- Page 1 RESERVE Owner’s Manual OEM UPGRADE HEAD UNIT FOR ® 2014+ HARLEY DAVIDSON MOTORCYCLES 13-BAND VOLT EQUALIZER 4ch. SPEAKER RCA AUDIO & CROSSOVERS OUTPUT AMPLIFIER WHD14+...
-
Page 2: Table Of Contents
Safety First Contents Safety Definitions Safety First Statements in this manual preceded by following Safety Definitions words are of special significance: Pre-Riding WARNING Check list Care and cleaning WARNING indicates a potentially hazardous situation which, if not avoided, could result Screen in death or serious injury. -
Page 3: Pre-Riding
Appearance Pre-RIDING Check list Configure the system with your personal preferences before riding to use features and wHD14+ minimize distractions while on the road entirely. 1. Set brightness, background. 2. Configure presets. 3. Adjust audio settings like EQ, volume, fade, balance etc. -
Page 4: Installation
Installation REMOVAL OF ORIGINAL HEAD UNIT Street Glide To prevent accidental vehicle start-up, which could cause death or serious injury, remove main fuse before proceeding. 1. Remove three outer fairing bolts using a T27 Torx screw driver. The three outer fairing bolts are located below the windshield. - Page 5 Installation 5. Disconnect electrical connections to the head unit. 5.1) Remove the main wire harness connector (1). To remove the main wire harness, depress the latch lock with a small flathead screwdriver and swivel the latch aside. Pull the wire harness connector to remove from the socket.
- Page 6 Installation REMOVAL OF ORIGINAL HEAD UNIT Road Glide To prevent accidental vehicle start-up, which could cause death or serious injury, remove main fuse before proceeding. 1. Detach each turn signal / indicator light by 2. Remove four inner fairing bolts using a T25 Torx removing the adjacent allen socket screw, driver.
- Page 7 Installation 8. Disconnect electrical connections to the head unit. 8.1) Remove the main wire harness connector (1). To remove the main wire harness,depress the latch locking tab wiht a small flathead screwdriver. While depressing the locking tab, pull the USB cable to release it from socket.
-
Page 8: Panel Description
Panel description WHD14+ 1 Apple CarPlay® / Android Auto® Home button Press to enter CarPlay® / Android Auto® Press to toggle between Home screen and • directly(When the iPhone/Android phone active media. is connected). • Available selections: Radio, Apple CarPlay®/Android Auto®, BT Music, BT 2 Siri Button（Voice Recognition）... -
Page 9: Wiring
Wiring To prevent accidental vehicle start-up, which could cause death or serious injury, remove main fuse before proceeding. 1. Install W HD14+ into the location of the OEM head unit. Secure the chassis to the OEM mounting location with the four bolts removed during the last step of REMOVAL OF ORIGINAL HEAD UNIT section using a 3/16”... -
Page 10: Pin Connector
Wiring Included Harness Connect to Exteral Amplifier Co n n ect to Han dlebar Con tro l M o du le: E4. Pink/White....UART-SPEED 48 PIN CONNECTOR L1. White/Black..FL- F4. Gray/White...UART-TX L2. White.......FL+ G4. Blue/White...UART-RX L3. Black......Ground H1. Green/Black..RL- L4. Black......Ground H4. - Page 11 Wiring 4. If an alternative handlebar integration module other than Scosche is available, skip this step and proceed to step 5. If included, connect the Scosche handlebar integration module to the corresponding 12-pin and 14-pin connectors on the wire harness of WHD14+. SCOSCHE 5.
-
Page 12: Handlebar Control
Handlebar Control Handlebar control the headunit: WHD14+ for select 2014+ touring motorcycles can retain factory handlebar controls using the HDHU.14HCM SWC module. Left HandControl ITEM ICON NAME FUNCTION Source change. Mode Previous Previous track. Media: /SeekDown Tune/seek down. Tuner: Next track. Media: Next/Seek Tune/seek up. -
Page 13: Main Menu
Main Menu Settings System Settings： WHD14+ is a headunit for Motorcycle with the following functions: The System Settings allow the user to set Wireless / Wired Apple CarPlay®, Wireless / up the Language, Date & Time, Key Beep, WiredAndroid Auto®, Radio, USB, BTMusic, GPS Status,Factory Reset and About. - Page 14 Settings Use a good quality flash drive from a reputable About: manufacturer. To display the WHD14+ MCU, SOC,hardware Avoid flash drives you might have given as a and firmware version, and the headunit’s serial freebie from a vendor at a rally, part of a novelty number.
- Page 15 Subwoofer Crossovers: not be necessary. If you are unsure about this point, Subwoofer Phase: 0° or 180°. please consult your authorized Soundstream dealer. • HPF (high pass filter): Cuts the lower frequencies and allows the higher frequencies to pass. • LPF (low pass filter): Cuts the higher frequencies and allows the lower frequencies to pass.
-
Page 16: Display Setting
Settings Background Wallpaper: Maximum Volume Adjust: User can select the preset wallpaper or select prefer picture in USB driver as the wallpaper. Use can turn Maximum Volume On / O˛. When turned ON, user can set the Touch the corresponding picture to select desired Maximum Volume level. -
Page 17: Apple Carplay/Android Auto
Apple CarPlay & Android Auto ® ® Apple CarPlay : You can operate iPhone applications with finger gestures such as tapping, dragging, scrolling, or flicking on the screen of this product. Compatible iPhone models For details about compatibility of iPhone models, refer to the following website. - Page 18 1. Turn on your iPhone’s Starting procedure of using Android Auto Bluetooth and Wi-Fi, and Soundstream V2 MagiCast_1104 Soundstream V2 connect to WHD14+. 1 Connect an Android Auto™ compatible device to this unit via USB.
- Page 19 Apple CarPlay & Android Auto ® ® How to connect Wireless Android Auto When the headunit detect the available device, follow the pop-up notice step by step Starting procedure of using Wirelessly Android to connect the iPhone. After connected, will Auto show below page: 1 On the Main menu tap the...
- Page 20 Radio Radio setting: Touch “Radio” in the main menu to enter the radio interface. Radio Area : Select the region , America/Europe /Eastern Europe /Japan /Southeast Asia /Latin America/ Asia / Australia. Touch “FM” can change between : Switch ON or OFF. FM1>FM2>FM3.
-
Page 21: Bluetooth Music
Bluetooth Music Press to select Repeat All> Bluetooth Music: Repeat 1> Repeat Folder. Touch the BT Music icon to enter Bluetooth Press to switch Randon is Music playing mode. If the Bluetooth is On or O˛. connected, the music will be playing as Press to select Audio setting or below shown: set the preferred EQ of each... -
Page 22: Bluetooth Phone
Bluetooth Phone Receive an incoming call: Bluetooth Phone: If the Phone is connected with the source After the mobile Phone is connected with the unit via Bluetooth, when an incoming call, source unit via Bluetooth(HFP), the user can below screen will be shown: go through the source unit. -
Page 23: Speci Cation
Bluetooth Phone Camera in BT Setup: Camera View For connecting a camera. Displaying the picture from the Camera The camera view screen is displayed when you enter the Camra in. Auto Answer On/O˛, incoming call auto Camera in answer. MIC Gain Low /Middle /High Specification GENERAL... -
Page 24: Trouble Shooting
If you have problems operating this product, refer to this section. The most common problems are listed below, along with likely causes and solutions. If a solution to your problem cannot be found here, contact your dealer or Soundstream Technical Support. Problem Correct action No response from the unit. -
Page 25: Warranty
Two-years (2-years) from the date of purchase from a Soundstream and/or Precision Power authorized retailer. During this Two-year (2-year) period, there will be no service charge for repair or replacement. -
Page 26: Fcc Notes
FCC Notes FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the follow- ing two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
