How To Measure And Cut The Nylon String; String Buckle Assembly; Gripper Buckle Assembly - CIC SOFTTUBE ROBOTIC ARM Assembly & Instruction Manual

1
Measuring & Cutting
P6
Colored Box
Cut off the burrs
before assembly.
A5
A5
Correct
Incorrect
G12
G3
Cut off the burrs
before assembly.
G3
A3

How to Measure and Cut the Nylon String

P5
Nylon String
(approx. 800cm)
(approx. 315 inches

String Buckle Assembly

70 cm
(27.56 inches)
Pull tight
String Buckle

Gripper Buckle Assembly

39 cm
(15.35 inches)
Correct
Incorrect
Marker Pen (Fine)
)
Press
String
39 cm
Pull tight
Gripper Buckle
4
2
Cut String
x8
String
70 cm
Correct
Incorrect
x8
x1
Correct
Assembly Tip
A3
Assembly Tip
Incorrect
x1
