Soundstream RESERVE WHD14+ Owner's Manual page 6

REMOVAL OF ORIGINAL HEAD UNIT
Road Glide
To prevent accidental vehicle start-up, which could cause death or serious injury, remove
main fuse before proceeding.
1. Detach each turn signal / indicator light by
removing the adjacent allen socket screw,
using a 3/16" allen head driver. Store these
screws in a safe place for re-installation later.
3. Remove four windshield bolts using a 1/8"
allen driver or Philips screw driver and remove
the windshield. Also remove factory vent by
pulling straight up on the vent. The vent comes
snapped in place. Store the screws in a safe
place for installation later.
5. Remove an additional inner fairing bolt with a T27 Torx or 5/32"
allen driver, one behind each speaker grill. Remove the speaker
grill by wedging a plastic/nylon pry tool between the inner fairing
and grill edge, popping it outward. Once these bolts are removed,
the outer fairing will be detached from the inner fairing. Store
these screws in a safe place for installation later.
6. While straddling the front wheel fender, grasp the outer
fairing. Gently pull the fairing apart from the bike. With the
fairing slightly pulled away from the bike, disconnect wire
harness for the headlamp or any other accessories. Lay the
fairing on a protected flat surface to prevent damage.
7. Remove two upper support bracket screws using a 3/16"
allen driver. Store the bracket and screws in a safe place for
re-installation later.
2. Remove four inner fairing bolts using a T25 Torx
driver. Two inner fairing bolts are located below each
glove box, adjacent to each wind deflector. Store
these screws in a safe place for installation later.
4. After removing the vent, locate and unplug the 3-pin
wire harness for the left and right side turn signal
indicator. These harness' are adjacent to each side of
the head unit.
