- Page 1 Your adorable smart friend Your adorable smart friend Your adorable smart friend Your adorable smart friend Assembly Instruction & Manual...
-
Page 3: Table Of Contents
CONTENTS ................Product Introduction ................Tools You May Need ................Mechanical Parts List ..................Plastic Parts ..........Tip:Cut Off The Burrs Before Assembly ................. Body Module Assembly ................. Head Module Assembly ............. Feet & Arms Module Assembly ..............How To Replace Batteries ..................... -
Page 4: Product Introduction
Tobbie The Robot Product Introduction Tobbie is an intelligent six legs robot which provides great interaction with children. Tobbie has two programmed modes to follow or avoid objects. In "Follow Me" mode, Tobbie follows the object which ever approaches it, and makes it feels like an obedient pet. Possessing IR auto detect, Tobbie can avoid obstacle in the "Explore"... - Page 5 Gear 40/10T(Pink) Gear 10T(Orange) Tapping Screw Tapping Screw Shaft ( Short ) Shaft ( Long ) (1:1) (1:1) Motor With Connector Motor With Connector Blue Black Black Battery Holder With Connector PC Board DC 6V Sticker...
-
Page 6: Plastic Parts
Plastic Parts Cut the plastic parts when they are required. Do not cut them in advance. 15 16 17 19 Tip:cut off the burrs before assembly burr burr burr... -
Page 7: Body Module Assembly
Body Module Assembly Blue Black P11x3 (Short) (Orange) (White) (Orange) Blue Black (Pink) - Page 8 P9x3...
- Page 9 Fasten P10 x4 to the bottom entirely. REMOVE Important : Remove assistance tool-A15 after above steps are finished.
- Page 10 Black (Long) (White) (Green) P12(Long) (Gray) (Blue) (White) P2(Gray) P3(Blue) (Green) (Orange) (Orange)
- Page 11 P9x3...
- Page 12 Important : Ensure A15 was removed before assembly of step 14. P9x4...
-
Page 13: Head Module Assembly
Head Module Assembly Body Module D2&D3 D2&D3 Important! Post P17 against corner of indent in A10 *P17 is on a white sticker sheet... - Page 14 P9x2 Fasten P9 x 2 as illustrated above with Cut off the burrs before assembly. burr burr burr burr...
- Page 15 Black Blue Black Press Down The Wires...
- Page 16 AAA(x4)
- Page 18 Side View...
- Page 19 Right View Left View...
- Page 20 A18x2 Make sure to snap on A18 with a “Click” Click Click...
- Page 21 Don’t mix up A1 & A2. Scale 1:1 PUSH PUSH...
- Page 22 PUSH PUSH...
- Page 24 Ensure the right direction of A19. Ensure the right direction of A17.
- Page 25 Scale 1:1 Don’t mix up A2 & A1. A1+B1 A2+B15 A2+B15 A1+B1 A1+B1 A2+B15...
- Page 26 P9x2 P9x2 P9x2...
-
Page 27: Feet & Arms Module Assembly
Feet & Arms Module Assembly... - Page 28 burr Cut off the burrs before assembly. burr burr Cut off the burrs before assembly. burr...
-
Page 29: How To Replace Batteries
How To Replace Batteries REMOVE REMOVE Battery( AAA) x 4... - Page 30 How To Play Power On - " Standby " Phase 1. Long-press the switch for 2 secs. Tobbie's eyes (LED) light up with sound effects 2. LED flashes enter " Standby " phase select playing mode. Note: Do not keep Tobbie waiting too long, Tobbie will keep stamping its feet with sound alerts to remind you.
- Page 31 Funway Follow-me mode Funway Explore mode...
-
Page 32: Warning
Power Off Long-press the switch for 3 secs. Tobbie becomes inactive, its LED eyes/Sound effects fade and then power off. Tobbie goes into " power off " mode. Warning Be gentle when holding Tobbie by its head, any improper motions (as shown to the right) might cause malfuction. -
Page 33: Trouble Shooting
Trouble Shooting 1. Ensure batteries are placed in correct polarity. ( refer to page 13, step 2. If Tobbie does not work ( LED doesn’t flash ) when pressing " power switch ", Check and ensure the screws are fastened to the bottom entirely ( refer to page 11, step 3. - Page 36 Batteries are to be inserted with the correct polarity. Do not attempt to recharge non-rechargeable batteries. Rechargeable batteries are only to be charged under adult supervision. Rechargeable batteries are to be removed from the toy before being charged. Copyright © 2018 CIC. All rights reserved 4350008931...
