CIC SOFTTUBE ROBOTIC ARM Assembly & Instruction Manual page 51

18
L
19
Fix both sides of the jig with your thumb
and forefinger.
20
Then adjust the upper and lower C and D
point, in units of ten-turn, rotate and adjust.
D D
Adjustment Tool
Use the knob to adjust the left and right A
and B points, in units of ten-turn, rotate and
adjust.
C C
A A
B B
48
Turn the adjustment tool while
observing the gap between H1 and
G8. Adjust until H1 touches G8.
Until you hear clicking sounds.
Rotate and adjust until you hear clicking
sounds.
