CIC SOFTTUBE ROBOTIC ARM Assembly & Instruction Manual page 48

Advertisement

5
Adjustment Tool
6
Fix both sides of the jig with your
thumb and forefinger.
7
Then adjust the upper C and lower D points,
rotate and adjust in ten-turn units.
C C
R
Use the adjustment tool to adjust the left A and
right B points, rotate and adjust in ten-turn units.
D D
A A
45
Rotate the adjustment tool while
observing the position of the triangle
mark to align the triangle with the
mark position.
Until you hear clicking sounds.
B B
Rotate and adjust until you hear clicking
sounds.
