such as wood, aerated concrete, gypsum plaster
boards, etc. However, this requires a certain practise
and is only possible with short saw blades.
1. Place the saw onto the workpiece and switch it on.
2. Ensure that the bottom edge of the footplate rests
on the workpiece surface as shown on Fig. G.
3. Slowly saw into the workpiece at an angle,
moving the saw to a vertical position and
continue to saw along the cutting line.
4. Switch the saw off and lift off the workpiece
when the work is complete.
Dust extraction (Fig. E)
• Insert the dust extraction adapter (8) into the
dust extraction connection.
• Connect the hose of a vacuum cleaner to the
dust extraction adapter (8).
Optimum use
• Clamp the workpiece. Use a clamping device for
small workpieces.
• Draw a line to define the direction in which to
guide the saw blade.
• Firmly hold the machine by the grip.
• Set the sawing speed.
• Set the mitre angle.
• Switch on the machine.
• Wait until the machine has reached full speed.
• Place the saw shoe on the workpiece.
• Slowly move the machine along the pre-drawn
line, firmly pressing the saw shoe against the
workpiece.
• Do not apply too much pressure on the machine.
Let the machine do the work.
• Switch off the machine and wait for the machine
to come to a complete standstill before putting
the machine down.
5. MAINTENANCE
Before cleaning and maintenance, always
switch off the machine and remove the
battery pack from the machine.
Clean the machine casings regularly with a soft
cloth, preferably after each use. Make sure that
the ventilation openings are free of dust and
dirt. Remove very persistent dirt using a soft
cloth moistened with soapsuds. Do not use any
solvents such as gasoline, alcohol, ammonia, etc.
Chemicals such as these will damage the synthetic
components.
WWW.VONROC.COM
ENVIRONMENT
Faulty and/or discarded electrical or
electronic apparatus have to be collected at
the appropriate recycling locations.
Only for EC countries
Do not dispose of power tools into domestic waste.
According to the European Guideline 2012/19/EC
for Waste Electrical and Electronic Equipment and its
implementation into national right, power tools that
are no longer usable must be collected separately
and disposed of in an environmentally friendly way.
WARRANTY
VONROC products are developed to the highest
quality standards and are guaranteed free of defects
in both materials and workmanship for the period
lawfully stipulated starting from the date of original
purchase. Should the product develop any failure
during this period due to defective material and/or
workmanship then contact VONROC directly.
The following circumstances are excluded from this
guarantee:
• Repairs and or alterations have been made
or attempted to the machine by unauthorized
service centers;
• Normal wear and tear;
• The tool has been abused, misused or
improperly maintained;
• Non-original spare parts have been used.
This constitutes the sole warranty made by
company either expressed or implied. There are
no other warranties expressed or implied which
extend beyond the face hereof, herein, including
the implied warranties of merchantability and
fitness for a particular purpose. In no event
shall VONROC be liable for any incidental or
consequential damages. The dealers remedies
shall be limited to repair or replacement of
nonconforming units or parts.
The product and the user manual are subject to
change. Specifications can be changed without
further notice.
EN
9
