RESERVE
'14-23' HARLEY DAVIDSON
13-BAND
EQUALIZER
& CROSSOVERS
To print a complete owners manual, visit us
scan this QR code with your phone's
camera to download the complete
OEM UPGRADE HEAD UNIT FOR
INSTALLATION GUIDE
online at motorcycleaudio.com/WHD14+
owners manual to your phone.
5-
VOLT
RCA AUDIO
OUTPUT
- or -
®
MOTORCYCLES
2-
OHM
4ch. SPEAKER
AMPLIFIER
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Soundstream RESERVE WHD14+
Summary of Contents for Soundstream RESERVE WHD14+
- Page 1 RESERVE OEM UPGRADE HEAD UNIT FOR ® ‘14-23’ HARLEY DAVIDSON MOTORCYCLES INSTALLATION GUIDE 13-BAND VOLT EQUALIZER RCA AUDIO 4ch. SPEAKER & CROSSOVERS OUTPUT AMPLIFIER To print a complete owners manual, visit us online at motorcycleaudio.com/WHD14+ - or - scan this QR code with your phone’s camera to download the complete owners manual to your phone.
- Page 2 REMOVAL OF ORIGINAL HEAD UNIT Street Glide To prevent accidental vehicle start-up, which could cause death or serious injury, remove main fuse before proceeding. 1. Remove three outer fairing bolts using a T27 Torx screw driver. The three outer fairing bolts are located below the windshield. Remove the windshield, store it and the screws removed in a safe place for re-installation later.
- Page 3 5. Disconnect electrical connections to the head unit. 5.1) Remove the main wire harness connector (1). To remove the main wire harness, depress connector to remove from the socket. 5.2) Remove the USB cable connector (2). To remove the USB cable connector, depress the cable to release it from the socket.
- Page 4 REMOVAL OF ORIGINAL HEAD UNIT Road Glide To prevent accidental vehicle start-up, which could cause death or serious injury, remove main fuse before proceeding. 1. Detach each turn signal / indicator light by 2. Remove four inner fairing bolts using a T25 removing the adjacent allen socket screw, using Torx driver.
- Page 5 8. Disconnect electrical connections to the head unit. 8.1) Remove the main wire harness connector (1). To remove the main wire harness, depress connector to remove from the socket. 8.2) Remove the USB cable connector (2). To remove the USB cable connector, depress the cable to release it from the socket.
- Page 6 INSTALLATION OF HWD14+ HEAD UNIT To prevent accidental vehicle start-up, which could cause death or serious injury, remove main fuse before proceeding. 1. Install W HD14+ into the location of the OEM head unit. Secure the chassis to the OEM mounting location with the four bolts removed during the last step of REMOVAL OF ORIGINAL HEAD UNIT section using a 3/16”...
- Page 7 4. If an alternative handlebar integration module other than Scosche is available, skip this step and proceed to step 5. If included, connect the Scosche handlebar integration module to the corresponding 12-pin and 14-pin connectors on the wire harness of WHD14+. SCOSCHE 5.
- Page 8 (2-years) from the date of purchase from a Soundstream and/or Precision Power authorized retailer. During this two-year (2-year) period, there will be no service charge for repair or replacement.
