VB370A
4K Dual Lens Video Bar
User Manual
—
—

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VB370A and is the answer not in the manual?

Questions and answers

Related Manuals for AVer VB370A

Summary of Contents for AVer VB370A

  • Page 1 VB370A 4K Dual Lens Video Bar User Manual — —...
  • Page 2 Caution Risk of explosion if battery is replaced by an incorrect Type. Dispose of used batteries according to the Instructions. PSTI Statement of Compliance Please refer to the following website: https://www.aver.com/product-security-advisory VCCI-A この装置はクラス A 機器です。この装置を住宅環境で使用すると電波妨害を引き起こすことがあります。こ の場合には使用者が適切な対策を講ずるよう要求されることがあります。 (注) 本製品同梱の電源ケーブルは本製品同梱の電源アダプタでのみ使用してください。本製品同梱の電源 ケーブルは他の電気機器では使用できません。...
  • Page 3 ©2024 AVer Information Inc. All rights reserved. | November 6, 2024 All rights of this object belong to AVer Information Inc. Reproduced or transmitted in any form or by any means without the prior written permission of AVer Information Inc. is prohibited. All...
  • Page 4 Contact Information Headquarters USA Branch Office Europe Branch Office AVer Information Inc. AVer Information Inc., AVer Information Europe B.V. 8F, No.157, Da-An Rd., Americas Westblaak 134, 3012 KM, Tucheng Dist., New Taipei City 44061 Nobel Drive, Fremont, Rotterdam, The Netherlands...

  • Page 5: Table Of Contents

    Wall Mount Installation ....................8 TV VESA Mount Installation (Optional) ................9 Start a Meeting in Zoom Rooms ..................11 Pair VB370A with a Controller ..................11 Sign In to Zoom Rooms ....................12 As the owner, admin, or user ................... 12 With an activation code ....................
  • Page 6 System .......................... 27 Video Service Provider ....................28 Web Interface ........................29 Access the Web Interface ..................... 29 AVer IP Finder ......................29 PTZ Control ........................31 Overview of PTZ Control ..................31 Save and Load a Preset ..................32 Setting ..........................

  • Page 7: Overview

    Overview Package Contents Video Bar Power Adapter & HDMI 2.0 Cable Remote Control Power Cord AAA Battery Wall Mount Bracket 1/4”-20 L=7.5 mm Drill Template (x2, US only) Screw (x2) Optional Accessories Expansion Expansion CP10 G2 USB 3.0 Type-C to C Speakerphone Microphone Collaboration...

  • Page 8: Parts Info

    Parts Info 1. Beamforming Microphones 2. LED Indicator 3. Wide-Angle Lens 4. Optical Zoom Lens 5. IR Sensors 6. DC Power Jack 7. Ethernet Port 8. N/A 9. Reset Hole 10. HDMI In Port 11. USB 3.0 Type-A Port (x2) 12.

  • Page 9: Led Indicators

    LED Indicators Color Status Solid red Start-up Solid white Standby Solid blue Streaming Solid red Microphone muted Solid orange Sleep Mode...

  • Page 10: Remote Control

    13. Enter Press to display current AI function on closed caption. 14. Mute 15. Camera Off N/A* 16. Volume Volume up or down. * Pending release. For the most updated information, please refer to the release note from AVer Download Center.

  • Page 11: Connections

    Zoom Rooms. USB 3.0 Type-A Port (x2) Connect peripheral devices, such as a keyboard or mouse to navigate the Android interface. * Pending release. For the most updated information, please refer to the release note from AVer Download Center.
  • Page 12 Room. This monitor displays a Zoom Rooms background image in absence of shared content or an additional camera feed. Bluetooth® Port N/A* * Pending release. For the most updated information, please refer to the release note from AVer Download Center.
  • Page 13 CP10 G2 •...

  • Page 14: Installation

    Installation Wall Mount Installation 1. Use the wall mount drilling template to mark and drill the mounting holes on the wall. 2. Insert 2 screws and plastic anchors (not included) to the wall. Concrete wall: M5 x20mm self-tapping screws (x2) + plastic anchors (x2) •...

  • Page 15: Tv Vesa Mount Installation (Optional)

    Screw(M8*20) x 4 Washer(M8) x 4 Screw(M8*30) x 4 The VB370A can be installed the same way on top of or under the TV. 1. Fix the screw (M5*10) with silicone washer Slightly fix the fixture on the rear side of the in suitable holes (1~5).
  • Page 16 Place the metal washers on the mount Place the TV mount rack on top of the holes of TV. If you don’t need to install TV fixtures. mount rack, skip step 3—5. Slightly secure the mount rack and fixture If you don’t need to install TV mount rack, on the TV.

  • Page 17: Start A Meeting In Zoom Rooms

    1. Make sure VB370A and CP10 G2 are connected to the same local area network (LAN). 2. Connect a monitor to the HDMI out 1 port on VB370A using the included HDMI cable. The monitor will display a pairing code.

  • Page 18: Sign In To Zoom Rooms

    Zoom Rooms. As the owner, admin, or user 1. Make sure you have paired VB370A with a controller. 2. On the Zoom Rooms Controller, tap Sign In. 3. Sign in as the account owner, admin, or user with access to Zoom Rooms.

  • Page 19: With An Activation Code

    4. Tap the name of this Zoom Room or add a new room from the controller. 5. The VB370A and controller will now be signed in. With an activation code An activation code is generated after setting up the Zoom Room on the web portal. Using the activation code is ideal when the person deploying Zoom Rooms is not the administrator.
  • Page 20 6. On the Zoom Rooms Controller, tap Enter Activation Code. 7. Enter the Activation Code, found on your web portal or emailed to you. 8. The VB370A and controller will now be signed in.

  • Page 21: Share Content In Zoom Rooms

    VB370A can share a second camera or your screen from a computer. Use HDMI 1. Connect your second camera or your computer to the HDMI in port on VB370A. 2. On the Zoom Rooms Controller, start or join a meeting.

  • Page 22: Use Zoom App Or Browser

    Use Zoom App or Browser 1. On the Zoom Rooms Controller, start or join a meeting. 2. Tap Share Content. The controller will display a sharing key and meeting ID. 3. Sign in to the Zoom desktop app or share.zoom.us on the browser.

  • Page 23: Android Interface

    You can access the device Android interface and configure device settings from the pairing code screen. 1. Connect a monitor to the HDMI out 1 port on VB370A using the included HDMI cable. The monitor will display a pairing code.

  • Page 24: Setting Page

    Setting Page You can navigate the Setting Page using the included remote control or a mouse.

  • Page 25: Ptz Control

    PTZ Control 1. PTZ Control SmartFrame: Click to frame entire group on screen and remove excess space. One-Touch Focus: Click to autofocus once. 3. Minimize Control Panel 4. Live View 5. Preset Function 6. Preset Number...

  • Page 26: Save, Load And Clear A Preset

    Save, Load and Clear a Preset To save a preset: 1. Use the pan, tilt and zoom controls to position your device. 2. Select Set, then a preset number to save that position. 3. Select Yes when prompted. To load a preset: Select Load, then a preset number to load that position.

  • Page 27: Firmware Update

    Firmware Update Check for and install the latest firmware update.

  • Page 28: Setting

    Setting Item Description Image Flip Flip the image vertically. Image Mirror Flip the image horizontally. True WDR Turn wide dynamic range (WDR) on or off. Flicker Decrease on IFP / Turn Flicker Decrease on IFP / Monitor on or off. Monitor Frequency Select a frequency.
  • Page 29 Low Light Compensation Turn Low Light Compensation on or off. Allow Remote Access Allow access to the device web interface. Enlarge Total Zoom Up to 18x Turn the function on or off.

  • Page 30: Audio

    Phone In Jack Phone In: Connect your mobile phone to the Phone In • port and use the VB370A as an external speakerphone in mobile-based video conferencing. 3.5mm External Microphone Only: Connect to an • external microphone as the only audio transmitter.
  • Page 31 AVer (TRS female to TRRS male). Note: Avoid connecting to an external speaker when using Line Out. The speaker sound will have impact on built-in speaker and microphone performance.

  • Page 32: Network

    Network Item Description RJ45 Set up Static IP or DHCP. Static IP: Enter your network settings to set up a static • IP connection and click Confirm.

  • Page 33: System

    System Item Description System Language Select the Android interface language. Country Select a country or region. Sleep Timer Set a duration before standby mode. Factory Default Reset your camera to factory default settings. You can choose to keep the IP address by selecting the checkmark. Camera Reboot Reboot the camera.

  • Page 34: Video Service Provider

    Video Service Provider Selection Item Description Zoom Rooms Go back to the Zoom Rooms interface.

  • Page 35: Web Interface

    Web Interface Access the Web Interface You can access the camera web interface and look up IP address using AVer IP Finder. Note: • The camera default network is DHCP. The camera default password is aver4321. • AVer IP Finder...
  • Page 36 1. Download and install AVer IP Finder to your computer from AVer Download Center. https://www.aver.com/download center 2. Open AVer IP Finder. Click Search to see available devices on the same local area network (LAN). Note: • Make sure your camera has internet.

  • Page 37: Ptz Control

    PTZ Control Overview of PTZ Control 1. Preset Function 2. Name Click the pencil icon to name a preset. 3. Preset Thumbnail There are 10 available presets 0-9 by default. 4. Log Out Log out of your account and close the web interface. 5.

  • Page 38: Save And Load A Preset

    Save and Load a Preset To save a preset: 4. Use the pan, tilt and zoom controls to position your device. 5. Select Set, then a preset number to save that position. 6. Select Yes when prompted. To load a preset: Select Load, then a preset number to load that position.

  • Page 39: Setting

    Setting Item Description Image Flip Flip the image vertically. Image Mirror Flip the image horizontally. True WDR Turn wide dynamic range (WDR) on or off. Flicker Decrease on IFP / Turn Flicker Decrease on IFP / Monitor on or off. Monitor Frequency Select a frequency.
  • Page 40 Manual: Adjust the white balance manually by dragging the • slider. Auto: Adjust the white balance automatically. • Noise Reduction Adjust noise reduction level. Brightness Adjust brightness level. Sharpness Adjust sharpness level. Saturation Adjust saturation level. Low Light Compensation Turn Low Light Compensation on or off. Enlarge Total Zoom Up to 18x Turn the function on or off.

  • Page 41: Overview Of The Floating Live View

    Overview of the Floating Live View The floating live view opens automatically on .Setting, Network, System, and Audio tabs. • • To open the floating live view again after closing, click on the camera icon on top of Setting, Network, System, and Audio tabs. 1.

  • Page 42: Network

    Network Item Description RJ45 Set up Static IP or DHCP. Static IP: Enter your network settings to set up a static • IP connection and click Confirm.

  • Page 43: System

    System Item Description Language Select a language for the web interface. Sleep Timer Set a duration before standby mode. FW Update Update your camera firmware. Auto Update: Check and update online. • Manual Update: Update the downloaded firmware file. • Note: The camera will reboot and the connection will be lost.
  • Page 44 Change Password Change the web interface password. Use 8-10 characters and a combination of uppercase letters, • lowercase letters, numbers, and symbols (* ! % + = , - _ ^ / @ . ~ # $). The password cannot be the same as the username.

  • Page 45: Audio

    Phone In: Connect your mobile phone to the Phone In Phone In Jack • port and use the VB370A as an external speakerphone in mobile-based video conferencing. 3.5mm External Microphone Only: Connect to an • external microphone as the only audio transmitter.
  • Page 46 AVer (TRS female to TRRS male). Note: Avoid connecting to an external speaker when using Line Out. The speaker sound will have impact on built-in speaker and microphone performance.
