- Page 1 NS12 MEDIA INTERFACE Quick Start Guide ®...
- Page 2 Overview ® Welcome to the Nodestream 12 (NS12) Please read these instructions carefully before using this product, and save this quick start guide for future use. See the User Manual for full details via the QR code on the back page.
- Page 3 Overview ® Connections / UI Reset Button Restart device - Press 2 sec & release Factory reset device Approximately 10 seconds Press & hold Status Status Release Reset Button Reset button (flashing) (off) Status LED BLUE - System starting GREEN - Solid (streaming), Flashing (idle) - Network issue Gigabit Ethernet...
-
Page 4: Installation
Installation ® Installation 98.3 Mount points Only either HDMI or HD-SDI can be connected to a given input at any time, connecting both may result in undesirable behavior Ensure there is adequate spacing around the device for cooling. Cooling air travels in the direction as shown by the arrows. -
Page 5: Web Interface
Configuration ® Web Interface Access the Web Interface Via a computer on the same network DHCP Enabled Network From the web browser of a PC connected to the same LAN, navigate to: device serial.local - e.g. au2240ns121a012.local, or the IP address of the device Non DHCP Enabled Network Configure the IPv4 network settings of a PC connected to the same LAN to: 192.168.100.102... -
Page 6: Troubleshooting
Bentley WA 6102, Australia harvest.technology All rights reserved. This document is the property of Harvest Technology Pty Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, photocopy, recording or otherwise without the written consent of the ®...
