 bytes, 256 bytes, 992 bytes EEPROM or 2000 bytes, 8192 bytes FRAM.

  • Page 244: Mds D100

    Transponder 7.2 MDS D100 This UID is transferred as an 8 byte value through a read command to address FFF0 with a length of 8. Note OPT memory The transponders have an OTP memory. This was previously only supported by the RF300 readers.

  • Page 245: Metal-Free Area

    Transponder 7.2 MDS D100 7.2.3 Metal-free area Direct mounting of the transponder on metal is not permitted. A distance of ≥ 20 mm is recommended to avoid a reduced read/write range and a reduction of the field data. This can be accomplished, for example, by installing a spacer. Note that if the distances (a and h) are not observed, this may result in a reduction of the field data as well as a reduced write/read range.

  • Page 246: Flush Mounting

    Transponder 7.2 MDS D100 Flush-mounting ① Transponder ② Metal ③ Non-metal ≥ 20 mm ≥ 20 mm Figure 7-3 Flush installation of the MDS D100 / D200 / D400 in metal with spacer 7.2.4 Technical data Table 7-3 Technical specifications for MDS D100    ...
  • Page 247 Transponder 7.2 MDS D100     6GT2600-0AD10 Enclosure     • Material •   • Color • White/black Recommended distance to metal ≥ 20 mm Power supply Inductive, without battery   Permitted ambient conditions Ambient temperature     • during write/read access •...

  • Page 248: Dimension Drawing

    Transponder 7.3 MDS D117 7.2.5 Dimension drawing   Dimensions in mm Dimensions for mounting holes Figure 7-4 MDS D100 dimension drawing MDS D117 7.3.1 Features MDS D117 Characteristics   Area of application Very compact data carrier that can be cemented into objects where precise positioning is necessary;...

  • Page 249: Ordering Data

    Transponder 7.3 MDS D117 7.3.2 Ordering data Table 7-4 Ordering data for MDS D117   Article number MDS D117 6GT2600-0AG00 Pack of 10 7.3.3 Mounting in metal Flush-mounted in metal ① Transponder ② Metal Figure 7-5 Flush-mounting of MDS D117 in metal without clearance 7.3.4 Technical specifications Table 7-5...
  • Page 250 Transponder 7.3 MDS D117     6GT2600-0AG00 Data retention time (at < 40 ℃) > 10 years Write/read distance (S Dependent on the reader used, see section "Field data (Page 37)"   Mechanical specifications Enclosure     • Material •   • Color •...

  • Page 251: Dimension Drawing

    Transponder 7.4 MDS D124 7.3.5 Dimension drawing Figure 7-6 Dimensions in mm MDS D124 7.4.1 Characteristics MDS D124 Characteristics Area of application Areas of application in production automation Can also be used in harsh environments under extreme environmental conditions (e.g. temperature stress up to +180 °C).

  • Page 252: Mounting On Metal

    Transponder 7.4 MDS D124 7.4.3 Mounting on metal Direct mounting of the transponder on metal is not permitted. A distance of ≥ 20 mm is recommended to avoid a reduced read/write range and a reduction of the field data. This can be accomplished, for example, by installing a spacer. Note that if the distances (a and h) are not observed, this may result in a reduction of the field data as well as a reduced write/read range.

  • Page 253: Using The Mds D124 In Hazardous Areas

    Transponder 7.4 MDS D124 7.4.4 Using the MDS D124 in hazardous areas The transponder MDS D124, device group II, category 1G or 1D may be installed and operated in zones 0, 1 and 2 or in the zones 20, 21 and 22. The following requirements of the 2014/34/EU directive are met: •...

  • Page 254: Electrical Data

    Transponder 7.4 MDS D124 WARNING Installation and operating conditions for hazardous areas • The device may not be used in areas influenced by processes that generate high electrostatic charges. • The device must be installed in such a way that it is mechanically protected. •...

  • Page 255: Technical Specifications

    Transponder 7.4 MDS D124 The surface temperature of the MDS D124 transponder for hazardous areas for dust depends on the ambient temperature range: Table 7-10 Temperature classes for hazardous areas for dust Ambient temperature of the transponder Permitted surface tem‐ perature RF210R, RF220R, RF240R, RF250R RF380R (incl.

  • Page 256: Ec Declaration Of Conformity According To Directive 2014/34/Eu Mds D124

    Transponder 7.4 MDS D124     6GT2600-0AC10   • during write/read access • -25 … +140 °C • from +125 ℃: 20% reduction in the limit dis‐ tance   • outside the read/write field • -40 … +180 °C • at +180 ℃: Tested up to 5000 hours or 3000 cy‐ cles  ...

  • Page 257: Dimension Drawing

    The manufacturing plant of the MDS D124 has an ATEX quality assurance system recognized by DEKRA EXAM GmbH with notification number "BVS 11 ATEX ZQS/E111". Manufacturer's address - distributor Manufacturer's address - factory Siemens AG Siemens AG DE – 76181 Karlsruhe, Germany Würzburger Str. 121 DE - 90766 Fürth, Germany...

  • Page 258: Ordering Data

    Transponder 7.5 MDS D126 7.5.2 Ordering data Table 7-12 Ordering data for MDS D126   Article number MDS D126 6GT2600-0AE00 Table 7-13 Ordering data for MDS D126 accessories   Article number Spacer 6GT2690-0AL00 7.5.3 Mounting on metal Direct mounting of the transponder on metal is not permitted. A distance of ≥ 20 mm is recommended to avoid a reduced read/write range and a reduction of the field data.

  • Page 259: Technical Specifications

    Transponder 7.5 MDS D126 Flush-mounted in metal h ≥ 25 mm ≥ 50 mm Figure 7-12 Flush installation of the MDS D126 / D426 / D526 in metal with spacer 7.5.4 Technical specifications Table 7-14 Technical specifications for the MDS D126    ...

  • Page 260: Dimension Drawing

    Transponder 7.5 MDS D126     6GT2600-0AE00 Ambient temperature     • during write/read access • -25 … +85 °C   • outside the read/write field • -40 … +100 °C   • during storage • -40 … +100 °C Degree of protection according to EN 60529 IP68 2 hours, 2 bar, +20 °C Shock-resistant acc.

  • Page 261: Mds D127

    Transponder 7.6 MDS D127 MDS D127 7.6.1 Features MDS D127 Characteristics   Area of application Very compact data carrier that can be screwed into areas where precise positioning is necessary; e.g. tool identification, workpiece holders etc. Memory size 112 bytes of EEPROM user memory Write/read range See section "Field data (Page 37)"...

  • Page 262: Mounting In Metal

    Transponder 7.6 MDS D127 7.6.3 Mounting in metal Flush-mounted in metal ① Metal ② Transponders Figure 7-14 Flush-mounting of MDS D127 in metal without clearance Note Damage to the transponder due to improper mounting To screw the MDS D127 into a suitable thread, use the supplied screw-in tool. This avoids damage to the MDS D127.

  • Page 263: Technical Specifications

    Transponder 7.6 MDS D127 7.6.4 Technical specifications Table 7-16 Technical specifications for MDS D127     6GT2600-0AF00 Product type designation SIMATIC MDS D127   Memory Memory configuration     • • 8 bytes   • User memory • 112 bytes EEPROM   •...

  • Page 264: Dimension Drawing

    Transponder 7.6 MDS D127     6GT2600-0AF00 Type of mounting • Glued • 1 x M3 screw     Standards, specifications, approvals MTBF 228 years The values for shock and vibration are maximum values and must not be applied continuously.  The processing instructions of the adhesive manufacturer must be observed. 7.6.5 Dimension drawing Figure 7-16...

  • Page 265: Mds D139

    Transponder 7.7 MDS D139 MDS D139 7.7.1 Characteristics MDS D139 Characteristics Area of application Applications in production automation and in assembly lines subject to thermal stress (up to +220 °C) Typical application areas: • Paintshops and their preparatory treatments) • Primer coat, electrolytic dip area, cataphoresis with the associated drying furnaces •...

  • Page 266: Flush Mounting

    Transponder 7.7 MDS D139 Note that if the distances (a and h) are not observed, this may result in a reduction of the field data as well as a reduced write/read range. Mounting on metal ≥ 30 mm Figure 7-17 Mounting the MDS D139 / D339 on metal with spacer Flush-mounting ≥...

  • Page 267: Cleaning The Transponder

    Transponder 7.7 MDS D139 7.7.4 Cleaning the transponder NOTICE Cleaning the transponder in normal operation Do not clean the transponder with mechanical tools, sand-blasting or pressure hose. These cleaning methods result in damage to the transponder. Clean the transponder only with the chemical cleansing agents listed in the section "Chemical resistance of the reader and transponders (Page 96)".
  • Page 268 Transponder 7.7 MDS D139 WARNING Information to be observed during installation, commissioning, operation, cleaning and disassembly Installations- und Betriebsbedingungen für den explosionsgefährdeten Bereich: a) Der Einsatz des Gerätes in der Nähe von stark ladungserzeugenden Prozessen ist untersagt. b) Das Gerät ist mechanisch geschützt zu montieren. c) Die Montage muss auf einem geerdeten, leitenden Untergrund erfolgen.

  • Page 269: Use In Hazardous Areas For Gasses

    Transponder 7.7 MDS D139 7.7.5.1 Use in hazardous areas for gasses The temperature class of the transponder for gas explosion hazardous areas depends on the ambient temperature range as well as the existing reader power or the field strength at the antenna within the explosion hazardous area.

  • Page 270: Use In Hazardous Areas For Dusts

    Transponder 7.7 MDS D139 7.7.5.2 Use in hazardous areas for dusts As intrinsically safe equipment, the transponder is suitable for complete dust covering. In this case, the ignition temperature specified here according to EN IEC 60079-0:2018 in accordance with ignition protection type ia refers to the maximum surface temperature of the transponder for flammable lint (ia IIIA) and non-conductive dusts (ia IIIB).
  • Page 271 Transponder 7.7 MDS D139     6GT2600-0AA10   • User memory • 112 bytes EEPROM   • OTP memory • 16 bytes (EEPROM) Read cycles (at < 40 ℃) > 10 Write cycles (at < 40 ℃) > 10 Data retention time (at < 40 ℃) >...

  • Page 272: Dimension Drawings

    Transponder 7.7 MDS D139     6GT2600-0AA10     Standards, specifications, approvals MTBF 228 years The values for shock and vibration are maximum values and must not be applied continuously. A combination of high application temperatures together with high shock or vibration values is not possible.

  • Page 273: Mds D160

    Transponder 7.8 MDS D160 MDS D160 7.8.1 Characteristics MDS D160 Characteristics   Area of application The transponder can also be deployed under extreme envi‐ ronmental conditions without problems due to its rugged de‐ sign. It is washable, heat-resistant and resistant to all chemi‐ cals generally used in the laundry process.

  • Page 274: Technical Specifications

    Transponder 7.8 MDS D160 Mounting on metal ① Transponder ② Metal carrier ③ Spacer ≥ 10 mm Figure 7-20 Mounting the MDS D160 / D460 / D560 on metal with spacer 7.8.4 Technical specifications Table 7-24 Technical specifications for the MDS D160  ...
  • Page 275 Transponder 7.8 MDS D160     6GT2600-0AB10   Permitted ambient conditions Ambient temperature     • during write/read access • -25 ... +85 °C   • outside the read/write field • -40 … +175 °C • from +125 ℃: for 1000 hours, 20% reduction of the limit distance •...

  • Page 276: Dimension Drawings

    Transponder 7.9 MDS D165 7.8.5 Dimension drawings Dimensional drawing of MDS D160 Dimensions in mm   Figure 7-21 Dimensional drawing of MDS D160 MDS D165 7.9.1 Features MDS D165 Characteristics   Area of application The design of the transponder (self-adhesive label) per‐ mits a variety of designs, guaranteeing optimum di‐ mensioning for the widest variety of applications.

  • Page 277: Technical Data

    Transponder 7.9 MDS D165 Type of delivery Minimum order quantity: 1250 units (5 rolls with 250 units each) 7.9.3 Technical data Table 7-26 Technical specifications for MDS D165     6GT2600-1AB00-0AX0 Product type designation SIMATIC MDS D165   Memory Memory configuration    ...

  • Page 278: Dimension Drawing

    Transponder 7.10 MDS D200     6GT2600-1AB00-0AX0 Dimensions (L x W x H) 86 x 54 x 0.3 mm Weight Type of mounting Glued with self-adhesive label     Standards, specifications, approvals MTBF 228 years The processing instructions of the adhesive manufacturer must be observed. 7.9.4 Dimension drawing Dimensions in mm...

  • Page 279: Ordering Data

    Transponder 7.10 MDS D200 7.10.2 Ordering data Table 7-27 Ordering data for MDS D200   Article number MDS D200 6GT2600-1AD00-0AX0 Table 7-28 Ordering data for MDS D200 accessories   Article number Spacer 6GT2190-0AA00 (in conjunction with fixing pocket 6GT2190-0AB00) Fixing pocket 6GT2190-0AB00 (in conjunction with spacer 6GT2190-0AA00) Fixing pocket...

  • Page 280: Flush Mounting

    Transponder 7.10 MDS D200 Mounting on metal ① Transponder ② Metal ③ Non-metal ≥ 20 mm Figure 7-23 Mounting the MDS D100 / D200 / D400 on metal with spacer Flush-mounting ① Transponder ② Metal ③ Non-metal ≥ 20 mm ≥ 20 mm Figure 7-24 Flush installation of the MDS D100 / D200 / D400 in metal with spacer SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 281: Technical Data

    Transponder 7.10 MDS D200 7.10.4 Technical data Table 7-29 Technical specifications for MDS D200     6GT2600-1AD00-0AX0 Product type designation SIMATIC MDS D200   Memory Memory configuration     • • 8 bytes   • User memory • 256 bytes EEPROM   • OTP memory •...

  • Page 282: Dimension Drawing

    Transponder 7.11 MDS D261     6GT2600-1AD00-0AX0     Standards, specifications, approvals MTBF 228 years The values for shock and vibration are maximum values and must not be applied continuously. The processing instructions of the adhesive manufacturer must be observed. 7.10.5 Dimension drawing Dimensions in mm Figure 7-25...

  • Page 283: Ordering Data

    Transponder 7.11 MDS D261 7.11.2 Ordering data Table 7-30 Ordering data for MDS D261   Article number MDS D261 6GT2600-1AA00-0AX0 Type of delivery Minimum order quantity: 1250 units (5 rolls with 250 units each) 7.11.3 Technical data Table 7-31 Technical specifications of MDS D261  ...

  • Page 284: Dimension Drawing

    Transponder 7.11 MDS D261     6GT2600-1AA01-0AX0   • during write/read access • -20 ... +60 °C   • outside the read/write field • -20 … +85 °C   • During transportation and storage • +20 to +30 ℃ Can be stored for 2 years, determined by the dura‐ bility of the adhesive Degree of protection IP65...

  • Page 285: Mds D324

    Transponder 7.12 MDS D324 7.12 MDS D324 7.12.1 Characteristics MDS D324 Characteristics Area of application Areas of application in production automation and prod‐ uct identification Can also be used in harsh environments under extreme environmental conditions (e.g. temperature stress up to +125 °C). Memory size 992 bytes of EEPROM user memory Write/read range...

  • Page 286: Technical Specifications

    Transponder 7.12 MDS D324 Mounting on metal ≥ 15 mm Figure 7-27 Mounting the MDS D124 / D324 / D424 / D524 on metal with spacer Flush-mounting ≥ 15 mm ≥ 25 mm Figure 7-28 Flush installation of the MDS D124 / D324 / D424 / D524 in metal with spacer 7.12.4 Technical specifications Table 7-34...
  • Page 287 Transponder 7.12 MDS D324     6GT2600-3AC00   • • 8 bytes   • User memory • 992 bytes EEPROM   • OTP memory • 16 bytes (EEPROM) Read cycles (at < 40 ℃) > 10 Write cycles (at < 40 ℃) >...

  • Page 288: Dimension Drawing

    Transponder 7.13 MDS D339 7.12.5 Dimension drawing Figure 7-29 Dimension drawing of MDS D324 All dimensions in mm 7.13 MDS D339 7.13.1 Characteristics MDS D339 Characteristics Area of application Applications in production automation and in assembly lines subject to thermal stress (up to +220 °C) Typical application areas: •...

  • Page 289: Mounting On Metal

    Transponder 7.13 MDS D339 Table 7-36 Ordering data for MDS D339 accessories   Article number Spacer 6GT2690-0AA00 Quick change holder 6GT2690-0AH00 (Ø x H): 22 x 60 mm Quick change holder 6GT2690-0AH10 (Ø x H): 22 x 47 mm 7.13.3 Mounting on metal Direct mounting of the transponder on metal is not permitted.

  • Page 290: Cleaning The Transponder

    Transponder 7.13 MDS D339 Flush-mounting ≥ 30 mm ≥ 100 mm Figure 7-31 Flush installation of the MDS D139 / D339 in metal with spacer Note Reduction of the range with mounting in metal It is possible to mount the MDS D139/D339 in metal. Note that with large antennas (e.g. ANT D5), this leads to reduced write/read ranges.

  • Page 291: Use In Hazardous Areas

    Transponder 7.13 MDS D339 7.13.5 Use in hazardous areas TÜV NORD CERT GmbH, appointed center no. 0044 as per Article 18 of the directive of the European Council of 26 February 2014 (2014/34/EU), has confirmed the compliance with the essential health and safety requirements relating to the design and construction of equipment and protective systems intended for use in hazardous areas as per Annex II of the directive.

  • Page 292: Use In Hazardous Areas For Gasses

    Transponder 7.13 MDS D339 Identification The identification is as follows: II 1 G Ex ia IIC T6 ... T2 Ga 0158 II 1 D Ex ia IIIB T100°C / T135°C / T185°C Da TÜV 18 ATEX 232450 X 7.13.5.1 Use in hazardous areas for gasses The temperature class of the transponder for gas explosion hazardous areas depends on the ambient temperature range as well as the existing reader power or the field strength at the antenna within the explosion hazardous area.

  • Page 293: Use In Hazardous Areas For Dusts

    Transponder 7.13 MDS D339 7.13.5.2 Use in hazardous areas for dusts As intrinsically safe equipment, the transponder is suitable for complete dust covering. In this case, the ignition temperature specified here according to EN IEC 60079-0:2018 in accordance with ignition protection type ia refers to the maximum surface temperature of the transponder for flammable lint (ia IIIA) and non-conductive dusts (ia IIIB).
  • Page 294 Transponder 7.13 MDS D339     6GT2600-3AA10   • User memory • 992 bytes EEPROM   • OTP memory • 16 bytes (EEPROM) Read cycles (at < 40 ℃) > 10 Write cycles (at < 40 ℃) > 10 Data retention time (at < 40 ℃) >...

  • Page 295: Dimensional Drawing

    Transponder 7.13 MDS D339     6GT2600-3AA10     Standards, specifications, approvals MTBF 228 years The values for shock and vibration are maximum values and must not be applied continuously. A combination of high application temperatures together with high shock or vibration values is not possible.

  • Page 296: Mds D400

    Transponder 7.14 MDS D400 7.14 MDS D400 7.14.1 Features MDS D400 Characteristics Area of application From simple identification such as electronic barcode replacement/supplementation, through warehouse and distribution logistics, right up to product identifica‐ tion. Memory size 2000 bytes of FRAM user memory Write/read range See section "Field data (Page 37)"...
  • Page 297 Transponder 7.14 MDS D400 Mounting on metal ① Transponder ② Metal ③ Non-metal ≥ 20 mm Figure 7-33 Mounting the MDS D100 / D200 / D400 on metal with spacer Flush-mounting ① Transponder ② Metal ③ Non-metal ≥ 20 mm ≥ 20 mm Figure 7-34 Flush installation of the MDS D100 / D200 / D400 in metal with spacer SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 298: Technical Specifications

    Transponder 7.14 MDS D400 7.14.4 Technical specifications Table 7-42 Technical specifications for MDS D400     6GT2600-4AD00 Product type designation SIMATIC MDS D400   Memory Memory configuration     • • 8 bytes   • User memory • 2000 bytes FRAM   • OTP memory •...

  • Page 299: Dimension Drawing

    Transponder 7.14 MDS D400     6GT2600-4AD00     Standards, specifications, approvals MTBF 228 years The values for vibration are maximum values and must not be applied continuously. The processing instructions of the adhesive manufacturer must be observed. 7.14.5 Dimension drawing Figure 7-35 Dimensional drawing MDS D400 (dimensions in mm) SIMATIC RF200...

  • Page 300: Mds D421

    Transponder 7.15 MDS D421 7.15 MDS D421 7.15.1 Characteristics MDS D421 Characteristics   Area of application Constructed for tool coding according to DIN 69873. It can be used wherever small data storage media and exact positioning are required,  e.g. tool identification, workpiece holders. The rugged enclosure of the transponder means that it can also be used in a harsh industrial environment without prob‐...

  • Page 301: Installation Instruction

    Transponder 7.15 MDS D421 Flush-mounting Figure 7-37 Flush-mounting of MDS D421 / D521 in metal without clearance Flush-mounting of the MDS in metal with tools 0.5 x 45° 0.3 x 45° or R0.3 10 (-0.04... -0.13) 10 (+0.09... 0) 4.5 (-0 ... -0.1) 4.6 (+0.2 ...

  • Page 302: Installation Examples

    Transponder 7.15 MDS D421 • Remove residues of adhesive • Allow to cure according to the manufacturer's instructions • Flush-mounting of the transponder in metal with tools Installation examples Figure 7-39 Installation example of MDS D421/D521/E623 in a steep cone Figure 7-40 Installation example of MDS D421/D521/E623 in a stud bolt 7.15.4 Technical specifications Table 7-44...
  • Page 303 Transponder 7.15 MDS D421     6GT2600-4AE00   • Material • Epoxy resin   • Color • Black Recommended distance to metal ≥ 0 mm Power supply Inductive, without battery   Permitted ambient conditions Ambient temperature     • during write/read access •...

  • Page 304: Dimension Drawing

    Transponder 7.16 MDS D422 7.15.5 Dimension drawing Figure 7-41 Dimension drawing of MDS D421 All dimensions in mm 7.16 MDS D422 7.16.1 Characteristics MDS D422 Characteristics Area of application Identification of metallic workpiece holders, workpieces or containers Memory size 2000 bytes of FRAM user memory Write/read range See section "Field data (Page 37).

  • Page 305: Mounting In Metal

    Transponder 7.16 MDS D422 7.16.3 Mounting in metal Flush-mounting Figure 7-42 Flush-mounting of MDS D422 / D522 in metal without clearance Mounting information for screws You can screw the transponder into a pre-drilled threaded hole using the screw-in aid. Mounting information for adhesion •...
  • Page 306 Transponder 7.16 MDS D422     6GT2600-4AF00   • OTP memory • 16 bytes FRAM Read cycles (at < 40 ℃) > 10 Write cycles (at < 40 ℃) > 10 Data retention time (at < 40 ℃) > 10 years Write/read distance (S Dependent on the reader used, see section "Field data (Page 37)"...

  • Page 307: Dimension Drawing

    Transponder 7.17 MDS D423 7.16.5 Dimension drawing Dimensions in mm Figure 7-43 Dimensional drawing of MDS D422 7.17 MDS D423 7.17.1 Characteristics MDS D423 Characteristics Area of application Identification of metallic workpiece holders, workpieces or containers, production automation Memory size 2000 bytes of FRAM user memory Write/read range See section "Field data (Page 37)"...

  • Page 308: Mounting On Metal

    Transponder 7.17 MDS D423 7.17.3 Mounting on metal Note that if the distance (a) is not observed, this may result in a reduction of the field data as well as a reduced write/read range. Mounting on metal Figure 7-44 Mounting the MDS D423 on metal Mounting in metal ≥...

  • Page 309: Technical Specifications

    Transponder 7.17 MDS D423 Figure 7-46 Flush-mounting of the MDS D423 in metal without clearance Note Reduction of the write/read range Note that when the device is flush-mounted in metal without a surrounding clearance ≥ 10 mm, the write/read range and the field data are reduced. 7.17.4 Technical specifications Table 7-49...
  • Page 310 Transponder 7.17 MDS D423     6GT2600-4AA00   Permitted ambient conditions Ambient temperature     • during write/read access • -25 … +85 °C   • outside the read/write field • -40 … +100 °C   • during storage • -40 … +100 °C Degree of protection according to EN 60529 •...

  • Page 311: Dimensional Drawing

    Transponder 7.18 MDS D424 7.17.5 Dimensional drawing Dimensions in mm Figure 7-47 Dimension drawing for MDS D423 7.18 MDS D424 7.18.1 Characteristics MDS D424 Characteristics Area of application Production automation as well use in assembly and manufacturing lines Memory size 2000 bytes of FRAM user memory Write/read range See section "Field data (Page 37)."...

  • Page 312: Mounting On Metal

    Transponder 7.18 MDS D424 Table 7-51 Ordering data of MDS D424 accessories   Article number Spacer 6GT2690-0AK00 7.18.3 Mounting on metal Direct mounting of the transponder on metal is not permitted. A distance of ≥ 20 mm is recommended to avoid a reduced read/write range and a reduction of the field data. This can be accomplished, for example, by installing a spacer.

  • Page 313: Technical Specifications

    Transponder 7.18 MDS D424 Flush-mounting ≥ 15 mm ≥ 25 mm Figure 7-49 Flush installation of the MDS D124 / D324 / D424 / D524 in metal with spacer 7.18.4 Technical specifications Table 7-52 Technical specifications for the MDS D424     6GT2600-4AC00 Product type designation SIMATIC MDS D424...

  • Page 314: Dimension Drawing

    Transponder 7.18 MDS D424     6GT2600-4AC00   Permitted ambient conditions Ambient temperature     • during write/read access • -25 … +85 °C   • outside the read/write field • -40 … +100 °C   • during storage • -40 … +100 °C Degree of protection according to EN 60529 •...

  • Page 315: Mds D425

    Transponder 7.19 MDS D425 7.19 MDS D425 7.19.1 Characteristics MDS D425 Characteristics   Area of application Compact and rugged ISO transponder for screw mounting Use in assembly and production lines in the powertrain sector; ideal for mounting on motors, gearboxes, and workpiece hold‐ Can also be deployed under extreme environmental condi‐...

  • Page 316: Application Example

    Transponder 7.19 MDS D425 7.19.3 Application example Figure 7-51 Application example 7.19.4 Technical specifications Table 7-54 Technical specifications for the MDS D425     6GT2600-4AG00 Product type designation SIMATIC MDS D425   Memory Memory configuration     • • 8 bytes   • User memory •...
  • Page 317 Transponder 7.19 MDS D425     6GT2600-4AG00   • Color • Black Recommended distance to metal ≥ 0 mm Power supply Inductive, without battery   Permitted ambient conditions Ambient temperature     • during write/read access • -25 … +85 °C   •...

  • Page 318: Dimension Drawing

    Transponder 7.20 MDS D426 7.19.5 Dimension drawing Dimensions in mm Figure 7-52 Dimension drawing of MDS D425 7.20 MDS D426 7.20.1 Characteristics MDS D426 Characteristics Area of application Compact and rugged ISO transponder, suitable for iden‐ tification of transport units in production-related logis‐ tics.

  • Page 319: Ordering Data

    Transponder 7.20 MDS D426 7.20.2 Ordering data Table 7-55 Ordering data of MDS D426   Article number MDS D426 6GT2600-4AH00 Table 7-56 Ordering data of MDS D426 accessories   Article number Spacer 6GT2690-0AL00 7.20.3 Mounting on metal Direct mounting of the transponder on metal is not permitted. A distance of ≥ 20 mm is recommended to avoid a reduced read/write range and a reduction of the field data.

  • Page 320: Flush-Mounted In Metal

    Transponder 7.20 MDS D426 Flush-mounted in metal h ≥ 25 mm ≥ 50 mm Figure 7-54 Flush installation of the MDS D126 / D426 / D526 in metal with spacer 7.20.4 Technical specifications Table 7-57 Technical specifications for the MDS D426    ...

  • Page 321: Dimension Drawing

    Transponder 7.20 MDS D426     6GT2600-4AH00 Ambient temperature     • during write/read access • -25 … +85 °C   • outside the read/write field • -40 … +100 °C   • during storage • -40 … +100 °C Degree of protection according to EN 60529 IP68 2 hours, 2 bar, +20 °C Shock-resistant according to IEC 68-2-27...

  • Page 322: Mds D428

    Transponder 7.21 MDS D428 7.21 MDS D428 7.21.1 Characteristics MDS D428 Characteristics   Area of application Compact and rugged ISO transponder for screw mounting Use in assembly and production lines in the powertrain sector Can also be deployed under extreme environmental condi‐ tions without problems due to the rugged design.

  • Page 323: Application Example

    Transponder 7.21 MDS D428 7.21.3 Application example Figure 7-56 Application example 7.21.4 Technical specifications Table 7-59 Technical specifications for the MDS D428     6GT2600-4AK00 Product type designation SIMATIC MDS D428   Memory Memory configuration     • • 8 bytes   • User memory •...
  • Page 324 Transponder 7.21 MDS D428     6GT2600-4AK00   • Color • Black Recommended distance to metal ≥ 0 mm Power supply Inductive, without battery   Permitted ambient conditions Ambient temperature     • during write/read access • -25 … +85 °C   •...

  • Page 325: Dimension Drawing

    Transponder 7.22 MDS D460 7.21.5 Dimension drawing SW 22 +0.5 Dimensions in mm Figure 7-57 Dimension drawing of MDS D428 7.22 MDS D460 7.22.1 Characteristics MDS D460 Characteristics   Area of application Identification in small assembly lines Can also be used in a harsh industrial environment without problem Memory size 2000 bytes of FRAM user memory...

  • Page 326: Ordering Data

    Transponder 7.22 MDS D460 7.22.2 Ordering data Table 7-60 Ordering data of MDS D460   Article number MDS D460 6GT2600-4AB00 Table 7-61 Ordering data of MDS D460 accessories   Article number Spacer 6GT2690-0AG00 Corner mounting bracket 6GT2690-0AN00 7.22.3 Mounting on metal Note that if the distance (h) is not observed, this may result in a reduction of the field data as well as a reduced write/read range.

  • Page 327: Technical Specifications

    Transponder 7.22 MDS D460 7.22.4 Technical specifications Table 7-62 Technical specifications for MDS D460     6GT2600-4AB00 Product type designation SIMATIC MDS D460   Memory Memory configuration     • • 8 bytes   • User memory • 2000 bytes FRAM   • OTP memory •...

  • Page 328: Dimension Drawings

    Transponder 7.23 MDS D521     6GT2600-4AB00     Standards, specifications, approvals MTBF 228 years The values for shock and vibration are maximum values and must not be applied continuously. The processing instructions of the adhesive manufacturer must be observed. 7.22.5 Dimension drawings Dimensional drawing of MDS D460 Dimensions in mm...

  • Page 329: Ordering Data

    Transponder 7.23 MDS D521 7.23.2 Ordering data Table 7-63 Ordering data for MDS D521   Article number MDS D521 6GT2600-5AE00 7.23.3 Mounting on metal Mounting on metal Figure 7-60 Mounting of MDS D421 / D521 on metal Flush-mounting Figure 7-61 Flush-mounting of MDS D421 / D521 in metal without clearance SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...
  • Page 330 Transponder 7.23 MDS D521 Flush-mounting of the MDS in metal with tools 0.5 x 45° 0.3 x 45° or R0.3 10 (-0.04... -0.13) 10 (+0.09... 0) 4.5 (-0 ... -0.1) 4.6 (+0.2 ... 0) Figure 7-62 Flush-mounting of MDS D421 / D521 in metal with tools; all dimensions in mm Note Installation instruction The MDS should not protrude out of the locating hole;...

  • Page 331: Technical Specifications

    Transponder 7.23 MDS D521 Figure 7-64 Installation example of MDS D421/D521/E623 in a stud bolt 7.23.4 Technical specifications Table 7-64 Technical specifications for MDS D521     6GT2600-5AE00 Product type designation SIMATIC MDS D521   Memory Memory configuration     • • 8 bytes  ...

  • Page 332: Dimension Drawing

    Transponder 7.23 MDS D521     6GT2600-5AE00 Vibration-resistant acc. to EN 60721-3-7, Class 200 m/s Torsion and bending load Not permitted   Design, dimensions and weight Dimensions (Ø x H) 10 x 4.5 mm Weight Type of mounting Glued     Standards, specifications, approvals MTBF 228 years The values for shock and vibration are maximum values and must not be applied continuously.

  • Page 333: Mds D522

    Transponder 7.24 MDS D522 7.24 MDS D522 7.24.1 Characteristics MDS D522 Characteristics Area of application Identification of metallic workpiece holders, workpieces or containers Memory size 8192 bytes of FRAM user memory Write/read range See "Field data (Page 37)." Mounting in metal ISO standard ISO 15693 Degree of protection IP68...

  • Page 334: Technical Specifications

    Transponder 7.24 MDS D522 Mounting information for screws You can screw the transponder into a pre-drilled threaded hole using the screw-in aid. Mounting information for adhesion • Drill installation hole • The adhesive surfaces must be dry, free from dust, oil, stripping agents and other impurities •...

  • Page 335: Dimension Drawing

    Transponder 7.24 MDS D522     6GT2600-5AF00   • outside the read/write field • -40 … +100 °C   • during storage • -40 … +100 °C Degree of protection according to EN 60529 IP68 2 hours, 2 bar, +20 °C Shock-resistant acc.

  • Page 336: Mds D522 Special Variant

    Transponder 7.25 MDS D522 special variant 7.25 MDS D522 special variant 7.25.1 Characteristics MDS D522 special version Characteristics Area of application Identification of metallic workpiece holders or workpie‐ Memory size 8192 bytes of FRAM user memory Write/read range See "Field data (Page 37)." Mounting in metal ISO standard ISO 15693...

  • Page 337: Installation Instructions

    Transponder 7.25 MDS D522 special variant Installation instructions The transponder MDS D522 special version is designed to be mounted once. Note the following instructions when mounting the MDS D522 in a workpiece to avoid damaging the transponder: • Prepare the workpiece according to the following drawing. •...

  • Page 338: Technical Specifications

    Transponder 7.25 MDS D522 special variant 7.25.4 Technical specifications Table 7-68 Technical data of MDS D522 special version     6GT2600-5AF00-0AX0 Product type designation SIMATIC MDS D522 special version   Memory Memory configuration     • • 8 bytes   • User memory •...

  • Page 339: Dimensional Drawing

    Transponder 7.25 MDS D522 special variant The values for shock and vibration are maximum values and must not be applied continuously. 7.25.5 Dimensional drawing Figure 7-70 Dimension drawing MDS D522 special version All dimensions in mm SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 340: Mds D524

    Transponder 7.26 MDS D524 7.26 MDS D524 7.26.1 Characteristics MDS D524 Characteristics Area of application Production automation as well use in assembly and manufacturing lines Memory size 8192 bytes of FRAM user memory Write/read range See section "Field data (Page 37)." Mounting on metal Yes, with spacer ISO standard ISO 15693...

  • Page 341: Technical Specifications

    Transponder 7.26 MDS D524 Mounting on metal ≥ 15 mm Figure 7-71 Mounting the MDS D124 / D324 / D424 / D524 on metal with spacer Flush-mounting ≥ 15 mm ≥ 25 mm Figure 7-72 Flush installation of the MDS D124 / D324 / D424 / D524 in metal with spacer 7.26.4 Technical specifications Table 7-71...
  • Page 342 Transponder 7.26 MDS D524     6GT2600-5AC00   • • 8 bytes   • User memory • 8192 bytes FRAM Read cycles (at < 40 ℃) > 10 Write cycles (at < 40 ℃) > 10 Data retention time (at < 40 ℃) >...

  • Page 343: Dimension Drawing

    Transponder 7.27 MDS D525 7.26.5 Dimension drawing Figure 7-73 Dimensional drawing of MDS D524 All dimensions in mm 7.27 MDS D525 7.27.1 Characteristics MDS D525 Characteristics   Area of application Compact and rugged ISO transponder for screw mounting Use in assembly and production lines in the powertrain sector; ideal for mounting on motors, gearboxes, and workpiece hold‐...

  • Page 344: Application Example

    Transponder 7.27 MDS D525 7.27.3 Application example Figure 7-74 Application example 7.27.4 Technical specifications Table 7-73 Technical specifications for MDS D525     6GT2600-5AG00 Product type designation SIMATIC MDS D525   Memory Memory configuration     • • 8 bytes   • User memory •...
  • Page 345 Transponder 7.27 MDS D525     6GT2600-5AG00 Recommended distance to metal > 0 mm Power supply Inductive, without battery   Permitted ambient conditions Ambient temperature     • during write/read access • -25 … +85 °C   • outside the read/write field •...

  • Page 346: Dimension Drawing

    Transponder 7.28 MDS D526 7.27.5 Dimension drawing Figure 7-75 Dimensional drawing of MDS D525 All dimensions in mm 7.28 MDS D526 7.28.1 Characteristics MDS D526 Characteristics Area of application Compact and rugged ISO transponder, suitable for iden‐ tification of transport units in production-related logis‐ tics.

  • Page 347: Ordering Data

    Transponder 7.28 MDS D526 7.28.2 Ordering data Table 7-74 Ordering data for MDS D526   Article number MDS D526 6GT2600-5AH00 Table 7-75 Ordering data for MDS D526 accessories   Article number Spacer 6GT2690-0AL00 7.28.3 Mounting on metal Direct mounting of the transponder on metal is not permitted. A distance of ≥ 20 mm is recommended to avoid a reduced read/write range and a reduction of the field data.

  • Page 348: Technical Specifications

    Transponder 7.28 MDS D526 Flush-mounted in metal h ≥ 25 mm ≥ 50 mm Figure 7-77 Flush installation of the MDS D126 / D426 / D526 in metal with spacer 7.28.4 Technical specifications Table 7-76 Technical specifications for MDS D526     6GT2600-5AH00 Product type designation SIMATIC MDS D526  ...

  • Page 349: Dimension Drawing

    Transponder 7.28 MDS D526     6GT2600-5AH00   • during write/read access • -25 … +85 °C   • outside the read/write field • -40 … +100 °C   • during storage • -40 … +100 °C Degree of protection according to EN 60529 IP68 2 hours, 2 bar, +20 °C Shock-resistant according to IEC 68-2-27...

  • Page 350: Mds D528

    Transponder 7.29 MDS D528 7.29 MDS D528 7.29.1 Characteristics MDS D528 Characteristics   Area of application Compact and rugged ISO transponder for screw mounting Use in assembly and production lines in the powertrain sector Can also be deployed under extreme environmental condi‐ tions without problems due to the rugged design.

  • Page 351: Application Example

    Transponder 7.29 MDS D528 7.29.3 Application example Figure 7-79 Application example 7.29.4 Technical specifications Table 7-78 Technical specifications for MDS D528     6GT2600-5AK00 Product type designation SIMATIC MDS D528   Memory Memory configuration     • • 8 bytes   • User memory •...
  • Page 352 Transponder 7.29 MDS D528     6GT2600-5AK00 Recommended distance to metal ≥ 0 mm Power supply Inductive, without battery   Permitted ambient conditions Ambient temperature     • during write/read access • -25 … +85 °C   • outside the read/write field •...

  • Page 353: Dimension Drawing

    Transponder 7.30 MDS D560 7.29.5 Dimension drawing SW 22 +0.5 Figure 7-80 Dimensional drawing of MDS D528 All dimensions in mm 7.30 MDS D560 7.30.1 Characteristics MDS D560 Characteristics   Area of application Identification in small assembly lines Can also be used in a harsh industrial environment without problem Memory size 8192 bytes of FRAM user memory...

  • Page 354: Ordering Data

    Transponder 7.30 MDS D560 7.30.2 Ordering data Table 7-79 Ordering data for MDS D560   Article number MDS D560 6GT2600-5AB00 Table 7-80 Ordering data for MDS D560 accessories   Article number Spacer 6GT2690-0AG00 Corner mounting bracket 6GT2690-0AN00 7.30.3 Mounting on metal Note that if the distance (h) is not observed, this may result in a reduction of the field data as well as a reduced write/read range.

  • Page 355: Technical Specifications

    Transponder 7.30 MDS D560 7.30.4 Technical specifications Table 7-81 Technical specifications for MDS D560     6GT2600-5AB00 Product type designation SIMATIC MDS D560   Memory Memory configuration     • • 8 bytes   • User memory • 8192 bytes FRAM Read cycles (at < 40 ℃) >...

  • Page 356: Dimension Drawings

    Transponder 7.30 MDS D560     6GT2600-5AB00     Standards, specifications, approvals MTBF 228 years The values for shock and vibration are maximum values and must not be applied continuously. The processing instructions of the adhesive manufacturer must be observed. 7.30.5 Dimension drawings Dimension drawing of MDS D560 Dimensions in mm...

  • Page 357: System Integration

    Function blocks are used for integration into the SIMATIC. They are used to transfer the input parameters to the reader using the "init_run" (RESET) command. You will find information on the following blocks on the Internet on the pages of the Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/14971/man).
  • Page 358 System integration You can easily and quickly configure and parameterize the entire RF300 system in the TIA Portal (as of STEP 7 Basic / Professional V14 SP 1) with the help of the "SIMATIC Ident" technology object. You can find detailed information about the technology object in the TIA Portal help.
  • Page 359 System integration The following table shows the program blocks compatible with the interface modules/ communications modules. Table 8-2 Compatible program blocks ASM/ Compatible program blocks in conjunction with ... communications S7-300 / S7-400 and S7-300 / S7-400 and S7-1200 / S7-1500 and module STEP 7 Classic V5.5 STEP 7 Basic/Professional...
  • Page 360 System integration SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 361: System Diagnostics

    System diagnostics Error codes of the RF200 readers Note Validity of the error codes The following error codes apply only to RF200 readers with an S-422 interface (CM mode) You have the following options to read out the error code: •...
  • Page 362 System diagnostics 9.1 Error codes of the RF200 readers Flashing of Error code Error mes‐ Description (hex) sage reader LED (hex) display Ident profile 0x0C 0xE1FE0100 Cannot write to the memory of the transponder. Possi‐ ble causes: • Transponder memory is defective. 0x0D 0xE1FE0300 Address error...

  • Page 363: Diagnostics Functions - Step 7

    Further information on RFID diagnostics options can be found in the following function manuals: • Function manual Ident profile and Ident blocks (https:// support.industry.siemens.com/cs/us/en/view/106368029) • Function Manual FB 45 (https://support.industry.siemens.com/cs/ww/en/view/21738808) 9.2.1 Reader diagnostics with "Reader Status" (SLG Status) With this command you can query the status and diagnostics data of the reader.

  • Page 364: Transponder Diagnostics With "Tag Status" (Mds Status)

    System diagnostics 9.2 Diagnostics functions - STEP 7 Name Type Possible Values Comment (hex) baud byte   Transmission speed 0x01 = 19.2 kBd 0x03 = 57.6 kBd 0x05 = 115.2 kBd multitag_SLG byte   Number of transponders (multitag/bulk) that can be processed in the antenna field  ...
  • Page 365 System diagnostics 9.2 Diagnostics functions - STEP 7 Name Type Possible Values Comment (hex) IC_version byte 0x00 ... 0xFF Chip version size word 0x00 ... 0xFF Memory size in bytes Depending on transponder type, e.g. MDS D3xx: 992 bytes lock_state byte 0x00 ...
  • Page 366 System diagnostics 9.2 Diagnostics functions - STEP 7 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 367: Appendix

    DIN ISO 9001 certificate The quality assurance system for the entire product process (development, production, and marketing) at Siemens fulfills the requirements of ISO 9001 (corresponds to EN29001: 1987). This has been certified by DQS (the German society for the certification of quality management systems).
  • Page 368 IC ID: 267X-RF... Importer UK: Siemens plc, Sir William Siemens House, Princess Road, Manchester M20 EAC (Eurasian Conformity) Eurasian Economic Union of Republic of Armenia, the Republic of Bela‐ rus, the Republic of Kazakhstan, the Kyrgyz Republic and the Russian...
  • Page 369 Appendix A.1 Certificates & approvals Labeling Description Mexico (COFETEL) Mexico (COFETEL) Estados Unidos Mexicanos Comision Federal de Telecomunicaciones South Africa (ICASA) Independent Communications Authority of South Africa, Sandton Radio Equipment Type Approval Certificate China (CMIIT) China (CMIIT) Radio Transmission Equipment Type Approval Certificate In accordance with the provisions on the Radio Regulations of the Peo‐...

  • Page 370: Accessories

    Appendix A.2 Accessories Accessories A.2.1 Antenna splitter Area of application Antenna splitter Characteristics   Area of application Designed for distributed mounting of antennas in warehouses, logistics and distribution Readers that can be connected RF285R, RF290R Number of connectable max. 4 antennas (by cascading) Connectable antennas •...

  • Page 371: Technical Specifications

    Appendix A.2 Accessories Technical specifications Table A-3 Technical specifications for antenna splitter Technical specifications max. input power 10 W Transmission frequency 13.56 MHz Power supply None Housing dimensions (L x W x H) 160 x 80 x 40 mm (without connector) Color Anthracite Material...

  • Page 372: Scope Of Supply

    Furthermore, the US version has been UL-certified for the US and Canada. Table A-4 Wide-range power supply unit for SIMATIC RF systems   Characteristics   Area of application Voltage supply for Siemens Ident devices Degree of protection IP67 Design features • Mechanically and electrically rugged design •...

  • Page 373: Safety Information

    Appendix A.2 Accessories   Article number   5 m 6GT2891-4EH50 • With open ends 24 VDC connecting cable 5 m 6GT2491-1HH50 for readers of the SIMATIC product family MOBY D 24 V DC connecting cable 5 m 6GT2891-4KH50 for SIMATIC RF200/RF300 readers with RS232 24 V DC connecting cable 6GT2091-0PH50 for SIMATIC RF360R 24 V DC connecting cable...
  • Page 374 Appendix A.2 Accessories NOTICE Liability If the wide input range power supply for SIMATIC RF systems is connected to third-party products, the end user is responsible and liable for operation of the system or end product that includes the wide input range power supply for SIMATIC RF systems. Note the conditions specified in the UL approval.

  • Page 375: Mounting & Connecting

    Appendix A.2 Accessories A.2.2.5 Mounting & connecting The wide-range power supply unit for SIMATIC RF systems is sold with a country-specific power cable for EU, UK and US. Note Country-specific adaptation of the connector When necessary, the primary cable can be adapted to country-specific conditions. The connector can be replaced by a country-specific connector.

  • Page 376: Grounding Connection

    Tighten the screw with a torque of ≃ 1.5 Nm. Grounding connection Hexagon-head screw (M5) Flat washer Cable lug Contact washer: To make ground contact, use contact washers according to the Siemens standard: SN 70093-6-FStflNnnc- 480h, Siemens item no.: H70093-A60-Z3 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 377: Degree Of Protection

    Appendix A.2 Accessories Degree of protection The wide-range power supply unit for SIMATIC RF systems meets degree of protection IP67. • Dust-tight: No ingress of dust • Protected against harm from temporary submersion in water: Water must not enter in amounts that can cause damage, if the housing is immersed in water 1 m deep for 30 minutes.
  • Page 378 Appendix A.2 Accessories     6GT2898-0ACx0 Insulation strength (prim./sec.) U AC 3.3 kV isol p/s Primary- secondary side are galvanically isolated Insulation resistance R > 1 GΩ Leakage current I < 200 µA leak at U = 230 VAC, f = 50 Hz Mains buffering t ≥...
  • Page 379 Appendix A.2 Accessories     6GT2898-0ACx0 HF coupling EN 61000-6-2 / EN 61000-4-6 10 V Line interruption EN 61000-6-2 / EN 61000-4-11   Design, dimensions and weights Dimensions (L × W × H)     • Without plug • 140 × 85 × 35 mm  ...

  • Page 380: Dimension Drawing

    Appendix A.2 Accessories Table A-10 Output configurations Input Outputs ILoad = I1 + I2 Efficiency (%) Remarks U1 = U2 110 VAC 24 VDC No-load protection 110 VAC 24 VDC ≥ 88 220 VAC 24 VDC No-load protection 220 VAC 24 VDC ≥...

  • Page 381: Certificates And Approvals

    Appendix A.2 Accessories A.2.2.9 Certificates and approvals Table A-11 Approvals for wide-range power supply unit for SIMATIC RF systems (Europe, UK): 6GT2898-0AC00, 6GT2898-0AC10 Marking Description CE approval acc. to • 2004/108/EG - EMC • 2006/95/EG - Voltage directive Radio approval for Russia, Belarus, Kazakhstan Table A-12 Approvals for wide-range power supply unit for SIMATIC RF systems (USA): 6GT2898-0AC20...

  • Page 382: Transponder Holders

    Appendix A.2 Accessories • The following secondary output circuits are supplied by a Limited Power Source: 24 Vdc output. • The following output terminals were referenced to earth during performance testing: Terminal P4 (-) during DETERMINATION OF WORKING VOLTAGE - WORKING VOLTAGE MEASUREMENT TEST.
  • Page 383 Appendix A.2 Accessories Product photo Insertable transponders Characteristics • MDS D100 • Fixing pocket not suitable for mounting directly on metal • MDS D200 • Mounting: 2 x M4 countersunk screws • MDS D400 • Material: PA6 • Weight: 21 g •...
  • Page 384 Appendix A.2 Accessories Product photo Insertable transponders Characteristics • MDS D126 • Spacer for mounting on metal • MDS D426 • Distance from transponder to metal: 25 mm • MDS D526 • Mounting: 1 x M4 countersunk screw • Tightening torque: ≤ 1 Nm •...

  • Page 385: Dimensional Drawings

    Appendix A.2 Accessories Dimensional drawings Figure A-2 Dimension drawing of spacer 6GT2190-0AA00 with fixing pocket 6GT2190-0AB00 Figure A-3 Dimension drawing of fixing pocket 6GT2390-0AA00 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...
  • Page 386 Appendix A.2 Accessories Figure A-4 Dimension drawing of spacer 6GT2690-0AA00 Figure A-5 Dimension drawing of quick change holder 6GT2690-0AH00 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...
  • Page 387 Appendix A.2 Accessories Figure A-6 Dimension drawing of quick change holder 6GT2690-0AH10 Figure A-7 Dimension drawing of spacer 6GT2690-0AK00 Figure A-8 Dimension drawing of spacer 6GT2690-0AL00 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...
  • Page 388 Appendix A.2 Accessories Figure A-9 Dimension drawing of spacer 6GT2690-0AG00 Figure A-10 Dimension drawing corner mounting bracket 6GT2690-0AN00 SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 389: Connecting Cable

    Appendix A.3 Connecting cable Figure A-11 Dimension drawing of fixing hood 6GT2690-0AE00 Connecting cable A.3.1 RF2xxR reader (RS-422) with ASM 456 / RF160C / RF170C / RF180C / RF18xC / RF182C Connecting cable with straight connector Figure A-12 Connecting cable between ASM 456, RF160C, RF170C, RF180C, RF18xC, RF182C and RF2xxR reader (RS422) SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...
  • Page 390 Appendix A.3 Connecting cable Table A-14 Ordering data Length L Article number 6GT2891-4FH20 6GT2891-4FH50 10 m 6GT2891-4FN10 20 m 6GT2891-4FN20 50 m 6GT2891-4FN50 Connecting cable with angled connector Figure A-13 Connecting cable between ASM 456, RF160C, RF170C, RF180C, RF18xC and RF2xxR reader (RS-422) with angled connector Table A-15 Ordering data Length L...

  • Page 391: Reader Rf2Xxr (Rs-422) With Asm 475

    Appendix A.3 Connecting cable Figure A-14 Distance between connector edge and housing edge The distance between the edge of the connector and the edge of the reader housing (H) is as follows: RF210R/RF220R = 33 mm, RF240R/RF260R = 36 mm and RF290R = 37 mm. If you look at the reader from below, the angled connector points 90°...

  • Page 392: Reader Rf2Xxr (Rs-422) With Rf120C

    Appendix A.3 Connecting cable A.3.3 Reader RF2xxR (RS-422) with RF120C Figure A-16 Connecting cable between RF120C and RF2xxR reader (RS-422) Table A-17 Ordering data Length L Article number 6GT2091-4LH20 6GT2091-4LH50 10 m 6GT2091-4LN10 A.3.4 RF240R/RF260R/RF285R/RF290R (RS232) readers with PC The connecting cables have a length of 5 m. The outgoing cable for the power supply has a length of 0.5 m.
  • Page 393 Appendix A.3 Connecting cable With 4-pin power supply connector Figure A-17 Connecting cable between PC and RF240R/RF260R/RF285R/RF290R (RS232) with 4-pin power supply connector Suitable power supply unit: e.g. wide-range power supply unit With open ends for the power supply Figure A-18 Connecting cable between PC and RF240R/RF260R/RF285R/RF290R (RS232) with open ends for the power supply Table A-18 Ordering data connecting cable...

  • Page 394: Rf285R/Rf290R Readers

    Appendix A.3 Connecting cable A.3.5 RF285R/RF290R readers Antenna connecting cable Figure A-19 ANT cable ↔ ANT Dx (3.3 m / 10.5 m) Table A-19 Ordering data Length L Article number 3.3 m 6GT2691-0CH33 10.5 m 6GT2691-0CN10 Antenna extension cable Figure A-20 Antenna extension cable (7.2 m) Table A-20 Ordering data Length L...

  • Page 395: Ordering Data

    Appendix A.4 Ordering data Ordering data RF200 components Table A-21 RF200 reader Readers Description Article number RF210R 6GT2821-1AC10 • With RS-422 interface (3964R) • IP67 • Operating temperature: -25 °C ... +70 °C • Dimensions (L x Ø): 83 x 18 mm •...
  • Page 396 Appendix A.4 Ordering data Readers Description Article number RF250R 6GT2821-5AC10 • With RS-422 interface (3964R) • IP67 • Operating temperature: -20 °C ... +70 °C • Dimensions (L x W x H): 50 x 50 x 30 mm • Reader with connections for external antennas ANT 1, ANT 3, ANT 8, ANT 12, ANT 18, ANT 30 RF250R •...
  • Page 397 Appendix A.4 Ordering data Readers Description Article number RF285R 6GT2821-7AC12 • with RS232 interface • IP65 • Operating temperature: -20 … +55 °C • Dimensions (L x W x H): 200 x 140 x 80 mm • Reader with connections for external antennas ANT D1, ANT D5 or ANT D6 RF290R 6GT2821-0AC12 •...
  • Page 398 Appendix A.4 Ordering data Antennas Description Article number ANT 3 S 6GT2398-1CD50-0AX0 • IP67 • Operating temperature: -25 °C ... +70 °C • Dimensions (L x W x H): 50 x 28 x 10 mm • Without antenna connecting cable 6GT2398-1CD60-0AX0 • incl.
  • Page 399 Appendix A.4 Ordering data Antennas Description Article number ANT D1 6GT2698-5AC00 • IP67 • Operating temperature: -25 °C ... +55 °C • Dimensions (L x W x H): 75 x 75 x 20 mm • incl. one plug-in antenna connecting cable 3.3 m ANT D5 6GT2698-5AA10 •...
  • Page 400 Appendix A.4 Ordering data ISO transponder Description Article number MDS D127 6GT2600-0AF00 • IP68; IPx9K • Memory size: 112 bytes of EEPROM user memory • Operating temperature: -25 °C ... +125 °C • Dimensions (Ø x H): M6 x 5 (±0.2) mm MDS D139 6GT2600-0AA10 •...
  • Page 401 Appendix A.4 Ordering data ISO transponder Description Article number MDS D421 6GT2600-4AE00 • IP67; IPx9K • Memory size: 2000 bytes of FRAM user memory • Operating temperature –25 °C ... +85 °C • Dimensions (Ø x H): 10 x 4.5 mm MDS D422 6GT2600-4AF00 •...
  • Page 402 Appendix A.4 Ordering data ISO transponder Description Article number MDS D522 6GT2600-5AF00 • IP68 • Memory size: 8192 bytes of FRAM user memory • Operating temperature: -25 °C ... +85 °C • Dimensions (Ø x H): M20 x 6 (±0.2) mm •...
  • Page 403 Appendix A.4 Ordering data Communications Description Article number module RF120C Communications module RF120C for SIMATIC S7-1200 6GT2002-0LA00 RF160C Communications module RF160C for PROFIBUS DP V0 6GT2002-0EF00 max. 2 readers connectable RF166C Communications module RF166C for PROFIBUS DP 6GT2002-0EE20 max. 2 readers connectable RF170C RF170C communications module 6GT2002-0HD00...
  • Page 404 Appendix A.4 Ordering data Accessories Table A-25 Reader accessories Readers Accessories Article number RF285R / RF290R Adapter for mounting on a DIN rail 6GK5798-8ML00-0AB3 (pack of 3) Table A-26 ISO transponder accessories Transponder Accessories Article number MDS D100 / D200 / Spacer 6GT2190-0AA00 D400...
  • Page 405 Appendix A.4 Ordering data Table A-28 Accessories - connecting cable reader ↔ PC Connecting cable Accessories Article number All readers with RS232 Connecting cable RS232 6GT2891-4KH50 interface D-sub ↔ M12-180 (8-pin) and M12-180 (4-pin), 5 m and PC Connecting cable RS232 6GT2891-4KH50-0AX0 D-sub ↔...
  • Page 406 Appendix A.4 Ordering data SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...

  • Page 407: Service & Support

    Industry Online Support In addition to the product documentation, you are supported by the comprehensive online information platform of Siemens Industry Online Support at the following Internet address: Link: (https://support.industry.siemens.com/cs/de/en/) Apart from news, you will also find the following there: •...
  • Page 408 Service & Support SIMATIC RF200 System Manual, 11/2022, J31069-D0227-U001-A12-7619...
