corresponding article number in below
specifications table for the correct
composition and contents of your set.
Batteries
Model No
included
JS505DC
-
S_JS505DC
CD832AA
S2_JS505DC
2 x CD832AA
S3_JS505DC
CD833AA
Machine information
Rated voltage
No load speed
Saw stroke
Max. saw capacity wood 0°
Max. saw capacity steel 0°
Weight
Sound pressure level LPA
Sound power level LWA
Vibration 'sawing sheet metal' 5.99 m/s² K=1.5 m/s²
Vibration 'sawing plywood'
Model No
Battery Type
Voltage
Capacity
Weight
Model No
Battery Type
Voltage
Capacity
Weight
To charge the battery only use the following
recommended charger:
Charger model
Charger power supply
Input
Output
WWW.VONROC.COM
Chargers
included
-
USB-C Cable
USB-C Cable
USB-C Cable
12V
3000/min
17.5mm
55mm
6mm
0.75 kg
80 dB(A), K=5dB(A)
88 dB(A), K=5dB(A)
7.06 m/s² K=1.5 m/s²
CD832AA
Lithium-Ion
12V
2.0 Ah
0.18 kg
CD833AA
Lithium-Ion
12V
4.0 Ah
0.4 kg
XZ0500-2200WU
XZ0500-2200WUB
100-240 V~;50/60 Hz; 0.3 A
5 V d.c.; 2.0 A
Only use the following batteries of the VONROC
VPOWER 12V battery platform. Using any other
batteries could cause serious injury or damage the tool.
CD832AA 12V, 2Ah Lithium-Ion
CD833AA 12V, 4Ah Lithium-Ion
The following charger of the can be used to charge
these batteries.
USB-C Cable 5V 1-2A
The batteries of the VONROC VPOWER 12V battery
platform are interchangeable with all the VONROC
VPOWER 12V battery platform tools.
Vibration level
The vibration emission level stated in this instruction
manual has been measured in accordance with
a standardized test given in EN 62841; it may be
used to compare one tool with another and as
a preliminary assessment of exposure to vibration
when using the tool for the applications mentioned.
• Using the tool for different applications, or with
different or poorly maintained accessories, may
significantly increase the exposure level.
• The times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work patterns.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-4.
1. On/off switch
2. Chuck
3. Machine
4. Baseplate
5. Battery
6. Battery unlock button
7. Battery LED indicator
8. Charger LED indicator
9. Scale for bevel angle
10. Vacuum cleaner adapter
11. Guide roller
12. Guard
13. Clamping lever
14. Hex key
15. Saw blade
16. Bolt for baseplate
