Congratulations on your decision to enjoy the finest spa available...
Welcome to the growing family of CALDERA spa owners.
Pre-Delivery Instructions
Please take the time to read this booklet carefully, as it will provide you with the information you will need to ensure
the safe, secure, and timely installation of your new spa. The following sections are guidelines on how to prepare for
delivery and set-up of your new spa. Specifically covered are site selection, delivery access, ground preparation, and
electrical requirements.
Remember to carefully read the Owner's Manual that accompanies your spa, and to complete the warranty card
within 10 days of delivery. These items, along with other valuable information, will be found in the Owner's Package
which has been placed in the equipment compartment of your spa, where you will also find a serial number.
WATKINS WELLNESS reserves the right to change features, specifications and design without notification and
without incurring any obligation.
DATE PURCHASED: _________________________________________________________________
DATE INSTALLED: ___________________________________________________________________
DEALER: ___________________________________________________________________________
ADDRESS: __________________________________________________________________________
TELEPHONE: _______________________________________________________________________
In most cities and counties, permits will be required for the installation of electrical circuits or the construction of
exterior surfaces (decks and gazebos). In addition, some communities have adopted residential barrier codes which
may require fencing and/or self-closing gates on the property to prevent unsupervised access to a pool (or spa)
by children under 5 years of age. Your Caldera
Standard for Safety Covers and as a result, is usually exempt from most barrier requirements. As a general practice,
your local Building Department will inform you of any applicable barrier requirements at the time a permit is obtained
for the installation of an electrical circuit. Your CALDERA dealer can provide information on which permits may be
required.
Vacanza
®
spa is equipped with a locking cover that meets the ASTM F1346
Series
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vacanza Series and is the answer not in the manual?

Questions and answers

Michael K Menegay
June 2, 2025

Step by step process to know how to check water chemical status for Marino

1 comments:
Mr. Anderson
June 2, 2025

To check the water chemical status for Caldera Spas Marino:

1. Test weekly for:
- Total Alkalinity (TA)
- pH
- Calcium Hardness (CH)
- Sanitizer (chlorine)

2. Use one of two recommended methods:
- Reagent Test Kit (more accurate)
- Test Strips (convenient but sensitive to heat and moisture)

3. Follow directions carefully on the test kit or strips for accurate results.

This answer is automatically generated

Michael K Menegay
June 5, 2025

The spa is cloudy after doing all the chemicals. Can’t figure out why? What do I do?

Summary of Contents for CalderaSpas Vacanza Series

  • Page 1 Vacanza Series ® Congratulations on your decision to enjoy the finest spa available... Welcome to the growing family of CALDERA spa owners. Pre-Delivery Instructions Please take the time to read this booklet carefully, as it will provide you with the information you will need to ensure the safe, secure, and timely installation of your new spa.
  • Page 2 Pre-Delivery Instructions SITE SELECTION AND PREPARATION IMPORTANT: Site selection and preparation are your responsibility. Carefully read these instructions and consult your authorized CALDERA dealer if you have any questions. You probably have a spot picked out for your new spa, whether it’s indoors or outdoors, on a patio or on a deck. Just make sure you check the following: •...
  • Page 3: Installation Notes

    round and evelInG reParatIon FOUNDATIONS FOR SPAS WITH ACCESSORIES Your CALDERA spa has been engineered to perform on several types (such as gazebo) of common yard surfaces. While a concrete slab is best for long-term use*, other foundations are acceptable so long as a level base is prepared prior to delivery.
  • Page 4 Pre-Delivery Instructions NOTE: It may be necessary to allow for additional over-head clearance if the spa will be rolled up or down an incline or moved up or down a short flight of stairs. Use the information below to determine the requirements for access to your desired location.
  • Page 5 ® PALATINO NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. FRONT VIEW DOOR DOOR 38.5” (98 cm) 35.5” (90 cm) 69.5" (176.5 69.5" (176.5 cm cm) ) ELECTRICAL 2.5” (6.3 cm) CUTOUT ELECTRICAL AIR VENT DO NOT BLOCK CUTOUT DRAIN...
  • Page 6 Pre-Delivery Instructions ® ® MARINO / VANTO NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions FRONT VIEW DOOR DOOR 36” (91 cm) 33” (83.9 cm) 64.75" (164.5 64.75" (164.5 cm cm) ) ELECTRICAL 2.5”...
  • Page 7 TARINO ™ NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions FRONT VIEW DOOR DOOR 33” (84 cm) 29.5” (75 cm) 62.5" (159 62.5" (159 cm cm) ) 2.5” (6.3 cm) ELECTRICAL ELECTRICAL AIR VENT DO NOT BLOCK CUTOUT CUTOUT DRAIN...
  • Page 8 Pre-Delivery Instructions CELIO ™ NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions DOOR 65in 164.16cm DOOR DOOR 65" (165 cm) 65in 164.16cm 29.5in 74.92cm 23.5in 59.80cm FRONT VIEW 29" (74 cm) 29.5in 74.92cm ELECTRICAL ELECTRICAL OUTLET...
  • Page 9 ® AVENTINE NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. FRONT VIEW 29” (74 cm) DOOR DOOR 25.5” (64 cm) 34.5" (88 34.5" (88 cm cm) ) ELECTRICAL 2.5” (6.3 cm) CUTOUT AIR VENT DO NOT BLOCK ELECTRICAL CUTOUT AIR VENT DO...
  • Page 10: Electrical Requirements

    Pre-Delivery Instructions ELECTRICAL REQUIREMENTS electInG oltaGe The PALATINO, MARINO and VANTO models require a 230 volt power supply. The TARINO, CELIO and AVENTINE may be converted from 115 volts to 230 volts. When the spa is connected to 115 volts, 20 amp, the heater will provide approximately 1000 watts of heat only when the thermostat is calling for heat.
  • Page 11 The TARINO, CELIO and AVENTINE spas come equipped with approximately 15 feet (4.5 m) of usable power cord (this is the maximum length allowed by regulatory standards and the National Electric Code). The power cord is wrapped in bubble packaging for shipping and can be found inside the equipment compartment. Disconnect the cord from the control box, feed through the electrical cutout then reconnect to the control box.
  • Page 12 Pre-Delivery Instructions INSTALLATION NOTE: After the spa has been installed, your electrician can connect the conduit from the subpanel to the spa’s control box and then complete the wiring connections in the control box. NOTE: Complete step-by-step Installation and wiring instructions for all models are included in the Owner’s Manual and with each sub-panel, which can be obtained from your dealer.
  • Page 13 TARINO, CELIO, & AVENTINE 230 volt converted mode WARNING! The exact physical location of the terminals on the GFCI breaker will vary between manufacturers. Connecting the hot wire to the neutral terminal will cause irreversible damage to the control box. 230V, 50 Amp, 2-POLE, CIRCUT BREAKER...
  • Page 14 Pre-Delivery Instructions SERVICES AVAILABLE FROM YOUR CALDERA SPA DEALER Pre-Delivery site inspection _____________ Deliver spa to installation site _____________ Unwrap spa and haul away packaging material _____________ Set up spa _____________ Fill the spa with water _____________ Explain and test the spa’s operation: _____________ •...
  • Page 15 ADDITIONAL PRODUCTS AVAILABLE FROM YOUR CALDERA SPA DEALER • FreshWater Salt System Start-Up Kit ® • FreshWater Salt System Replacement Cartridges • Ozone Kit • FreshWater Mineral Spa Sanitizer • Clean Screen Pre-Filter ® • FreshWater Vanishing Act Calcium Remover ®...
  • Page 16 acanza PecIFIcatIons PALATINO 89" x 89" 230 volt, 20A 400 Gal 5,295 & 30A Single 38.5" 65 ft² lbs/ft² Seating 2.3 m 4,000 phase GFCI (6 Adults) 1,525 2,420 .98 m 6 m² circuits 2.3 m kg/m² liters MARINO 84" x 84" 360 Gal 4,885 230 volt, 20A...
