˜ Parts description
Fig. A
Infrared signal receiver
1 ] [
button (on/off)
2 ] [
button (return to charging dock)
[ 3 ]
Bumper
[ 4 ]
Charging dock
[ 5 ]
Indicator light (charging dock)
6 ] [
Charging contact (charging dock)
7 ] [
Lug (primary filter)
8 ] [
Primary filter
[ 9 ]
HEPA filter
[ ]
Bottom cover (dust collector)
[ ]
Top cover (dust collector)
[ ]
Anti-drop sensor
[ ]
Castor
[ ]
Charging contact (product)
[ ]
Side brush (R)
[ ]
Wheel
[ ]
Roller brush
[ ]
Latch (roller brush cover)
[ ]
Dust collector
[ ]
Roller brush cover
[ ]
On/off switch
[ ]
Side brush (L)
[ ]
Fig. B
Weekday
[ ]
Clock
[ ]
indicator (corner mode)
[ ]
indicator (spot mode)
[ ]
indicator (automatic mode)
[ ]
indicator (return to charging dock)
[ ]
indicator (suction power)
[ ]
indicator (setting a schedule)
[ ]
indicator (setting the clock)
[ ]
Remote control
[ ]
Infrared signal transmitter
[ ]
Display
[ ]
MODE button (cleaning mode selection)
[ ]
button (up/moving forwards)
[ ]
button (start/stop)
[ ]
button (right/moving to the right)
[ ]
button (down/turning back)
[ ]
button (setting the clock)
[ ]
button (return to charging dock)
[ ]
button (setting a schedule)
[ ]
10 GB/IE/NI
button (left/moving to the left)
[ ]
button (suction power)
[ ]
Fig. D
Mains adapter
[ ]
Fig. H
Floor cloth
[ ]
Water tank
[ ]
Rubber cover
[ ]
Pin
[ ]
Fig. I
Release button (dust collector)
[ ]
Cleaning brush
[ ]
˜ Technical data
Robot vacuum cleaner
Operating voltage:
Rated power:
Rechargeable
battery:
Run time:
Charging time:
Suction power:
Water tank volume:
Dust collector volume:
Dimensions (Ø × H):
Charging dock
Rated output voltage:
Rated output current:
Remote control
Batteries:
14.4 V
30 W
Li-ion, 2,400 mAh,
14.4 V
max. 70 minutes
(varies by mode and
flooring)
approx. 4–6 hours
0.4/0.8/2.0 kPa
150 ml
500 ml (total)
435 ml (usable)
32 cm × 8 cm
19 V
0.6 A
2× 1.5 V ,
type AAA (included)
