Hytek SPT60A.K1 Technical Data Manual

Economy pump kit 230v - 50 lpm

Advertisement

Quick Links

Technical Data
ECONOMY PUMP KIT
230v - 50 LPM
SPT60A.K2
Applies to the following models
ONLY:
SPT60A.K2
SPT60A.K1
Please read carefully
BEFORE
commencing installation.
Registered Office: HYTEK (GB) LIMITED,
Delta House, Green Street, Elsenham, Bishop's Stortford,
CM22 6DS UK.
Registered in England No. 1915382
Tel:
+44 (0) 1279 815 600
Email:
info@hytekgb.com
www.hytekgb.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPT60A.K1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hytek SPT60A.K1

  • Page 1 Applies to the following models ONLY: SPT60A.K2 SPT60A.K1 Please read carefully BEFORE commencing installation. Registered Office: HYTEK (GB) LIMITED, Delta House, Green Street, Elsenham, Bishop’s Stortford, CM22 6DS UK. Registered in England No. 1915382 Tel: +44 (0) 1279 815 600 Email: info@hytekgb.com...
  • Page 2 • Switch & 2m long mains cable. • Integral filter & bypass. • Weatherproof to IP55 for outdoor use. • Pump kit includes 6m long delivery hose. • 2m long suction hose & strainer. • SPT60A.K1 Manual nozzle kit • SPT60A.K2 Automatic nozzle kit S653/3...
  • Page 3 IMPORTANT WARNING NOTES 1. This pump MUST NOT be used to dispense petrol or other flammable liquids. 2. It must not be sited adjacent to a petrol dispenser or any other hazardous zone. 3. Installation of this equipment and its associated tank, pipe work and fittings should only be carried out by qualified fuel installation engineers.
  • Page 4 INSTALLATION 1. If no wall-mounting bracket is supplied, mount on a horizontal surface using the holes provided in the pump feet, or use a tank/barrel mount adaptor if provided. 2. On assembly use a suitable thread-sealing compound or the PTFE tape supplied to seal all threaded joints. 3.
  • Page 5 INSTRUCTIONS FOR USE 1. Switch on pump. 2. Place nozzle spout in the fuel tank. 3. Squeeze nozzle trigger to dispense fuel. 4. On completion of delivery, release nozzle trigger and remove nozzle from fuel tank. OPERATION WARNING - FAILURE TO OBSERVE THE WARNINGS BELOW MAY LEAD TO THE PUMP UNIT BEING DAMAGED: 1.
  • Page 6 EXPLODED PUMP DIAGRAM AND PARTS LIST ITEM PART DESCRIPTION PART NUMBER Rotor SPT60A.1 Vanes (5 per rotor) SPT60A.2 On/Off Switch SPT60A.3 Foot casting (2 per pump) SPT60A.4 Flange Kit EP80.13 (2x Flanges with O-rings) Shaft Seal SPT60A.6 Fan Cover SPT60A.7 Bypass Assembly SPT60A.8 Pump Housing O-ring...
  • Page 7 NOTES S653/3...
  • Page 8 Regulations 2006 2002/96/EC 2003/108/EC Certificate Numbers EMC test report number: and Details: SZEE090616404102-1 By Centre Testing International Corp. Building C, Hongwei Industrial Zone, Baoan 70 District, Shenzen, Guangdong, China Authorized By: Clive Wellings Technical Manager Hytek Declaration Number: EC075/1 S653/3...
