Hercules HCB97B Owner's Manual & Safety Instructions

20 v lithium-ion 1/2″ brushless mud mixer
Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual &
Safety Instructions
TM
24h
Model
HCB97B
Battery and Charger Sold Separately
20  V Lithium-Ion 1/2" Brushless Mud Mixer
WARNING: To prevent serious injury, User must read and
understand Owner's Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and
undamaged. If any parts are missing or broken, please call
1-888-866-5797 as soon as possible. Reference 59715.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HCB97B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hercules HCB97B

Summary of Contents for Hercules HCB97B

  • Page 1 Owner’s Manual & Safety Instructions Model HCB97B Battery and Charger Sold Separately 20  V Lithium-Ion 1/2″ Brushless Mud Mixer WARNING: To prevent serious injury, User must read and understand Owner’s Manual. SAVE THIS MANUAL. When unpacking, make sure that the product is intact and undamaged.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings 3. Personal safety a. Stay alert, watch what you are doing and Read all safety warnings, instructions, illustrations use common sense when operating a and specifications provided with this power tool. power tool. Do not use a power tool while Failure to follow all instructions listed below may you are tired or under the influence of result in electric shock, fire and/or serious injury.
  • Page 3 l. People with pacemakers should consult their 5. Service physician(s) before use. Electromagnetic fields in a. Have your power tool serviced by a close proximity to heart pacemaker could cause qualified repair person using only identical pacemaker interference or pacemaker failure. replacement parts.

  • Page 4: Extension Cords

    7. Battery tool use and care in a hot environment. Do not place the Charger on a flammable surface. Do not obstruct any a. Prevent unintentional starting. Ensure the vents on the Charger. Especially avoid placing switch is in the off-position before connecting the Charger on carpets and rugs;...

  • Page 5: Specifications

    Symbology SPECIFICATIONS 20V Li-Ion 57373, 57306 Volts Battery Type Hercules (sold separately) 20V Li-Ion 56224, 56559 Direct Current Charger Type Hercules (sold separately) No Load Speed : 0  –   5 50  /   m in Amperes Chuck Size 1/2" (Ø13  m m)
  • Page 6 Functions Speed Control Battery Dial (sold separately) Direction Chuck Switch Chuck Auxiliary Handle Worklight Lock ON Button Variable Speed Trigger Main Handle Page 6 For technical questions, please call 1-888-866-5797. Item 59715...

  • Page 7: Setting And Testing

    Setting Direction Switch OPERATING INSTRUCTIONS To set Direction Switch: Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of Forward: Push Switch in on right side this manual including all text under (arrow pointing forward) for clockwise rotation. subheadings therein before set up or use. Reverse: Push Switch in on left side (arrow pointing backward) for Setting and Testing...
  • Page 8 1. Push Direction Switch to the center to speed. Do not overload tool. If tool bogs lock Trigger, then attach a 20  V  Hercules  down, release Trigger, or press and release the Battery Pack (sold separately). Trigger if the Lock ON Button is engaged.

  • Page 9: Maintenance And Servicing

    Cleaning, Maintenance, MAINTENANCE AND SERVICING and Lubrication Procedures not specifically explained 1. BEFORE EACH USE, inspect the general in this manual must be performed condition of the tool. Check for: only by a qualified technician. • leaking, swollen, or cracked battery pack •...

  • Page 10: Troubleshooting

    Troubleshooting Problem Possible Causes Likely Solutions Tool will 1. Battery Pack not properly 1. Remove Battery Pack, make sure there are no not start. connected. obstructions, reinsert the Battery Pack according to its shape (it should only fit one way), and press firmly until the Battery Pack locks in place.
  • Page 11 Record Product’s Serial Number Here: Note: If product has no serial number, record month and year of purchase instead. Note: Replacement parts may be available for this item. Visit harborfreight.com/parts for a list of in-stock parts. Reference UPC 193175479846. Item 59715 For technical questions, please call 1-888-866-5797.

  • Page 12: Year Limited Warranty

    5-YEAR LIMITED WARRANTY This Hercules tool is warranted to the original purchaser to be free from defects in materials and workmanship for a period of five (5) years beginning on the date of purchase. This warranty does not cover battery packs and battery chargers, which are covered under separate warranties.

This manual is also suitable for:

59715
