Shrimp Assembly; Adjustment Tool Assembly - CIC SOFTTUBE ROBOTIC ARM Assembly & Instruction Manual

Use corresponding (size-compatible) screwdriver. By following steps
below, you can fasten the tapping screws perfectly.
Put the screwdriver
towards the top of
screws.
1
P7
P7 Sponge
2
1
P4
1
G4
2
F6
Unnecessary
burrs
Fasten tapping screws
(1) Screw in
(2) Feel the tension getting higher
(3) Keep screwing

Shrimp Assembly

2
C9/G18
C10/G23
Incorrect
Correct

Adjustment Tool Assembly

2
Don't mix up
P4 & P8.
P4 P8
1:1
Unnecessary
burrs
Unnecessary
burrs
Repeat until
screws are
tightly fastened.
2
P7
2
Incorrect
Correct
G19
Correct
Incorrect
3
It happens a lot some burrs are left at the edge
of plastic parts after cutting them off.
Make sure the burrs are completely removed to
avoid operation malfunction.
Please lock screws all the way
down to the bottom. If they are not
fastened tightly enough, parts may
come off. The product may
consequently not work.
Correct
C9/G18
Shrimp
C10/G23
Incorrect
Assembly Tip
White
Yellow
Assembly Tip
Adjustment Tool
